1.4 Hardware Overview

2
6
7
PHYLINK Bullet HD User Manual
1. Sun Shield
2. External Antenna
3. Front Shell
4. Microphone
5. Stand
6. Reset/WPS Button
7. Camera Cable
8. Status indicator LED
9. Infrared LED
10. Light Sensor
11. Power Jack
12. Ethernet RJ45 connector
13
13. Micro SD Card slot
5
14. Wrench
14
8
9
10
11
12
8
