2 Framework

2.1 Cable

You can refer to the following figure for
Please refer to the following sheet for detailed information.
No. Port Function
Name
1
LAN Network port
2
Power
DC 12V
port

2.2 Framework and Dimension

Please refer to the following figure for dimension information. The unit is mm. See Figure 2-2 and
Figure 2-3.
cable information. See Figure 2-1
Figure 2-1 Cable
Connection Note
Connect to standard Ethernet cable.
Ethernet Note:
port
Before making crystal head, pull the anti-dust cover
through network cable.
Power port. Input DC 12V.
input
/
.
