WebWay IP/GPRS & WebWay GPRS/PSTN Installation Manual
PIN inputs
PINS 1-8 End of line or simple PINS, PINS 9-16 simple PINS
PINS – Tamper, Mains Fail, Battery Fail
BIAS voltage +/-
PIN Outputs
PIN outputs 1, 2 & 3
Reference voltages A+ Nominal 12 volts or 24 volts depending on application; A- 0 volts
Power
Inputs + PWR - adjacent to the Ethernet connector
WebWayOne Ltd, 11 Kingfisher Court, Newbury, Berkshire, RG14 5SJ
Tel 01635 231514: Email
support@webwayone.co.uk
Page 9
