Annex A - Configuration profiles

WebWay IP/GPRS and WebWay GPRS/PSTN have been tested and certificated to LPS1277 for enhanced ATS performance.
The Revised Table 10 shown below permits stakeholders to select enhanced option C ATS 5 and enhanced options ATS4Plus.
Alarm Transmission Systems for use with Grade 2, 3, and 4 I&HAS. When an option is selected the profile is automatically
downloaded to the WebWay when connected to the chosen Alarm Receiving Centre. The ARC or WebWayOne will only make
changes to a configuration on instruction in writing from the End User and the associated Alarm Company.
Configuration profiles for Intruder and Hold-Up Alarm Systems
WebWay IP/GPRS
The IP/GPRS has been tested and certificated by LPCB to LPS1277 for enhanced ATS performance criteria higher than currently
available in Table 11 (EN50131-1:2006+A1:2009)
The standard profile for IP/GPRS is Dual Path Enhanced ATS5 where the reporting time of the secondary path steps up to 3
minutes when the primary is failed and the system will detect a catastrophic ATS failure or attack within 3.5 minutes. A unique
feature of the WebWay IP/GPRS is the system software that provides availability figures for the monitoring and management every
path of every ATS to 99.8%.
WebWay GPRS/PSTN
The GPRS/PSTN has been tested and certificated by LPCB to LPS1277 for enhanced ATS performance criteria higher than
currently available in Table 11 (EN50131-1:2006+A1:2009)
The standard profile for GPRS/PSTN is Dual Path Enhanced ATS4+ where the reporting time of the secondary path steps up to 10
minutes when the primary is failed and the system will detect a catastrophic ATS failure or attack within 11 minutes. A unique
feature of the WebWay IP/GPRS is the system software that provides availability figures for the monitoring and management every
path of every ATS to 99.8%.
Configuration profiles for Fire alarm transmission and fault warning routing equipment
WebWay IP/GPRS
The IP/GPRS has been tested and certificated by LPCB under LPS1277 for Fire Alarm System to the ATS Type 1 requirements of
EN54-21:2006 Annex A Table A1. See revised Table 11.
The ATS criteria chosen, as the standard profile for IP/GPRS is Dual Path ATS Fire Type 1 where the reporting time of the
secondary path steps up to 90 seconds when the primary path is failed and the system will detect a catastrophic ATS failure or
attack within 3 minutes. A unique feature of the WebWay IP/GPRS is the system software that provides availability figures for the
monitoring and management every path of every ATS to 99.8%.
WebWay GPRS/PSTN
The GPRS/PSTN has been tested and certificated by BRE under LPS1277 for Fire Alarm System to the ATS Type 2 requirements
of EN54-21:2006 Annex A Table A1. See revised Table 11. The standard profile for GPRS/PSTN is Dual Path Enhanced ATS4+
where the reporting time of the secondary path steps up to 10 minutes when the primary is failed and the system will detect a
catastrophic ATS failure or attack within 11 minutes.
A unique feature of the WebWay GPRS/PSTN is the system software that provides availability figures for the monitoring and
management every path of every ATS to 99.8%.
Revised Table 10 - EN50131-1:2006+A1:2009 for enhanced ATS options C4+ and C5
Notification
C
Equipment
Remotely
powered Audible Op
WD
Self-powered
Op
Audible WD
ATS
Main ATS
2
ATS
Additional ATS
1
ATS Dual Path
Note: Single path options and Grade 1 I&HAS have been removed for clarity
Grade 2 (I&HAS)
Options
C C
ATS4PLUS ATS 5
WebWay WebWay
GPRS IP
PSTN GPRS
Op Op
Op Op
ATS4PLUS ATS 5
ATS4PLUS ATS 5
Enhanced Enhanced
ATS4PLUS ATS 5
WebWayOne Ltd, 11 Kingfisher Court, Newbury, Berkshire, RG14 5SJ
Tel 01635 231514: Email
Grade 3 (I&HAS)
Options
C
C
ATS4PLUS
WebWay
GPRS
PSTN
Op Op
Op Op
ATS
ATS4PLUS
4
ATS
ATS4PLUS
3
Enhanced Enhanced
ATS4PLUS
support@webwayone.co.uk
Page 16
Grade 4 (I&HAS)
Options
C
C
ATS 5
WebWay
IP
GPRS
Op Op
Op Op
ATS
ATS 5
5
ATS
ATS 5
4
ATS 5
C
ATS 5
WebWay
IP
GPRS
Op
Op
ATS 5
ATS 5
Enhanced
ATS 5
