Bang & Olufsen BEOLINK Handbook page 11

Contents
1.5m
Use
Type number
Miscellaneous
MASTER LINK
BeoLink Passive
BeoLink Passive consists of a control box, an IR receiver, a cable to the IR
receiver and a mains cable.
Please note the following for installation: the amplifier block is designed to
function within a temperature range of 10-40º C. At temperatures outside
this range it can block the whole Master Link system if connected to one.
5m
BeoLink Passive is used in link rooms together with passive loudspeakers.
All Bang & Olufsen passive loudspeakers can be connected.
BeoLink Passive has built-in sound control, which means that sound and
volume can be adjusted independently of the main room.
Using the volume adjustment it is possible to adjust balance, bass, treble and
volume individually.
BeoLink Passive enables you to listen to the sound from all the main room's
products – both video and audio sources.
BeoLink Passive has the following local control options:
- Timer on/off
- PLAY / ST.BY
- Volume up/down:
1165566 (AUS)
1165666 (EU)
1165766 (GB)
1165866 (USA/CDN)
1165966 (KOR)
1166766 (CHN/HK)
In addition to the accessories supplied with BeoLink Passive, the installation
also requires a Master Link cable and plugs, sockets and junction boxes (see
section on installation types, page 23).
7
