Summary of Contents for SecurityMan cucam1
- Page 4 900MHz 900MHz 900MHz...
- Page 7 900MHz Thank you for purchasing the CUcam SM-202-900TX SM-202-900RX • 1 x manual...
- Page 8 • Do-it-yourself(D.I.Y.), easy to setup and use • Perfect for monitoring around your home or business • Wireless video direct to your TV or recorder • High quality picture and sound transmitting and receiving • No interference from crowded 2.4GHz devices •...
- Page 11 A/V Output (To Monitor/TV)
- Page 14 Away from the camera Toward the camera...
- Page 16 Image Sensor 1/4_CMOS Total Pixels 510(H)_492(V) Video Format NTSC Minimum Illumination 0 lux (IR on) Night Vision Range Up to 23ft Lens Internal, f=3.6mm fish eye lens Transmission Frequency 900MHz Modulation Type 40dB(AGCOff) Transmission Power 2~30mW Audio Frequency Band 4.5MHz Microphone Built-in Voice Monitoring Distance...
- Page 17 Transmission Frequency 900MHz Channel Indication 1 Green LED Frequency Stability ±100KHz Local Oscillator Leakage ≤-55dBm Receiving Sensitivity ≤-85dBm Differential Phase 10Deg. 38dB Video Output Impedance 75ohm Video Output Voltage 1.0±0.2Vp-p(Standard value:1Vp-p) Audio Carrier 4.5MHz Audio Frequency Band 100_20KHz Audio Output Impedance 10Kohm Audio Output Impedance 1.2±0.4Vp-p(Standard value:1Vp-p)
