WebWay IP/GPRS & WebWay GPRS/PSTN Installation Manual
Testing Alarm signals with the ARC
When the WebWay AUTO TAKEON is completed you should send test alarms to your ARC.
If the ARC successfully receives the alarms the system is fully commissioned.
If the ARC does not receive the correct test alarms contact WebWayOne Technical Support on 01635 231514.
Alarm Transmission Path tests with the ARC - Manual
To simulate a failure of the Ethernet path, PSTN Telephone line, or the GPRS path select the following switch positions:
DIP switch settings
RESET
INDICATORS &
DISPLAY
DISPLAY
A
B
CONFIGURATION
BUTTONS
C
Ethernet
Interface
IP/GPRS DIP Switch 1 - if set to 'ON' will simulate Ethernet failure
GPRS/PSTN DIP Switch 1 - if set to 'ON' will simulate PSTN failure
IP/GPRS & GPRS/PSTN DIP Switch 2 - if set to 'ON' will simulate GPRS failure
Note: Ensure that DIP Switches 1 & 2 are returned to the 'OFF' position once testing is complete.
Note: Remote servicing requirements for ATS path tests are explained in the section Remote Servicing.
The installation is now complete
Maximising signal strength
Where signal strength is inadequate for reliable GPRS operation WebWay offer the following Antenna options.
- High Performance disc antenna with that may be attached to the outside of the enclosure.
- High Gain aerial extension antenna with 10, 15 and 20 metre leads
Note: In all cases any excess cable must be loosely coiled outside of the enclosure and ensure the cable is not crushed or kinked,
as this will affect performance.
Roaming SIM & High performance Aerials
A WebWay Roaming SIM is provided which will identify a suitable network for connectivity. If an intermittent or poor quality
performance is not attainable on any of the networks, a High performance/High Gain Aerial should be considered to improve the
GPRS availability to the required performance level. For assistance call WebWay support for assistance on 01635 231514.
DIP SWITCHES
CONSOLE
+ PWR -
WebWayOne Ltd, 11 Kingfisher Court, Newbury, Berkshire, RG14 5SJ
Tel 01635 231514: Email
support@webwayone.co.uk
Page 14
