PC/104 SBC with AMD Geode™ LX800 CPU, VGA/TTL,
LAN, USB 2.0 and CF II
PM-LX2
Quick Installation Guide
Version 1.0
Mar. 30, 2009
Package List
PM-LX2 package includes the following items:
1 x PM-LX2 Single Board Computer
1 x IDE 44P/44P flat cable
1 x Dual Ports USB cable
1 x LAN cable
2 x RS-232 cable
1 x PS/2 KB/MS cable
1 x VGA cable
1 x Power cable
1 x Mini Jumper Pack
1 x Utility CD
1 x QIG (Quick Installation Guide)
©2006 Copyright by IEI Technology corp.
All rights reserved.
1
Advertisement
Table of Contents
Related Manuals for IEI Technology PM-LX2
Summary of Contents for IEI Technology PM-LX2
-
Page 1: Quick Installation Guide
PM-LX2 Quick Installation Guide Version 1.0 Mar. 30, 2009 Package List PM-LX2 package includes the following items: 1 x PM-LX2 Single Board Computer 1 x IDE 44P/44P flat cable 1 x Dual Ports USB cable 1 x LAN cable 2 x RS-232 cable... -
Page 2: Specifications
PC/104 slot (ISA Bus, by PCI to ISA Bridge ITE IT8888G) SSD: CF Type II Super I/O: PM-LX2-800-R10: SMSC SCH3114-NU PM-LX2-800W-R10: SMSC SCH3114I-NU (Wide Temperature) Display: CRT integrated in AMD Geode™ LX800 24-bit TTL integrated in AMD Geode™ LX800 WDT: Software programmable 1-255 sec. by super I/O SMSC... -
Page 3: Ordering Information
PM-LX2-800W-R10: -40~70°C Humidity: Operation:5%~95% non-condensing Dimension: 95mm x 95mm Weight: GW: 500g; NW: 110g Ordering Information PM-LX2-800-R10: PC/104 SBC with AMD Geode™ LX800 500MHz CPU, VGA/TTL, LAN, USB2.0 and CF II PM-LX2-800W-R10: PC/104 SBC with AMD Geode™ LX800 500MHz CPU, VGA/TTL, LAN, USB2.0 and CF II, Wide Temperature -40~+70°C... - Page 4 Table of Connectors LABEL FUNCTION LCD Inverter Connector Reset, LED Indicators connector LAN Box-header Connector VGA1 VGA 10-pin Box-header Connector COM1, 2 RS-232 Serial Port Box-header Connectors RS-422/485 Serial Port Wafer-header Connector KBMS2 6-pin Keyboard/Mouse Connector +3.3V Battery Connector IDE 44pin 2.0mm connector LPT1 Parallel port Box-header connector TFT LCD connector (TTL)
- Page 5 VGA1: VGA 10-pin Box-header Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION DDCCLK GREEN DDCDAT BLUE HSYNC VSYNC COM1, 2: RS-232 Serial Port Box-header Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION DCD# DSR# RTS# CTS# DTR# CN7: RS-422/485 Serial Port COM3 Wafer-header Connector PIN NO.
- Page 6 CN2: IDE 44pin 2.0mm connector Pin No. Description Pin No. Description RESET# IOW# IOR# ACK# CABLEID CS0# CS1# ASP# LPT1: Parallel port Box-header connector Pin No. Description Pin No. Description STB# AFD# ERR# INIT# SLIN# ACK# BUSY SLCT...
- Page 7 CN5: TFT LCD connector (TTL) Pin No. Description Pin No. Description LCD_VCC LCD_VCC LCD_VCC LCD_VCC VSYNC HSYNC LCD_EN DISP_EN CN3: +12V & +5V Main Power Input Connector PIN NO DESCRIPTION +12V CN4: -12V & -5V Power Input Connector PIN NO DESCRIPTION -12V USB1: 2 ports internal USB Connector...
- Page 8 CN8: PC/104 Connector(ISA Bus) Pin Description Pin Description Pin Description Pin Description IOCHCK# RESET SBHE# MEMCS16# VCC5 LA23 IOCS16# IRQ9 LA22 IRQ10 LA21 IRQ11 DRQ2 LA20 IRQ12 -12V SA19 IRQ15 OWS# SA18 IRQ14 +12V SA17 DACK0# IOCHRDY MEMR# DRQ0# SMEMW# MEMW# DACK5# SA19...
- Page 9 CN9 : CF Card Interface Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION CD1# CE2# IOR# IOW# CSEL# RESET# WAIT# INPACK# REG# BVD2 BVD1 CD2#...
- Page 10 CN10: FDD FPC connector Pin No. Description INDEX# DSA# DSKCHG# MOTO0# DIR# STEP# WDATA# WGATE# TRACK0# RDATA# HEAD#...
-
Page 11: Board Layout: Jumper And Connector Locations
Board Layout: Jumper and Connector Locations...
