WebWay IP/GPRS & WebWay GPRS/PSTN Installation Manual
WebWay GPRS/PSTN LPS I&HAS & WebWay GPRS/PSTN LPS Fire
I&HAS signalling configuration –
Enhanced configuration profiles are available for Intruder and Hold-up systems when using the WebWay IP/GPRS. These should
be selected at the time of ordering the system and they will be configured into the WebWay GPRS/PSTN when it is commissioned
to your selected ARC:
When installed as a WebWay GPRS/PSTN I&HAS Signalling System the LPCB label will be identified by a tick in the 1022b/02 box
denotes the approved hardware and configuration.
Configuration
- Grade 2 Alarm systems - LPS1277 Enhanced ATS4PLUS
- Grade 3 Alarm systems - LPS1277 Enhanced ATS4PLUS
Fire signalling configuration
- Fire Alarm Systems – LPS1277 Type 2 Alarm Transmission and fault warning routing equipment
Important: When installed as a FIRE Signalling System a tick in the 22-5015 LPS Fire and 1022a/02 boxes denotes the approved
hardware and configuration will identify the CE label.
Important: The WebWay IP/GPRS should either be installed in the associated EN54 compliant Fire Alarm Panel or an EN54-4
compliant PSU.
Configuration
The configuration settings for compliance with EN54-21 Type 2 are LPS 1277 EN54-21 Type 2 (Part number 1411AD155003)
________________________________________________________________________________________________________
Important notes:
For further information of the signalling profiles and their parameters please refer to the section "Statutory information &
Configuration profiles".
An 'Auto Take-On' procedure is described in this document and should be completed in conjunction with testing of alarm signalling
to the ARC.
If you require assistance from the WebWayOne support group during the installation process you will need to provide the chip
number, site ID and central station number. The number will have been provided by your ARC / Branch and is the number required
for the 'Auto Take-on' procedure
WebWayOne technical support is available between 09.00 am and 5.00 pm Monday to Friday.
Any suspected faulty units should be notified to WebWayOne technical support during the installation process.
Contact for WebWay Technical support - 01635 231514
WebWayOne Ltd, 11 Kingfisher Court, Newbury, Berkshire, RG14 5SJ
Tel 01635 231514: Email support@webwayone.co.uk
