Summary of Contents for Minuteman X17 ECO

  • Page 1 User Manual X17 ECO Carpet Extractor...
  • Page 2 This manual is furnished with each new Minuteman X17. This provides the necessary operating and preventive maintenance instructions. Operators must read and understand this manual before operating or servicing this machine. This machine was designed to give you excellent performance and efficiency. For best results and minimal cost, please follow the general guidelines below: ·...
  • Page 3: Technical Specifications

    Technical Specifications Model X17 ECO Model No. X17115 / X17115HP X17230 / X17230HP Current Max. 12 Amps 7 Amps Voltage 115V 230V Vacuum motor power 1250W 1250W Brush motor power 100W 100W Pump motor power 50PSI / 100PSI 50PSI / 100PSI Working width 17”...
  • Page 4: Ce Declaration

    CE Declaration...
  • Page 5: Table Of Contents

    Brush Removal ......................................18 Brush Pressure Gauge ................................... 19 Removable Recovery Tank ..................................20 Cord Relief ....................................... 21 Handle Adjustment ....................................21 Accessories ......................................22 Maintenance ................................... 23 Operating Instructions ................................26 Troubleshooting ..................................28 Minuteman International Made Simple Commercial Limited Warranty................30...
  • Page 6: Safety Instructions

    Safety Instructions FOR COMMERCIAL USE ONLY IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING WARNING - To reduce the risk of fire, electric shock, or injury: •...
  • Page 7 Consignes de sécurité POUR USAGE COMMERCIAL SEULEMENT MODE D’EMPLOI SECURITAIRE Lorsque l’on utilise un appareil électrique, des précautions de base doivent toujours être suivies telles que: BIEN LIRE LE MODES D’EMPLOI AVANT USAGE AVERTISSEMENT - Pour réduire les risques de feu, choc électrique ou blessure: •...
  • Page 8: Unpacking Instructions

    Unpacking Instructions INSPECTION DANGER Carefully unpack and inspect your machine for shipping damage. Improper connection of the equipment-grounding conductor can result in a risk Each unit is tested and thoroughly inspected before shipment, and of electric shock. Check with a qualified electrician or service person if you are any damage is the responsibility of the delivery carrier who should in doubt as to whether the outlet is properly grounded.
  • Page 9 Instructions de déballage INSPECTION DANGER Déballez et inspectez soigneusement votre machine en cas de Une mauvaise connexion du conducteur de terre peut entraîner un risque de dommages d’expédition. Chaque unité est testée et soigneusement choc électrique. Consultez un électricien qualifié ou une personne de service inspecté...
  • Page 10: Assembly

    Assembly Insert handle assembly in Use philips screwdriver to Align the teeth on the Unpack machine. between bushings. Insert unscrew 4 screws and bushing and handle assem- the shoulder bolt through the remove cover. bly before tightening the bushing and screw into the adjustment knob.
  • Page 11: Handle Assembly

    Assembly HANDLE ASSEMBLY The X17 Handle Assembly (D) is not assembled on the machine when shipped. Follow the instruction on page 10 to connect the handle assembly to the machine. A HANDLE ADJUSTMENT KNOB B SHOULDER BOLT C COVER D HANDLE ASSEMBLY E SCREW F CORD RELIEF...
  • Page 12: Machine Overview

    Machine Overview X17 Front A HANDLE B RECOVERY DOME LID C RECOVERY TANK D SOLUTION TANK E SOLUTION TANK FILL PORT F FAUCET FILL HOSE G RECOVERY WINDOW H BRUSH MOTOR BELT COVER VAC SHOE Vacuum Connection K VACUUM MOTOR INTAKE COVER L VACUUM CONNECTION TUBE M RECOVERY INLET N HANDLE...
  • Page 13: X17 Back & Bottom

    X17 Back & Bottom (X17115) TWIST LOCK POWER CONNECTOR (SHOWN) (X17230) POWER CONNECTOR HANDLE ADJUSTMENT KNOB AUXILIARY POWER OUTLET (FOR MINUTEMAN MOTORIZED TOOL ONLY) RECOVERY TANK DUMP HOSE BRUSH PRESSURE ADJUSTMENT KNOB OFF AISLE WAND WATER FEMALE QUICK-CONNECT VACUUM HOSE CONNECTION POINT...
  • Page 14: Machine Overview

    Machine Overview Handle/ Control Panel A MOMENTARY SPRAY SHUT-OFF B BRUSH SWITCH C VACUUM SWITCH D SPRAY JET \ AUXILIARY SWITCH Circuit Breakers The circuit breakers are located on bottom and rear of the handle assembly. 1 BRUSH MOTOR BREAKER - (X17115) 1.5amp (X17230) 1.0amp 2 VACUUM PUMP BREAKER - (X17115) 12amp (X17230) 7amp...
  • Page 15: Momentary Handle

    Machine Overview Momentary Handle (A) When handle is pushed forward the spray jets shut off. Brush Switch (B) ON\OFF switch for brush. Flip switch up to (I) position to turn on the brush motor. Flip switch to (o) position to shut off brush motor. Vacuum Switch (C) ON\OFF switch for vacuum.
  • Page 16: Solution Tank In-Line Filter

    Machine Overview Solution Tank In-line Filter The In-line Filter (B) should be cleaned regularly. To clean: 1. Close the Shut-off Valve (C) by turning the handle 90 clockwise. 2. Next, twist the Filter Cap (A) counterclockwise. 3. Pull the filter out to clean filter and cap. 4.
  • Page 17: Solution Tank Drain Hose

    Machine Overview Solution Tank Drain Hose The solution tank may be drained by removing the Solution Tank Drain Hose (A) from the Hose Barb (B) and routing the hose to a floor drain. Solution Level Indicator The solution Tank Drain Hose also serves as a water level indicator for the solution tank.
  • Page 18: Brush Removal

    Machine Overview Brush Removal • Use a 4mm or 5/32 Hex Tool to remove the flat- head screw on the underside of the right side of the brush housing. • Pry open the brush housing door. • Pull brush straight out to the side. To re-install: •...
  • Page 19: Brush Pressure Gauge

    Machine Overview Brush Pressure Gauge The brush pressure gauge informs the operator if the brush pressure setting is in optimum range. The machine operates best in the green area. If the machine reaches the yellow or red range the brush pressure can be lowered by raising the brush by turning the brush pressure adjustment knob counter-clockwise.
  • Page 20: Removable Recovery Tank

    Machine Overview Removable Recovery Tank To remove tank: 1. Unclip dump hose from solution tank. 2. Pull recovery tank straight up. To replace tank: 1. Feed dump hose through opening in solution tank 2. Lower tank into place. Recovery vacuum inlet will rest on vacuum connection tube (See page 12, items L &...
  • Page 21: Cord Relief

    Machine Overview Handle Adjustment ed with operator comfort in The X17 handle was design mind. The angle position of the handle can be adjusted to suit the needs of the operator. Angle Adjustment The handle can be adjusted without tools by loosening the Handle Adjustment Knob (A) and rotating the handle to the desired position.
  • Page 22: Accessories

    Machine Overview Accessories • (X17115) C46300-00 - Motorized Tool • (X17230) C46300-02 - Motorized Tool Only this tool may plug into the Auxiliary Power (B). • The vacuum hose as shown on Page 13 Item (G) must be first disconnected from the machine back panel. Connect the Suction Hose (D) tool to the Vacuum Inlet (A).
  • Page 23: Maintenance

    Maintenance USER MAINTENANCE INSTRUCTIONS All service and repairs should be performed by a qualified service representative or electrician. No user serviceable components are employed in the electrical assembly. No lubrication of the motor is required. BEFORE CLEANING OR MAINTAINING THE MACHINE, UNPLUG THE ELECTRICAL CORD. Protect equipment from freezing.
  • Page 24 Maintenance BI-MONTHLY/MONTHLY/YEARLY MAINTENANCE EVERY TWO WEEKS: 1. Purge solution system to remove residue build-up by flushing as follows: a. Use - 1 quart White Vinegar to two gallons clean hot water - in the solution tank, operate solution pump with spray jets installed for two full minutes.
  • Page 25: Cord Storage

    Maintenance 3. Flush out Recovery Window Extension Hose (page 12, item Q) while Recovery Window is removed by pouring water/vinegar solution through the hose. Rinse with clear water. 4. Clean off any debris from the Vac Connection Tube & Recovery Inlet (page 12, items L, M). 5.
  • Page 26: Operating Instructions

    This can reduce or stop solution flow to the pump and spray jets. Carpet should be thoroughly vacuumed and obstacles relocated before beginning the cleaning cycle. Heavy traffic lane areas should be pre-treated or spotted with Minuteman Pre-Treat order #902183 for best results.
  • Page 27 Operating Instructions CONTINUED... During the cleaning cycle, care should be taken not to allow foam to build up in the recovery tank. If this should happen, the machine should be turned off. Defoamer order #910543 should be added to the recovery tank only, never into the solution tank.
  • Page 28: Troubleshooting

    Troubleshooting Troubleshooting Guide Caution! Unplug power cord before servicing machine components. Problem Possible Cause Remedy Power cord may be disconnected at the Check connections and reconnect if Machine does not function twist lock or wall outlet. necessary. Wall outlet breaker may have tripped Reset breaker.
  • Page 29 Troubleshooting Circuit breaker in handle tripped. Reset breaker. Belt is damaged Replace belt Brush does not turn ON Debris is lodged in the brush housing Remove debris Switch is in OFF (O) position Flip switch to ON (I) position. Dome lid filter or vac float shut off may be Rinse out items clogged Recovery dome lid is not seated properly.
  • Page 30: Minuteman International Made Simple Commercial Limited Warranty

    Minuteman International, Inc. warrants to the original purchaser/user that the product is free from defects in workmanship and materials under normal use. Minuteman will, at its option, repair or replace without charge, parts that fail under normal use and service when operated and maintained in accordance with the applicable operation and instruction manuals.
  • Page 31 Cord Electric Group: Three years parts, two years labor, ninety days travel (Not to exceed two hours) Exceptions………. Model Parts Labor Poly Travel Port A Scrub 1 yr 6 months 10 yrs MPV 13 1 yr MPV 14 & 18 2 yrs 1 yr V Series Upright Vacuums...
