The warranty set forth above is inclusive and no other
warranty, whether written or oral, is expressed or
implied.

SPECIFICATIONS

Ranges
DC Voltage 300mV, 3V
30,300, 500V
AC Voltage 3, 30, 300, 500V
DC Current 30, 300mA
AC Current 30, 300mA
Resistance 300,3k,30k,300kΩ
3MΩ
30MΩ
Continuity Buzzer sounds for resistance less than 20 ohms (approximately)
Logic <1V Logic low, 1V to 2V Indeterminate, >2V Logic High, 3V reference, 220kΩ input impedance
Power supply Two 1.5V AAA batteries
Dimmensions/Wt. 1x7.5x1.9" (26x191x40mm) / 3.9oz (120gm)

SAFETY INSTRUCTIONS

Version 1.1
Resolution Accuracy
100µV +(1.5% reading + 5 digits)
+(1.0% reading + 2 digits
1mV +(1.5% reading + 8 digits)
10µA +(1.5% reading + 3 digits)
10µA +(2.0% reading + 5 digits)
0.1 ohms +(1.5% reading + 5 digits)
+(2.0% reading + 8 digits)
+(3.0% reading + 10 digits)
4 August, 2000
Input Impedance 10MΩ
Max Input 500V AC/DC
AC Freq. Response:
40Hz to 400Hz
Average responding
Overload Protection:
250VAC rms
Open ckt. V: 0.6V -
1.2V
