STACKED ISO UNITS PROVISION

*
Note: Refer also to the instructions included with the aftermarket radio.
1 Slide the appropriate side bracket over
the mounting legs of the Double DIN
trim plate aligning the holes in the trim
plate and the bracket. (Figure A)
2 Slide the stacked ISO DIN units into the
trim plate bracket assembly and secure
the units to the kit using the screws
supplied with the head units. (Figure B)
3 NOTE:
The notch in the housing should be on
top.
Continue to final assembly.
99-5807 KIT ASSEMBL Y
9
A
B
