WebWay IP/GPRS & WebWay GPRS/PSTN Installation Manual
Interfaces, Push buttons, Switches, Display, LED Indicators, Inputs, Outputs, and Power
Interfaces - IP/GPRS
Ethernet
Antenna
Serial RS232 – 3 wires: Transmit, Receive & Return path ground
Serial RS485 – 3 wires: A, B, & Return path ground
Serial TTL – 3 wires: Transmit, Receive & Return path ground
Console port
Interfaces – GPRS/PSTN
In addition to IP/GPRS interfaces:
Telephone line – a and b
Extension wiring – a and b
Push Buttons
A, B, & C
DIP Switches
Switch Description
IP/GPRS - force Ethernet FAIL
Switch 1
GPRS/PSTN - force PSTN FAIL
Switch 2 Force GPRS FAIL
Switch 3 MENU
Switch 4 DISP
Switch 5 MODE
Switch 6 RUN/BOOT
Switch 7 33/66
Switch 8 HIGH/LOW
Switch 9 SOFT
Switch 10 TERM

Display

Starburst display
LED Indicators
Legend Indicator
PNL Panel indicator
External port interface
EXT
indicator
ATS Path and interface status
MSG Message status
SMG Commission status
Ethernet data
Notes
Return to OFF after test procedure
Return to OFF after test procedure
Factory setting – do not change
Factory setting – do not change
Factory setting – do not change
Factory setting – do not change
Set to ON when using, Imaging, Modem Capture & Audio Capture module
Factory setting – do not change
Factory setting – do not change
Factory setting – do not change
Description
Shows the data flow for the serial alarm panel interface
- Red for data from the alarm panel to the WebWay
- Green for data from the WebWay to the alarm panel
Shows the data flow for the optional serial alarm panel interface
- Red for data from the external device to the WebWay
- Green for data from the WebWay processor to the external device
Shows the status of each transmission interface and path.
The indicator flashes once for each path followed by a gap.
Each flash provides the following status indications:
Green – Good path on good interface
Orange – Bad interface
Red – Bad path (no communication with ARC) but interface good
Message queue status indication
Indicates the status of the queue of messages being sent to the ARC
Red – Messages are queued and have not been sent
Green – Messages have been sent but not acknowledged
Orange – Messages waiting to be sent plus messages sent and waiting to be
acknowledged
Off – No messages waiting to be sent or waiting to be acknowledged
Indicates the configuration and commission status of the WebWay
Flashing Green (sometimes with a hint of orange) – Commissioned
Flashing Orange – Initialising, system not ready yet
Red / Green Alternate – Not commissioned
Flashing Red – Not Commissioned
Green on – 10BaseT
Green off – 100BaseT
Red - Data activity to and from the LAN
WebWayOne Ltd, 11 Kingfisher Court, Newbury, Berkshire, RG14 5SJ
Tel 01635 231514: Email support@webwayone.co.uk
Page 8
