IEI Technology ROCKY-6614 User Manual

Lga 775 pentium 4 full-size cpu card with dual gbe, dual sata and usb 2.0
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ROCKY-6614 CPU Card
0-1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROCKY-6614 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology ROCKY-6614

Summary of Contents for IEI Technology ROCKY-6614

  • Page 1 ROCKY-6614 CPU Card...
  • Page 2 CKY-6614 WSB- Card REVISION HISTORY Title ROCKY-6614 Intel Pentium 4 M/Pentium M Socket 479 CPU board Revision Number Description Date of Issue Initial release March 2006 COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer.

  • Page 3: Table Of Contents

    1.1.2 ROCKY-6614 CPU Board Benefits..............14 1.1.3 ROCKY-6614 CPU Board Features..............14 ROCKY-6614 CPU B ............15 OARD VERVIEW 1.2.1 ROCKY-6614 CPU Board Connectors ............15 1.2.2 Technical Specifications................... 16 DETAILED SPECIFICATIONS ................19 IEI B ................20 OMPATIBLE ACKPLANES CPU S ....................
  • Page 4 2.19.2 Optional Accessory Items................30 CONNECTORS AND JUMPERS ................. 31 .............. 32 ERIPHERAL NTERFACE ONNECTORS 3.1.1 ROCKY-6614 CPU Board Layout..............32 3.1.2 Peripheral Interface Connectors ..............33 3.1.3 Rear Panel Connectors ..................34 3.1.4 Onboard Jumpers..................... 34 ..............35 NTERNAL...
  • Page 5 ROCKY-6614 CPU Card 4.1.1 Installation Notices ..................58 ......................59 NPACKING 4.2.1 Unpacking Precautions..................59 4.2.2 Checklist......................59 ROCKY-6614 CPU C ............60 NSTALLATION 4.3.1 CPU Installation ....................61 4.3.1.1 CPU Selection: HT Functionality Requirements ........61 4.3.1.2 CPU Installation..................61 4.3.2 Cooling Kit (CF-520) Installation ..............
  • Page 6 CKY-6614 WSB- Card 5.3.6 ACPI Configuration ..................98 5.3.6.1 General ACPI Configuration..............99 5.3.6.2 Advanced ACPI Configuration ............... 100 5.3.7 MPS Configuration ..................103 5.3.8 Smbios ......................103 5.3.9 Remote Access Configuration ................ 104 5.3.10 USB Configuration..................107 PCI/P P ......................110 ........................116 5.5.1 Boot Settings Configuration................117 5.5.2 Boot Device Priority ..................
  • Page 7 ROCKY-6614 CPU Card DMA C ............... 174 HANNEL SSIGNMENTS EXTERNAL AC’97 AUDIO CODEC ..............176 ....................177 NTRODUCTION ..................177 RIVER NSTALLATION ..............178 OUND FFECT ONFIGURATION ....................179 OUND FFECT ................180 NVIRONMENT IMULATION ....................181 ARAOKE ..................182...
  • Page 8 Figure 3-11: SATA Connector Locations ..............48 Figure 3-12: KB1 Connector Location...............49 Figure 3-13: ATX Connector Location...............50 Figure 3-14: ROCKY-6614 CPU Board Rear Panel ..........51 Figure 3-15: PS/2 Pinout locations ................52 Figure 3-16: RJ-45 Ethernet Connector ..............53 Figure 3-18: Jumper Locations..................55 Figure 4-1: Intel LGA775 Socket ................62...
  • Page 9 ROCKY-6614 CPU Card Figure 6-5: Restart the Computer ................145 Figure 6-6: Audio Driver Install Shield Wizard Starting ........146 Figure 6-7: Audio Driver Setup Prerparation............146 Figure 6-8: Audio Driver Welcome Screen ............147 Figure 6-9: Audio Driver Software Configuration ..........147 Figure 6-10: Audio Driver Digital Signal ..............
  • Page 10 CKY-6614 WSB- Card List of Tables Table 1-1: Technical Specifications ................17 Table 2-1: Supported CPUs..................20 Table 2-2: Power Consumption .................30 Table 3-1: Peripheral Interface Connectors..............34 Table 3-2: Peripheral Interface Connectors..............34 Table 3-3: Onboard Jumpers ..................34 Table 3-4: FDD Connector Pinouts................36 Table 3-5: IDE Connector Pinouts ................37 Table 3-6: Internal COM Port Connector Pinouts ............39 Table 3-7: LPT Connector Pinouts ................40...
  • Page 11 ROCKY-6614 CPU Card List of BIOS Menus Menu 1: Main ....................74 Menu 2: Advanced 76 Menu 3: CPU Configuration ..................77 Menu 4: IDE Configuration ..................82 Menu 5: IDE Master and IDE Slave Configuration ...........86 Menu 6: Floppy Configuration ...................92 Menu 7: Super IO Configuration ................93 Menu 8: Hardware Health Configuration ..............97...
  • Page 12 CKY-6614 WSB- Card Glossary AC ’97 Audio Codec 97 Hard Disk Drive ACPI Advanced Configuration and Integrated Data Electronics Power Interface Input/Output Advanced Power Management ICH4 I/O Controller Hub 4 ARMD ATAPI Removable Media Device L1 Cache Level 1 Cache ASKIR Shift Keyed Infrared L2 Cache Level 2 Cache Advanced Technology...

  • Page 13: Introduction

    ROCKY-6614 CPU Card Chapter Introduction 1-13...

  • Page 14: Rocky-6614 Cpu Board Overview

    CKY-6614 WSB- Card ROCKY-6614 CPU Board Overview The PICMG 1.0 form factor ROCKY-6614 LGA775 Pentium 4 CPU platform is fully equipped with a high performance processor and advanced multi-mode I/Os. The ROCKY-6614 is designed for system manufacturers, integrators, and VARs that want performance, reliability, and quality at a reasonable price.

  • Page 15: Rocky-6614 Cpu Board Connectors

    ROCKY-6614 CPU Card ROCKY-6614 CPU Board Overview Figure 1-1: ROCKY-6614 CPU Board Overview 1.2.1 ROCKY-6614 CPU Board Connectors The ROCKY-6614 CPU board has the following connectors onboard: 1 x ATX 12V connector 1 x CPU cooling fan connector 1 x IrDA connector...

  • Page 16: Technical Specifications

    CKY-6614 WSB- Card 1 x Keyboard connector The ROCKY-6614 CPU board has the following connectors on the board rear panel: 1 x PS/2 connector 1 x VGA connector 1 x LINE_OUT connector 1 x RJ-45 Ethernet connector 2 x USB ports The location of these connectors on the CPU Card can be seen in Figure 1-1.

  • Page 17: Table 1-1: Technical Specifications

    ROCKY-6614 CPU Card USB Interfaces Eight USB 2.0 connectors supported Serial Ports Two COM ports Real Time Clock 256-byte battery backed CMOS RAM Hardware Monitoring Cooling fans, temperature and system voltages Power Management Supports Advanced Configuration and Power Interface (ACPI) Specifications Revision 2.0...

  • Page 18: This Page Is Intentionally Left Blank

    CKY-6614 WSB- Card THIS PAGE IS INTENTIONALLY LEFT BLANK ® Technology, Corp. 1-18...

  • Page 19: Detailed Specifications

    ROCKY-6614 CPU Card Chapter Detailed Specifications 1-19...

  • Page 20: Compatible Iei Backplanes

    CKY-6614 WSB- Card Compatible IEI Backplanes The ROCKY-6614 CPU card is compatible with all IEI PICMG1.0 backplanes. For more information on these backplanes, please visit the IEI website or contact your CPU card reseller or vendor. CPU Support Table 2-1 lists the CPUs supported by the ROCKY-6614 CPU board.

  • Page 21: Onboard Chipsets

    ROCKY-6614 CPU Card Onboard Chipsets 2.3.1 Northbridge and Southbridge Chipsets The following chipsets are preinstalled on the board: Northbridge: SiS661CX Southbridge: SiS964 The following two sections (Section 2.3.2 and Section 2.3.3) list some of the features of the SiS661CX and the SiS964 chipsets. For more information on these two chipsets please refer to the SiS website.

  • Page 22: Sis964 Southbridge Chipset

    CKY-6614 WSB- Card 2.3.3 SiS964 Southbridge Chipset The SiS964 southbridge chipset comes with the following features: SiS MuTIOL® 1G Delivering 1GB/s Bandwidth Proprietary Interconnect between SiS north bridge and SiS964 southbridge Bi-Directional 16 bit Data Bus at 533MHz Operating Frequency Integrated Serial Host Controller Provides 2 independent ports for SATA, compliant with Serial ATA 1.0 specification with transfer rate 150MB/s...

  • Page 23: Figure 2-1: Data Flow Block Diagram

    ROCKY-6614 CPU Card Figure 2-1: Data Flow Block Diagram 1-23...

  • Page 24: Graphics Support

    LCD highest resolution mode: 1600x1200x32@ 60NI TV highest resolution mode: 1024x768x32@60NI Memory Support The ROCKY-6614 CPU has two 240-pin dual inline memory module (DIMM) sockets and supports up to two un-buffered DDR DIMMs with the following specifications: Maximum RAM: 2GB (1GB module in each slot) DIMM Transfer Rates: 400MHz, 333MHz ®...

  • Page 25: Pci Bus Interface Support

    ROCKY-6614 CPU Card PCI Bus Interface Support The PCI bus on the ROCKY-6614 CPU Board has the following features: 33MHz Revision 2.3 is implemented Up to six external bus masters are supported Maximum throughput: 133MB/sec Master devices: Maximum of six with three implemented...

  • Page 26: Drive Interfaces

    The ROCKY-6614 CPU Board supports the following SATA drives: 2 x first generation SATA drives with transfer rates up to 150MB/s 2.9.2 IDE HDD Interfaces The ROCKY-6614 southbridge chipset IDE controller supports up to two HDDs with the following specifications: Supports PIO IDE transfers up to 16MB/s...

  • Page 27: Real Time Clock

    The ROCKY-6614 CPU board has eight USB interfaces, six internal and two external. The USB interfaces support USB 2.0. 2.15 BIOS The ROCKY-6614 CPU Board uses a licensed copy of AMI BIOS. The features of the flash BIOS used are listed below: SMIBIOS (DMI) compliant...

  • Page 28: Operating Temperature And Temperature Control

    2.17 Audio Codec The ROCKY-6614 has an integrated REALTEK ALC655 CODEC. The ALC655 CODEC is a 16-bit, full-duplex AC'97 Rev. 2.3 compatible six-channel audio CODEC designed for PC multimedia systems, including host/soft audio and AMR/CNR-based designs. Some of the features of the codec are listed below.

  • Page 29: Power Consumption

    Configuration Panel for improved user convenience 2.18 Power Consumption Table 2-2 shows the power consumption parameters for the ROCKY-6614 CPU board when a Pentium 4 processor with a clock speed of 3.4GHz, an L2 cache of 2MB and a FSB 800MHz is running with a 2GB DDR400 module.

  • Page 30: Packaged Contents And Optional Accessory Items

    Table 2-2: Power Consumption 2.19 Packaged Contents and Optional Accessory Items 2.19.1 Package Contents When you unpack the ROCKY-6614 CPU board you should find the following components. 1 x ROCKY-6614 single board computer 1 x mini jumper pack 1 x ATA 66/100 flat cable (P/N: 32200-000052-RS)

  • Page 31: Connectors And Jumpers

    ROCKY-6614 CPU Card Chapter Connectors and Jumpers 1-31...

  • Page 32: Peripheral Interface Connectors

    The locations of the peripheral interface connectors are shown in Section 3.1.1. A complete list of all the peripheral interface connectors can be seen in Section 3.1.2. 3.1.1 ROCKY-6614 CPU Board Layout Figure 3-1 shows the onboard peripheral connectors, backplane peripheral connectors and onboard jumpers.

  • Page 33: Peripheral Interface Connectors

    ROCKY-6614 CPU Card 3.1.2 Peripheral Interface Connectors Table 3-1 shows a list of the peripheral interface connectors on the ROCKY-6614 CPU board. Detailed descriptions of these connectors can be found in Section 3.2 on page 35. Label Connector Type FDD1...

  • Page 34: Rear Panel Connectors

    Keyboard connector 5-pin header Table 3-1: Peripheral Interface Connectors 3.1.3 Rear Panel Connectors Table 3-2 lists the rear panel connectors on the ROCKY-6614 CPU card. Detailed descriptions of these connectors can be found in Section 3.3 on page 51. Label Connector...

  • Page 35: Internal Peripheral Connectors

    CN Type: 2x17 pin header CN Location: See Figure 3-2 CN Pinouts: See Table 3-4 The ROCKY-6614 is shipped with a 34-pin daisy-chain drive connector cable. This cable can be connected to the FDD connector. DESCRIPTION DESCRIPTION REDUCE WRITE INDEX#...

  • Page 36: Figure 3-2: Fdd Connector Location

    CKY-6614 WSB- Card READ DATA# SIDE 1 SELECT# DISK CHANGE# Table 3-4: FDD Connector Pinouts Figure 3-2: FDD Connector Location ® Technology, Corp. 1-36...

  • Page 37: Ide Connectors

    ROCKY-6614 CPU Card 3.2.2 IDE Connectors CN Label: PIDE1 and SIDE2 CN Type: 2x20 pin header CN Location: See Figure 3-3 CN Pinouts: See Table 3-5 Two IDE connectors provide connectivity for four IDE devices. PIN NO. DESCRIPTION PIN NO.

  • Page 38: Com Ports

    CN Type: 2x5 pin headers CN Location: See Figure 3-4 CN Pinouts: See Table 3-6 The ROCKY-6614 CPU board has two internal high-speed UART connectors accessed through a 10-pin cable connector. DESCRIPTION DESCRIPTION DATA CARRIER DETECT (DCD) DATA SET READY (DSR)

  • Page 39: Parallel Port

    ROCKY-6614 CPU Card TRANSMIT DATA (TXD) CLEAR TO SEND (CTS) DATA TERMINAL READY (DTR) RING INDICATOR (RI) GND (GND) GND (GND) Table 3-6: Internal COM Port Connector Pinouts Figure 3-4: COM Port Locations 3.2.4 Parallel Port CN Label: LPT1 CN Type:...

  • Page 40: Figure 3-5: Lpt Connector Location

    CKY-6614 WSB- Card DESCRIPTION DESCRIPTION STROBE# AUTO FORM FEED # DATA0 ERROR# DATA1 INITIALIZE# DATA2 PRINTER SELECT LN# DATA3 DATA4 DATA5 DATA6 DATA7 ACKNOWLEDGE# BUSY PAPER EMPTY PRINTER SELECT Table 3-7: LPT Connector Pinouts Figure 3-5: LPT Connector Location ® Technology, Corp.

  • Page 41: Internal Usb Connectors

    ROCKY-6614 CPU Card 3.2.5 Internal USB Connectors CN Label: USB23, USB45, USB67 CN Type: 2x4 pin header CN Location: See Figure 3-6 CN Pinouts: See Table 3-8 Three 2x4 pin connectors provide connectivity to six USB 2.0 ports. Two additional USB ports are found on the rear panel.

  • Page 42: Cooling Fan Connector

    CKY-6614 WSB- Card 3.2.6 Cooling Fan Connector CN Label: CPU_FAN1 CN Type: 1x3 pin header CN Location: See Figure 3-7 CN Pinouts: See Table 3-9 The CPU_FAN1 CPU cooling fan connector provides a 12V, 500mA current to the cooling fan. The connector has a "rotation" pin to get rotation signals from fans and notify the system so the system BIOS can recognize the fan speed.

  • Page 43: Backplane To Mainboard Atx Connector

    ROCKY-6614 CPU Card 3.2.7 Backplane to Mainboard ATX Connector CN Label: ATXCTL1 CN Type: 1x3 pin header CN Location: See Figure 3-8 CN Pinouts: See Table 3-10 Connects a power source from a backplane with an ATX Connector. PIN NO.

  • Page 44: System Front Panel Connector

    CKY-6614 WSB- Card 3.2.8 System Front Panel Connector CN Label: F_PANEL1 CN Type: 2x7 pin header CN Location: See Figure 3-9 CN Pinouts: See Table 3-11 The system panel connector connects to: the system chassis front panel LEDs the chassis speaker the power switch the reset button.

  • Page 45: Irda Connector

    ROCKY-6614 CPU Card Figure 3-9: System Panel Connector Location 3.2.9 IrDA Connector CN Label: CN Type: 1x6 pin header CN Location: See Figure 3-10 CN Pinouts: See Table 3-12 The integrated IrDA connector supports both the SIR and ASKIR infrared protocols.

  • Page 46: Figure 3-10: Irda Connector Location

    CKY-6614 WSB- Card DESCRIPTION VCC5 IR-RX IR-TX CIRRX Table 3-12: IrDA Connector Pinouts Figure 3-10: IrDA Connector Location ® Technology, Corp. 1-46...

  • Page 47: Sata Drive Connectors

    ROCKY-6614 CPU Card 3.2.10 SATA Drive Connectors CN Label: SATA1, SATA2 CN Type: 1x7 pin port CN Location: See Figure 3-11 CN Pinouts: See Table 3-13 The SATA drive ports provide connectivity to SATA drives with a maximum data transfer rate of 150MB/s.

  • Page 48: Figure 3-11: Sata Connector Locations

    CKY-6614 WSB- Card Figure 3-11: SATA Connector Locations NOTE: 1. SATA is supported by: • Windows 2000 SP4 • Windows XP SP1 • Windows 2003, or later versions. 2. Older OSes, such as Windows 98SE or ME, do not support the SATA interface. ®...

  • Page 49: Keyboard Connector

    ROCKY-6614 CPU Card 3.2.11 Keyboard Connector CN Label: CN Type: 1x5 pin header CN Location: See Figure 3-12 CN Pinouts: See Table 3-14 For alternative application, a keyboard pin header connector is also available on board. PIN NO. DESCRIPTION KEYBOARD CLOCK...

  • Page 50: Atx-12V Power Source Connector

    CKY-6614 WSB- Card 3.2.12 ATX-12V Power Source Connector CN Label: CPU12V CN Type: 2x2 pin header CN Location: See Figure 3-13 CN Pinouts: See Table 3-15 This connector supports the ATX-12V power supply. PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V +12V Table 3-15: CN100 Connector Pinouts Figure 3-13: ATX Connector Location...

  • Page 51: External (Rear Panel) Connectors

    ROCKY-6614 CPU Card External (Rear Panel) Connectors Figure 3-14 shows the ROCKY-6614 CPU board rear panel. The peripheral connectors on the back panel can be connected to devices externally when the CPU card is installed in a chassis. The peripheral connectors on the rear panel are:...

  • Page 52: Usb Connectors

    CKY-6614 WSB- Card Clock Table 3-16: PS/2 Pinouts Figure 3-15: PS/2 Pinout locations 3.3.2 USB Connectors CN Label: USB_C0, USB_C1 CN Type: USB port CN Location: See Figure 3-14 (labeled number 2 and 3) CN Pinouts: See Table 3-17 USB devices can be connected directly to the USB connectors on the rear panel. DESCRIPTION DESCRIPTION DATA-...

  • Page 53: Vga Connector

    ROCKY-6614 CPU Card One 1Gb connections can be made between the Ethernet connector and a Local Area Network (LAN) through a network hub. An RJ-45 Ethernet connector is shown in Figure 3-16. DESCRIPTION DESCRIPTION TXD+ GRN+ TXD- GRN- RXD+ CT_TXD...

  • Page 54: Onboard Jumpers

    To CLOSE/SHORT a jumper means connecting the pins of the jumper with the plastic clip and to OPEN a jumper Figure 1-3-17 Jumper means removing the plastic clip from a jumper. The ROCKY-6614 CPU Board one onboard jumper, “Clear CMOS.” ® Technology, Corp. 1-54...

  • Page 55: Reset Cmos Jumper

    ROCKY-6614 CPU Card Figure 3-18: Jumper Locations 3.4.1 Reset CMOS Jumper Jumper Label: J_CMOS1 Jumper Type: 3 pin header Jumper Settings: See Table 3-21 Jumper Location: See Figure 3-18 1-55...

  • Page 56: Table 3-21: Jp2 Jumper Settings

    CKY-6614 WSB- Card If the CPU Card fails to boot due to improper BIOS setting, use this jumper to clear the CMOS data and reset the system BIOS information. To do this, use the jumper cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1 and 2. If the “CMOS Settings Wrong”...

  • Page 57: Installation And Configuration

    ROCKY-6614 CPU Card Chapter Installation and Configuration 1-57...

  • Page 58: Installation Considerations

    CPU card and injury to the person installing the CPU card. 4.1.1 Installation Notices Before and during the installation of the ROCKY-6614 CPU Board, please do the following: Read the user manual The user manual provides a complete description of the ROCKY-6614 CPU board, installation instructions and configuration options.

  • Page 59: Unpacking

    CPU card from. 4.2.1 Unpacking Precautions Before you install the ROCKY-6614 CPU card, you must unpack the CPU card. Some components on ROCKY-6614 are very sensitive to static electricity and can be damaged by a sudden rush of power.

  • Page 60: Rocky-6614 Cpu Card Installation

    1 x Utility CD 1 x QIG If one or more of these items are missing, please contact the reseller or vendor you purchased the ROCKY-6614 CPU card from and do not proceed any further with the installation. ROCKY-6614 CPU Card Installation WARNING! 1.

  • Page 61: Cpu Installation

    ROCKY-6614 CPU Card WARNING! When installing electronic components onto the CPU Card always take the following anti-static precautions in order to prevent ESD damage to your board and other electronic components like the CPU and DIMM modules The following components must be installed onto the CPU Card or connected to the CPU Card during the installation process.

  • Page 62: Figure 4-1: Intel Lga775 Socket

    CKY-6614 WSB- Card The LGA775 socket is shown in Figure 4-1. Figure 4-1: Intel LGA775 Socket To install Intel LGA775 socket CPU onto your CPU Card, follow the steps below: Remove the protective cover. Remove the black protective cover by prying it Step 1: off the load plate.

  • Page 63: Figure 4-3: Open The Cpu Socket Load Plate

    ROCKY-6614 CPU Card Figure 4-3: Open the CPU Socket Load Plate Inspect the CPU and the socket. Make sure that the pins on the CPU are not Step 3: bent. Also make sure socket contacts are free of foreign material. If you see any debris in the socket remove it using compressed air.

  • Page 64: Cooling Kit (Cf-520) Installation

    It is strongly recommended that you use the original heatsink and cooler provided by Intel on the ROCKY-6614. The CPU board is vertically mounted on a horizontal backplane, and Intel’s heatsink does not come with a support bracket on the soldering side, the PCB may be bent by the weight of the cooling kit.
  • Page 65 ROCKY-6614 CPU Card The IEI LGA775 CPU cooling kit (CF-520) shown in Figure 4-5 comprises a CPU heatsink and a cooling fan. CAUTION: The CF-520 heatsink has a layer of thermal paste sprayed on the lower surface. Do not accidentally wipe the thermal paste away when you unpack or install the heatsink.

  • Page 66: Dimm Module Installation

    CKY-6614 WSB- Card Figure 4-6: Securing the heatsink to the PCB board Use the screwdriver to tighten the four screws. Tighten each nut a few turns at a Step 4: time and do not over-tighten the screws. Connect the fan cable on the cooler fan to the CPU fan connector on the CPU Step 5: card.

  • Page 67: Dimm Module Installation

    Both DIMMs must be either single-sided or dual-sided. 4.3.3.2 DIMM Module Installation The ROCKY-6614 CPU Board has two DDR SDRAM DIMM sockets. To install the DIMM modules, follow the instructions below. Pull the two white handles on either side of the DIMM socket down.

  • Page 68: Ide Disk Drive Connector (Ide1)

    CKY-6614 WSB- Card 4.3.4.1 IDE Disk Drive Connector (IDE1) The cable used to connect the CPU card to the IDE HDD is a standard 44-pin ATA 66/100 flat cable. To connect an IDE HDD to the CPU Card, follow the instructions below. Find the ATA 66/100 flat cable in the kit that came with the CPU Card.

  • Page 69: Chassis Installation

    ROCKY-6614 CPU Card Chassis Installation After the CPU, the cooling kit, and the DIMM modules have been installed and after the internal peripheral connectors have been connected to the peripheral devices and the jumpers have been configure, the CPU Card can be mounted into chassis.
  • Page 70 CKY-6614 WSB- Card THIS PAGE IS INTENTIONALLY LEFT BLANK ® Technology, Corp. 1-70...

  • Page 71: Ami Bios Setup

    ROCKY-6614 CPU Card Chapter AMI BIOS Setup 1-71...

  • Page 72: Introduction

    CKY-6614 WSB- Card Introduction A licensed copy of AMI BIOS is preprogrammed into the ROM BIOS. The BIOS setup program allows users to modify the basic system configuration. This chapter describes how to access the BIOS setup program and the configuration options you may change. 5.1.1 Starting Setup The AMI BIOS is activated when you turn on the computer.

  • Page 73: Getting Help

    ROCKY-6614 CPU Card F2 /F3 key Change color from total 16 colors. F2 to select color forward. F10 key Save all the CMOS changes, only for Main Menu Table 5-1: BIOS Navigation Keys 5.1.3 Getting Help When you press F1 a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears.

  • Page 74: Main

    CKY-6614 WSB- Card Main When you enter the BIOS Setup program, the Main menu (BIOS Menu 1) appears. The Main menu gives you an overview of the basic system information. BIOS Menu 1: Main System Overview The System Overview lists a brief summary of different system components. The fields in System Overview cannot be changed.

  • Page 75: Advanced

    ROCKY-6614 CPU Card Installed BIOS ID Processor: Displays auto-detected CPU specifications Type: Names the currently installed processor Speed: Lists the processor speed Count: The number of CPUs on the CPU board System Memory: Displays the auto-detected system memory. Size: Lists memory size The System Overview field also has two user configurable fields: System Time [xx:xx:xx]: Allows you to set the system time.

  • Page 76: Cpu Configuration

    CKY-6614 WSB- Card BIOS Menu 2: Advanced 5.3.1 CPU Configuration The CPU Configuration menu (BIOS Menu 3) shows detailed CPU specifications and CPU configuration options. ® Technology, Corp. 1-76...

  • Page 77: Menu 3: Cpu Configuration

    ROCKY-6614 CPU Card BIOS Menu 3: CPU Configuration [Advanced] The CPU Configuration menu (BIOS Menu 3) lists the following CPU details: Manufacturer: Lists the name of the CPU manufacturer Brand String: Lists the brand name of the CPU being used...

  • Page 78: Ratio Cmos Setting [18]

    CKY-6614 WSB- Card Ratio CMOS Setting [18] The Ratio CMOS Setting sets the ratio between the core clock and the FSB frequency. The following configuration options are available: NOTE: If an invalid ratio has been entered to this field, BIOS will restore it to the previous state.

  • Page 79: Hardware Prefetcher [Enabled]

    ROCKY-6614 CPU Card Hardware Prefetcher [Enabled] The Hardware Prefetcher BIOS option allows you to set the CPU prefetching data feature. Disabled Does not allow the Hardware Prefetcher Disable feature to be enabled or disabled. (Default) Allows the Hardware Prefetcher Disable feature to be...

  • Page 80: Cpu/Dram Frequency Ratio [1:1]

    CKY-6614 WSB- Card The CPU Frequency Setting BIOS option is not user configurable. The setting indicates the frequency of the CPU. This setting will only be configurable when the Auto Detect CPU and DRAM FREQU BIOS option is disabled. CPU/DRAM Frequency Ratio [1:1] The CPU/DRAM Frequency Ratio BIOS option allows you to set the ratio between the CPU Frequency Setting (CFS) stipulated above (previous configuration option) and the RAM speed.

  • Page 81: Ide Configuration

    ROCKY-6614 CPU Card DRAM Frequency [200*2 MHz] The DRAM Frequency is not user configurable but reflects the DRAM frequency setting after the CPU/DRAM Frequency Ratio (described above) has been set. This setting will only appear when the Auto Detect CPU and DRAM FREQU BIOS option is disabled.

  • Page 82: Onboard Pci Ide Controller [Both]

    CKY-6614 WSB- Card BIOS Menu 4: IDE Configuration [Advanced] OnBoard PCI IDE Controller [Both] The OnBoard PCI IDE Controller BIOS option specifies the IDE channels used by the onboard PCI IDE controller. The following configuration options are available. Disabled Prevents the system from using the onboard IDE controller Primary Only allows the system to detect the Primary IDE...

  • Page 83: Onboard Pci Ide Mode [Legacy Mode]

    ROCKY-6614 CPU Card Secondary Slave) (Default) Allows the system to detect both the Primary and Both Secondary IDE channels including the Primary Master, Primary Slave, Secondary Master and Secondary Slave. Onboard PCI IDE Mode [Legacy Mode] The Onboard PCI IDE Mode BIOS option allows you to set the running mode for the PCI IDE.

  • Page 84: Hard Disk Write Protect [Disabled]

    CKY-6614 WSB- Card Primary IDE Slave Secondary IDE Master Secondary IDE Slave Third IDE Master Third IDE Slave The IDE Configuration menu (BIOS Menu 4) allows you to set or change the configurations for the IDE devices installed in the system. If an IDE device is detected, and one of the above listed four BIOS configuration options are selected, the IDE configuration options shown in Section 　...

  • Page 85: Ata (Pi) 80Pin Cable Detection [Host & Device]

    ROCKY-6614 CPU Card The best setting to use if the onboard IDE controllers are set to a specific IDE disk drive in the AMIBIOS is “0 seconds” and a large majority of ultra ATA hard disk drives can be detected well within “5 seconds” (the default setting).

  • Page 86: Ide Master, Ide Slave

    CKY-6614 WSB- Card 5.3.2.1 IDE Master, IDE Slave IDE Master and IDE Slave configuration options for both primary and secondary IDE devices are shown in the BIOS menu below. BIOS Menu 5: IDE Master and IDE Slave Configuration [Advanced/IDE Configuration] Auto-Detected Drive Parameters The “grayed-out”...

  • Page 87: Type [Auto]

    ROCKY-6614 CPU Card LBA Mode: Indicates whether the LBA (Logical Block Addressing) is a method of addressing data on a disk drive is supported or not. Block Mode: Block mode boosts IDE drive performance by increasing the amount of data transferred. Only 512 bytes of data can be transferred per interrupt if block mode is not used.

  • Page 88: Lba/Large Mode [Auto]

    CKY-6614 WSB- Card LS-120 LBA/Large Mode [Auto] The LBA/Large Mode BIOS option allows you to disable or auto detect LBA (Logical Block Addressing). LBA is a method of addressing data on a disk drive. In LBA mode, the maximum drive capacity is 137 GB. This selection prevents the BIOS from using the LBA Disabled mode control on the specified channel.

  • Page 89: Dma Mode [Auto]

    ROCKY-6614 CPU Card PIO mode 0 selected with a maximum transfer rate of 3.3MBps PIO mode 1 selected with a maximum transfer rate of 5.2MBps PIO mode 2 selected with a maximum transfer rate of 8.3MBps PIO mode 3 selected with a maximum transfer rate of 11.1MBps PIO mode 4 selected with a maximum transfer rate of 16.6MBps...

  • Page 90: Auto]

    CKY-6614 WSB- Card UDMA1 Ultra DMA mode 0 selected with a maximum data transfer rate of 16.6MBps UDMA1 Ultra DMA mode 1 selected with a maximum data transfer rate of 25MBps UDMA2 Ultra DMA mode 2 selected with a maximum data transfer rate of 33.3MBps Ultra DMA mode 3 selected with a maximum data transfer UDMA3...

  • Page 91: Floppy Configuration

    ROCKY-6614 CPU Card 32Bit Data Transfer [Enabled] The 32Bit Data Transfer BIOS option allows you to enable or disable 32-bit data transfers. Disabled Prevents the BIOS from using 32-bit data transfers. Enabled (Default) Allows BIOS to use 32-bit data transfers on support hard disk drives.

  • Page 92: Super Io Configuration

    CKY-6614 WSB- Card BIOS Menu 6: Floppy Configuration [Advanced] 5.3.4 Super IO Configuration The Super IO Configuration menu (BIOS Menu 7) allows you to set or change the configurations for the FDD controllers, parallel ports and serial ports. ® Technology, Corp. 1-92...

  • Page 93: On Board Floppy Controller [Enabled]

    ROCKY-6614 CPU Card BIOS Menu 7: Super IO Configuration [Advanced] On Board Floppy Controller [Enabled] Allows BIOS to disable the floppy controller Disabled Enabled (Default) Allows BIOS to enable the floppy controller Floppy Drive Swap [Disabled] Disabled (Default) Cannot designate A or B to a floppy drive without...

  • Page 94: Serial Port1 Address [3F8/Irq4]

    CKY-6614 WSB- Card Serial Port1 Address [3F8/IRQ4] The Serial Port1 Address option allows BIOS to select the Serial Port 1 base address. Disabled No base address is assigned to Serial Port 1 3F8/IRQ4 (Default) Serial Port 1 I/O port address is 3F8 and the interrupt address is IRQ4 Serial Port 1 I/O port address is 3E8 and the interrupt 3E8/IRQ4...

  • Page 95: Serial Port2 Mode [Normal]

    ROCKY-6614 CPU Card 2E8/IRQ3 Serial Port 1 base address is 2F8/IRQ3 Serial Port2 Mode [Normal] Allows BIOS to select the mode for Serial Port 2 Normal (Default) Serial Port 1 mode is normal IrDA Serial Port 1 mode is IrDA...

  • Page 96: Hardware Health Configuration

    CKY-6614 WSB- Card bi-directional communication between the system and the parallel port device and the transmission rates between the two are much faster than the Normal mode. ECP+EPP The parallel port will operate in the extended capabilities port (ECP) mode. The ECP mode supports bi-directional communication between the system and the parallel port device and the transmission rates between the two are much faster...

  • Page 97: H/W Health Function [Enabled]

    ROCKY-6614 CPU Card BIOS Menu 8: Hardware Health Configuration [Advanced] H/W Health Function [Enabled] Disabled Disables the health monitoring function Enabled (Default) Enables the health monitoring function If the H/W Health Function is enabled different system parameters and values are shown.

  • Page 98: Acpi Configuration

    CKY-6614 WSB- Card Voltages: The following system voltages are monitored Vcore +3.30Vin +5.00Vin +12Vin –12Vin –5Vin 5.3.6 ACPI Configuration The ACPI Configuration menu (BIOS Menu 9) allows you to configure the Advanced Configuration and Power Interface (ACPI) and Power Management (APM) options. BIOS Menu 9: ACPI Configuration [Advanced] ®...

  • Page 99: General Acpi Configuration

    ROCKY-6614 CPU Card ACPI Aware O/S [Yes] ACPI Aware O/S can only be configured if your OS complies with the ACPI standard. Windows 98, Windows 2000, and Windows XP all comply with ACPI. Disables the ACPI support for the OS. This selection should be...

  • Page 100: Advanced Acpi Configuration

    CKY-6614 WSB- Card Suspend Mode [S1(POS)] The Suspend Mode BIOS option allows you to specify the sleep state your system will enter when it is not being used. S1 (POS) (Default) System appears off. The CPU is stopped; RAM is refreshed;...

  • Page 101: Acpi 2.0 Features

    ROCKY-6614 CPU Card BIOS Menu 11: General ACPI Configuration [Advanced\ ACPI Configuration] ACPI 2.0 Features The ACPI 2.0 Features BIOS option allows you to enable the ACPI (Advanced Configuration and Power Interface) features. By enabling this feature the system RSDP (Root System Description Pointer) will be able to obtain physical addresses for other 64-bit fixed system description tables.

  • Page 102: Ami Oemb Table [Enabled]

    CKY-6614 WSB- Card The ACPI APIC Support BIOS option allows you to you to add a pointer to an ACPI APIC table in the RSDT (Root System Description Table). The RSDT is an array of pointers that direct the system to the physical addresses of other description tables. The RSDT is the main ACPI table.

  • Page 103: Mps Configuration

    ROCKY-6614 CPU Card 5.3.7 MPS Configuration The MPS Configuration menu (BIOS Menu 12) allows you to configure the multi-processor table. BIOS Menu 12: MPS Configuration [Advanced] MPS Revision [1.1] The Multiprocessor Specification (MPS) for OS specifies the MPS version to be used.

  • Page 104: Remote Access Configuration

    CKY-6614 WSB- Card BIOS Menu 13: Remote Access Configuration [Advanced] Smbios Smi Support [Enabled] The Smbios Smi Support allows you to specify support for the SMBIOS SMI wrapper for the PnP function 50h – 54h. Enabled (Default) SMBIOS SMI wrapper for the PnP function 50h – 54h supported Disabled SMBIOS SMI wrapper for the PnP function 50h –...

  • Page 105: Remote Access [Disabled]

    ROCKY-6614 CPU Card and allows a remote host running a terminal program to display and configure the BIOS settings. BIOS Menu 14: Remote Access Configuration [Advanced] Remote Access [Disabled] (Default) If selected, no configuration options will appear. Disabled Enabled If selected the remote access configuration options...

  • Page 106: Redirection After Bios Post

    CKY-6614 WSB- Card Redirection after BIOS POST Terminal Type VT-UTF8 Combo Key Support These configuration options are discussed below. Serial Port Number [COM1] The Serial Port Number BIOS option allows you to select which serial port will be used for the remote access.

  • Page 107: Usb Configuration

    ROCKY-6614 CPU Card Flow Control [None] The Flow Control BIOS option reports the flow control method for the console redirection application. None (Default) No control flow, Hardware Hardware is set as the console redirection Software is set as the console redirection...

  • Page 108: Onboard Sis Usb1.1 Device [Enabled]

    CKY-6614 WSB- Card The USB Configuration menu (BIOS Menu 15) gives you information on the USB configuration and allows you to configure some USB features. BIOS Menu 15: USB Configuration [Advanced] Onboard SiS USB1.1 DEVICE [Enabled] The Onboard SiS USB1.1 DEVICE BIOS option allows you to enable or disable the onboard SiS USB1.1 controller.

  • Page 109: Usb Configuration

    ROCKY-6614 CPU Card The Onboard SiS USB2.0 DEVICE BIOS option allows you to enable or disable the onboard SiS USB2.0 controller. If disabled, you will not be able to use USB2.0 devices on the system. Disabled USB 2.0 interface is disabled and cannot be used.

  • Page 110: Pci/Pnp

    CKY-6614 WSB- Card HiSpeed (Default) The controller is capable of operating at high speed (480Mbits/second) PCI/PnP The PCI/PnP menu (BIOS Menu 15) allows you to configure advanced PCI and PnP settings. WARNING! Setting wrong values for the BIOS selections in the PCIPnP BIOS menu may cause your system to malfunction.

  • Page 111: Menu 16: Pci/Pnp Configuration [Part 1]

    ROCKY-6614 CPU Card BIOS Menu 16: PCI/PnP Configuration [Part 1] 1-11...

  • Page 112: Clear Nvram [No]

    CKY-6614 WSB- Card BIOS Menu 17: PCI/PnP Configuration [Part 2] Clear NVRAM [No] The Clear NVRAM option allows you to specify whether the contents of the NVRAM (Non-Volatile RAM) when the power is turned off. (Default) System does not clear NVRAM during system boot System clears NVRAM during system boot Plug &...

  • Page 113: Pci Latency Timer [64]

    ROCKY-6614 CPU Card specifications, this option allows the BIOS to configure all the devices in the system. This setting allows the operating system to change the interrupt, I/O, and DMA settings. Set this option if the system is running Plug and Play aware operating systems.

  • Page 114: Pci Ide Busmaster [Disabled]

    CKY-6614 WSB- Card snooping to be enabled, this option should be disabled. PCI devices are informed that an ISA based Graphics device is installed in the system so the ISA based Graphics card will function correctly. This does not necessarily indicate a physical ISA adapter card. The graphics chipset can be mounted on a PCI card.

  • Page 115: Irq# [Available]

    ROCKY-6614 CPU Card PCI Slot 3 PCI Slot 3 is selected as the location of the OffBoard PCI IDE adapter card. Only select this slot if the adapter card is installed in PCI Slot 3. PCI Slot 4 PCI Slot 4 is selected as the location of the OffBoard PCI IDE adapter card.

  • Page 116: Boot

    CKY-6614 WSB- Card DMA Channel# [Available] (Default) The specified DMA is available to be used by Available PCI/PnP devices Reserved The specified DMA is reserved for use by Legacy ISA devices Available DMA Channels are: DM Channel 0 DM Channel 1 DM Channel 3 DM Channel 5 DM Channel 6...

  • Page 117: Boot Settings Configuration

    ROCKY-6614 CPU Card BIOS Menu 18: Boot 5.5.1 Boot Settings Configuration The Boot Settings Configuration menu (BIOS Menu 18) allows you to configure advanced system boot options. 1-11...

  • Page 118: Quick Boot [Enabled]

    CKY-6614 WSB- Card BIOS Menu 19: Boot Settings Configuration [Boot] Quick Boot [Enabled] The Quick Boot BIOS option allows you to make the computer speed up the boot process. Disabled System will not skip any POST procedures Enabled (Default) Allows system to skip some POST procedures to decrease the system boot time Quiet Boot [Disabled] The Quiet Boot BIOS option allows the boot up screen options to be modified between...

  • Page 119: Addon Rom Display Mode [Force Bios]

    ROCKY-6614 CPU Card Enabled Displays OEM Logo instead of POST messages AddOn ROM Display Mode [Force BIOS] The AddOn ROM Display Mode option allows add-on ROM (read-only memory) messages to be displayed. Force BIOS (Default) Allows the computer system to force a third party BIOS to display during system boot.

  • Page 120: Wait For 'F1' If Error [Enabled]

    CKY-6614 WSB- Card mouse port from using system resources. Enabled (Default) Allows the system to use a PS/2 mouse. Wait For ‘F1’ If Error [Enabled] The Wait For ‘F1’ if Error option allows you to specify how the system will respond when the system detects an error on boot up.

  • Page 121: Boot Device Priority

    ROCKY-6614 CPU Card Disabled (Default) Does not allow optional ROM to trap interrupt 19 Enabled Allows optional ROM to trap interrupt 19 5.5.2 Boot Device Priority The Boot Device Priority menu (BIOS Menu 20) specifies the boot sequence from the available devices.

  • Page 122: Hard Disk Drives

    CKY-6614 WSB- Card 5.5.3 Hard Disk Drives The Hard Disk Drives menu is similar to the Removable Drives BIOS Menu 21 and it specifies the boot sequence of the available HDDs. When the menu is opened, the HDDs connected to the system are listed as shown below: 1st Drive [HDD: PM-(part number)] 2nd Drive...
  • Page 123 ROCKY-6614 CPU Card NOTE: Only the drives connected to the system will be shown. For example, if only one FDD is connected only “1st Drive” will be listed. You will then be able to select the boot sequence from the available devices. If you select the “1st Drive”...

  • Page 124: Cd/Dvd Drives

    CKY-6614 WSB- Card 5.5.5 CD/DVD Drives The CD/DVD Drives menu is similar to the Removable Drives BIOS Menu 21 and it specifies the boot sequence of the available CD/DVD drives. When the menu is opened, the CD drives and DVD drives connected to the system are listed as shown below: 1st Drive [CD/DVD: PM-(part ID)] 2nd Drive...

  • Page 125: Change Supervisor Password

    ROCKY-6614 CPU Card BIOS Menu 22: Security Change Supervisor Password The default setting for the Change Supervisor Password is Not Installed. If you wish to install a supervisor password, select this field and enter the password. After the password has been added, Install will appear next to Change Supervisor Password.

  • Page 126: Chipset

    CKY-6614 WSB- Card Enabled Enables the boot sector virus protection Chipset The Chipset menu (BIOS Menu 23) has two sub-menus, NorthBridge SIS661FX Configuration and SouthBridge SiS964 Configuration. The NorthBridge SIS661FX Configuration menu allows you to configure the northbridge chipset and the SouthBridge SiS964 Configuration menu allows you to configure the southbridge chipset.

  • Page 127: Northbridge Sis661Fx Configuration

    ROCKY-6614 CPU Card BIOS Menu 23: Chipset 5.7.1 NorthBridge SIS661FX Configuration The NorthBridge SIS661FX Configuration menu (BIOS Menu 23) allows you to configure the northbridge chipset. 1-12...

  • Page 128: Primary Graphics Adapter [Pci]

    CKY-6614 WSB- Card BIOS Menu 24:NorthBridge Chipset Configuration [Chipset] Primary Graphics Adapter [PCI] The Primary Graphics Adapter option allows you to select the graphics adapter your system will use. (Default) PCI graphics adapter is used AGP graphics adapter is used MA 1T/2T Select The MA 1T/2T Select BIOS option allows you to set the lead-off time control for the DRAM read, write, and background commands.

  • Page 129: Dram Cas# Latency [By Spd]

    ROCKY-6614 CPU Card N/B Reg AAh Bit [1:0] The N/B Reg AAh Bit [1:0] BIOS option allows you to set the Pentium 4 CPU input strobe delay control. N/B Reg AAh Bit [3:2] The N/B Reg AAh Bit [3:2] BIOS option allows you to set the Pentium 4 CPU input data delay control.

  • Page 130: Southbridge Sis964 Configuration

    CKY-6614 WSB- Card Share Memory Size [32MB] The Share Memory Size BIOS feature allows you to allocate the maximum amount of system memory to the integrated graphics processor. The options are: 16MB 32MB (Default) 64MB 128MB Disabled 5.7.2 SouthBridge SiS964 Configuration The SouthBridge SiS964 Configuration menu (BIOS Menu 25) allows you to configure the southbridge chipset.

  • Page 131: Power Key

    ROCKY-6614 CPU Card OnBoard AC97 Audio DEVICE [Enabled] The OnBoard AC97 Audio DEVICE option allows you to enable or disable the AC’97 CODEC. Enabled (Default) The onboard AC’97 automatically detected and enabled Disabled Onboard AC’97 manually disabled MAC Address [780000007800] The MAC Address option allows you to type in the hexadecimal MAC (media access control) address.

  • Page 132: Power Management/Apm [Enabled]

    CKY-6614 WSB- Card BIOS Menu 26:Power Power Management/APM [Enabled] The Power Management/APM BIOS option allows you to access the advanced power management features. If this option is disabled, the only other option on the screen will be the “Resume On RTC Alarm.” Disables the Advanced Power Management (APM) Disabled feature...

  • Page 133: Suspend Time Out [Disabled]

    ROCKY-6614 CPU Card In this sleep state all the system clocks, with the exception of the RTC are stopped. Upon any wake-up event, the system hardware must restart all the system clocks. (Default) The CPU powers down into a lower power state and the processor is able to maintain the context of the system caches.

  • Page 134: Video Power Down Mode [Disabled]

    CKY-6614 WSB- Card Video Power Down Mode [Disabled] The Video Power Down Mode BIOS option allows you to specify in what system mode the video device can be turned off. Disabled (Default) The Video cannot be turned off in the Suspend or Standby mode Standby The video can be turned off in the Standby mode...

  • Page 135: Restore On Ac Power Loss [Last State]

    ROCKY-6614 CPU Card Enabled Restore on AC Power Loss [Last State] The Restore on AC Power Loss BIOS option allows you to specify what state the system will return into if there is a sudden loss of power to the system.

  • Page 136: Ps2 Mouse Resume Function [Disabled]

    CKY-6614 WSB- Card PS2 MOUSE Resume Function [Disabled] The PS2 MOUSE Resume Function BIOS option allows you to specify if the system will be roused from a suspended or standby state when there is activity on the PS/2 mouse. Disabled (Default) Wake event not generated by PS/2 mouse activity Enabled...

  • Page 137: Exit

    ROCKY-6614 CPU Card Resume On RTC Alarm [Disabled] The Resume On RTC Alarm allows you to determine when the computer will be roused from a suspended state. Disabled (Default) The real time clock (RTC) cannot generate a wake event Enabled...

  • Page 138: Save Changes And Exit

    CKY-6614 WSB- Card BIOS Menu 27:Exit Save Changes and Exit If you have finished making the configuration changes and wish to save them and exit the BIOS menus, select this option. Discard Changes and Exit If you have finished making configuration changes but do not want to save them and you want to exit the BIOS menus, select this option.

  • Page 139: Load Optimal Defaults

    ROCKY-6614 CPU Card Load Optimal Defaults This option allows you to load optimal default values for each of the parameters on the Setup menus. F9 key can be used for this operation. Load Failsafe Defaults This option allows you to load failsafe default values for each of the parameters on the Setup menus.

  • Page 140: Software Drivers

    CKY-6614 WSB- Card Chapter Software Drivers 1-14 ® Technology, Corp.

  • Page 141: Available Software Drivers

    AGP Driver Installation To install the AGP driver, please follow the steps below: Insert the CD into the system that contains the ROCKY-6614 CPU card. Open Step 1: the AGP 121 directory and locate the icon for the Setup installation file. Once located, use the mouse to move the cursor over the icon and double click the mouse button.

  • Page 142: Figure 6-1: Startinginstallshield Wizard Screen

    CKY-6614 WSB- Card Figure 6-1: StartingInstallShield Wizard Screen The “Preparing Setup” window in Figure 6-2 appears next. Step 3: Figure 6-2: Preparing Setup Screen The “Install Shield” window in Figure 6-3 appears next. If you wish to continue Step 4: installing the AGP pack driver, click “N .”...

  • Page 143: Figure 6-3: Install Shield Screen

    ROCKY-6614 CPU Card Figure 6-3: Install Shield Screen The installation shield will then start to extract and install files as shown in Step 5: Figure 6-4. 1-14...

  • Page 144: Figure 6-4: Installing Screen

    CKY-6614 WSB- Card Figure 6-4: Installing Screen Once the installation process is complete, you will be asked if you wish to restart Step 6: your computer or if you want to restart your computer (see Figure 6-19). Select the option you prefer and click “F ”...

  • Page 145: Realtek Audio Driver Installation

    RealTek Audio Driver Installation To install the RealTek AC’97 Audio driver, please follow the steps below: Insert the CD into the system that contains the ROCKY-6614 CPU card. Open Step 1: the CD folder and locate the AUDIO DRIVER A3.79 directory. Open the directory and look for icon for the setup.exe installation file.

  • Page 146: Figure 6-6: Audio Driver Install Shield Wizard Starting

    CKY-6614 WSB- Card Figure 6-6: Audio Driver Install Shield Wizard Starting The RealTek Audio Setup prepares the install shield to guide you through the Step 3: rest of the setup process. See Figure 6-7. Figure 6-7: Audio Driver Setup Prerparation After install shield is prepared, the welcome screen shown in Figure 6-8 Step 4: appears.

  • Page 147: Figure 6-8: Audio Driver Welcome Screen

    ROCKY-6614 CPU Card Figure 6-8: Audio Driver Welcome Screen Figure 6-9: Audio Driver Software Configuration At this stage the “Digital Signal Not Found” screen shown in Figure 6-10 Step 5: 1-14...

  • Page 148: Figure 6-10: Audio Driver Digital Signal

    CKY-6614 WSB- Card appears. To continue the installation process, click the “Y ” button. The installation notice shown below will appear. Figure 6-10: Audio Driver Digital Signal At this stage the clicking the “Y ” button in Figure 6-10 appears, the installation Step 6: of the driver begins.

  • Page 149: Figure 6-11: Audio Driver Installation Begins

    ROCKY-6614 CPU Card Figure 6-11: Audio Driver Installation Begins After the driver installation process is complete, a confirmation screen shown in Step 7: Figure 6-12 appears 1-14...

  • Page 150: Sis Vga Utilities Driver

    To install the SiS VGA Utilities driver in the Chipset_VGA 3.72logo directory please follow the steps below: Insert the CD into the system that contains the ROCKY-6614 CPU card. Open Step 1: the Chipset_VGA 3.72logo directory and locate the icon for the setup installation file.

  • Page 151: Figure 6-13: Vga Utilities Welcome Screen

    ROCKY-6614 CPU Card Figure 6-13: VGA Utilities Welcome Screen You then select the setup type (see Figure 6-14). Once the setup type is Step 3: selected, click on the N button in the setup type menu (see Figure 6-14). 1-15...

  • Page 152: Figure 6-13: Select Setup Installation Type

    CKY-6614 WSB- Card Figure 6-14: Select Setup Installation Type You are then prompted to select a folder to copy the files in (see Figure 6-15). Step 4: Once the setup type is selected, click on the N button. 1-15 ® Technology, Corp.

  • Page 153: Figure 6-13: Select Folders To Copy Files

    ROCKY-6614 CPU Card Figure 6-15: Select Folders to Copy Files Before the files are copied, you can review you selected settings (see Figure Step 5: 6-16). Once you have completed reviewing your settings, click on the N button. Figure 6-16: Review Settings...

  • Page 154: Figure 6-13: Read Readme File

    CKY-6614 WSB- Card The driver installation will then start. Step 6: Once the installation is complete, you will be prompted to read the Read Me file. Step 7: (see Figure 6-17) Figure 6-17: Read ReadMe File Once you have completed reading the Read Me file or it you skip reading the Step 8: Read Me file, you will be prompted to restart your computer.

  • Page 155: Sis Ide Driver Installation

    SiS IDE Driver Installation To install the SiS IDE driver in the IDE R204a directory please follow the steps below: Insert the CD into the system that contains the ROCKY-6614 CPU card. Open Step 9: the IDE R204a and locate the icon for the setup installation file. Once located, use the mouse to move the cursor over the icon and double click the mouse button.

  • Page 156: Figure 6-13: Select A Language

    CKY-6614 WSB- Card Figure 6-19: Select a Language After you select a language a welcome screen shown in Figure 6-20 appears. Step 11: To continue the installation, click the “N ” button. Figure 6-20: Welcome Screen You are then prompted to select an OS as shown in Figure 6-21. Step 12: 1-15 ®...

  • Page 157: Figure 6-15: Chipset Driver Readme File Information

    ROCKY-6614 CPU Card Figure 6-21: Chipset Driver Readme File Information Select an OS and click on the “N ” button to initiate driver installation. The Step 13: installation screen shown in Figure 6-22 appears. 1-15...

  • Page 158: Lan Driver Installation

    Step 0: LAN Driver Installation To install the LAN driver, please follow the steps below: Insert the CD into the system that contains the ROCKY-6614 driver. Open the Step 1: lan\RTL81698169S(B)8110S(B)\LanSetup_v1.80.635.051018 directory and locate the icon for the Setup installation file. Once located, use the mouse to move the cursor over the icon and double click the mouse button.

  • Page 159: Figure 6-17: Lan Driver Welcome Screen

    ROCKY-6614 CPU Card Figure 6-23: LAN Driver Welcome Screen To continue installing click “Next.” The driver will be installed and a confirmation Step 3: screen at the end of the installation will appear. (See Figure 6-24) Step 0: 1-15...

  • Page 160: Figure 6-18: Lan Driver Installation Complete

    CKY-6614 WSB- Card Figure 6-24: LAN Driver Installation Complete 1-16 ® Technology, Corp.
  • Page 161 ROCKY-6614 CPU Card THIS PAGE IS INTENTIONALLY LEFT BLANK 1-16...

  • Page 162: Abios Configuration Options

    CKY-6614 WSB- Card Appendix BIOS Configuration Options 1-16 ® Technology, Corp.
