Tile Cutting Saw
600W
Instruction Manual
3 Year Replacement Warranty
OZTCS600WA
! !
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
0212
www.ozito.com.au
To view the full range visit:
Advertisement
Table of Contents
Related Manuals for Ozito OZTCS600WA
Summary of Contents for Ozito OZTCS600WA
- Page 1 600W Instruction Manual 3 Year Replacement Warranty OZTCS600WA WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
-
Page 2: Specifications
SPECIFICATIONS - MODEL NO. OZTCS600WA Motor: 600W (S1=500W S2-20min=600W) Input: 230V ~ 50Hz No load speed: 2950 /min Wheels: 180mm x 22.2mm Max. cutting depth: 33mm Mitre angle: 0 - 45º Table dimensions: 330mm x 360mm Protection Class: 1 (Earthed appliance) Weight: 9.5kg... -
Page 3: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS………………………………………… Page 2 KNOW YOUR PRODUCT……………………………….. Page 2 INTRODUCTION………………………………………... Page 4 SAFETY INSTRUCTIONS………………………………… Page 5 ADDITIONAL SAFETY RULES FOR CUTTING SAW… Page 7 OPERATION …………………………………………….. Page 7 MAINTENANCE …………….………………………….. Page 10 SPARE PARTS……………………………………………. Page 10 CONTENTS ……………………………………………... Page 11 WARRANTY………………………………………………... -
Page 4: Introduction
The tool is earthed in accordance with AS/NZS 60335:2002 Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealeand. Using an Extension Lead Always use an approved extension lead suitable for the power input of this tool. -
Page 5: Safety Instructions
GENERAL SAFETY RULES Warning! Read all instructions, Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “Power Tool” in all of the warnings listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 6 GENERAL SAFETY RULES (cont.) c) Avoid accidental starting. Ensure the switch is in the off position before plugging in. Carrying power tools with your finger on the switch or plugging in power tools that have the switch on invites accidents. d) Remove any adjusting key or wrench before turning the power tool on.
-
Page 7: Additional Safety Rules For Cutting Saw
ADDITIONAL SAFETY RULES FOR CUTTING SAW • Recommendation for the use of a residual current device with a rated residual current device of 30mA or less for extra protection against electric shock. • Make sure that the cutting blade is correctly screened by the guard. •... - Page 8 OPERATION (cont.) Mounting the guard (Fig. 1) Fig. 1 • Fit the riving knife (6) to the table (4) using the screws (9). • Place the guard over the riving knife (6). • Fit the guard (5) to the riving knife. Tighten the lock knob (10).
- Page 9 OPERATION (cont.) Adjusting the bevel angle (Fig. 4) Fig. 4 The bevel angle is infinitely variable between 0º and 45º. • Loosen the lock knob (19). • Set the desired bevel angle according to the scale (20). • Tighten the lock knob (19). Instructions for use •...
-
Page 10: Maintenance
Blow dust from the tile cutting saw through the rear ventilation slots with compressed air periodically to ensure a dust free tool. NOTE: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the circular saw by an unauthorised person or by mishandling of the tool. -
Page 11: Contents
Reuse of recycled material decreases pollution in the environment. Please recycle packaging where facilities exist. Check with your local council authority for recycling advice. CONTENTS 1 x Tile Cutting Saw OZTCS600WA 1 x Allen Key 1 x Cutting Blade (fitted) 1 x Shaft Wrench... -
Page 12: Warranty
If the tool shows signs of damage or defects caused by or resulting from abuse, accidents or alterations. Failure to perform maintenance as set out within the instruction manual. • • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175...
