Reporting ATS faults to the CIE

When Installing the WebWay to meet EN54-21, EN50131-1 and PD6662 standards the following connections should be made
between the WebWay and the Alarm System.
Fault output relay Signal
EN54-21 Fire mode
PIN output 1 Spare
PIN output 2 Fire Alarm Acknowledged
PIN output 3 Fault Warning
EN50131 I&HAS mode 1
PIN output 1 GPRS failure
Ethernet (IP/GPRS) or
PIN output 2
PSTN failure (GPRS/PSTN)
Spare
PIN output 3
EN50131 I&HAS mode 2
Communications failure/Dual Path
PIN output 1
failure
PIN output 2 Spare
PIN output 3 Spare

Power connection

Ensure the Alarm System power is OFF before connecting the WebWay.
Connect the WebWay PWR + and – terminals to the power supply of the alarm panel +v and –v.
Restore power to the Alarm System.
The WebWay will automatically initiate a start-up sequence and on completion the GSM signal strength will be shown on the
display; represented by a number between 1 - 9 & A (representing a maximum value of 10).
Antenna installation – part 2
Locate the T-Bar Aerial in a position that provides the maximum GPRS signal (1 being the lowest and A, the highest) and fix the
Antenna using the self-adhesive pad.
Note: Do not fix the T-Bar Antenna to the enclosure
Where the panel mounted Antenna is used, affix to a suitable knock-out.
WebWay configuration
The WebWay will normally have been pre configured for your installation and commissioning will automatically commence after
you have entered the site ID and the unit is reset.
Entering the Site ID
Ensure the WebWay displays a stable GSM signal strength reading and proceed to enter the Site ID using the display and
configuration buttons as follows:
Tap button A until menu option 'd' is displayed
Press and hold the 'C' button until '_' is displayed
Tapping the 'A' button decreases the displayed number, and tapping the 'B' button increases the displayed number. Use the A and
B buttons to select the first number of the site ID. When the number appears on the display, press the 'C' button to enter - this will
return the display to '_'
Follow the same process to enter the remaining numbers of the site ID
After the final number of the site ID has been entered press the 'C' button a second time. A moving circle will be displayed followed
by a return to menu option 'd'
Check that you have correctly entered the site ID by pressing the 'C' button and observing the readout
IMPORTANT: If you have entered the ID incorrectly, when the system returns to the signal strength display re-enter the
Site ID.
Commissioning and Automatic Configuration – AUTO TAKEON
Press the RESET button located at the top left of the board (above the display) to finalise the commissioning – it will take up to 5
minutes to complete the commissioning and automatic configuration of the WebWay.
WebWayOne Ltd, 11 Kingfisher Court, Newbury, Berkshire, RG14 5SJ
Tel 01635 231514: Email
Description
Received acknowledgement from the fire alarm receiving centre
A Fault warning signal will be generated when one of the
following faults is detected
1 Failure to receive an acknowledgement to a Fire Alarm
Message within 100s
2 Failure of the WebWay IP/GPRS or WebWay GPRS/PSTN or
power.
3 Failure of the Alarm Transmission Network (all paths failed)
4 A PIN fault (Open Circuit, Short Circuit etc.)
Single Path alarm presented after the elapsed reporting times
defined in Table 11 – enhanced ATS 4+ and Enhanced ATS 5+
Single Path alarm presented after the elapsed reporting times
defined in Table 11 – enhanced ATS 4+ and Enhanced ATS 5+
Catastrophic failure of the Alarm transmission System
