5
DIN HEAD UNITS: Slide the DIN cage into the Radio Housing and secure by bending the
metal locking tabs outward. Slide the aftermarket head unit into the cage until it snaps into
place.
6
A
B
C
D
A) Strip wire ends back ½"
B) Twist ends together
C) Solder
D) Tape
Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adaptor and making
connections as shown. (Isolate and
individually tape off the ends of any
unused wires to prevent electrical short
circuit).
3
7
Re-connect the battery terminal and test the unit
for proper operation.
Snap the head unit/kit
assembly into the sub-dash.
rev. 4-10-08
KIT FEATURES
DIN unit
provision
99-5800
Equalizer
provision
INSTALLATION
Pocket
INSTRUCTIONS
provision
APPLICATIONS
KIT COMPONENTS
CAR
Radio Housing
FORD
Expedition 1997-98.........................................1-3
F-150 1997-98...................................................1-3
TOOLS REQUIRED
86-5618 - Head unit
removal keys
Socket set
Cutting tool
1-800-221-0932
Dremel tool
© COPYRIGHT 2001 METRA ELECTRONICS CORPORATION
PAGE
www.metraonline.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Metra Electronics 99-5800
Summary of Contents for Metra Electronics 99-5800
- Page 1 (Isolate and Cutting tool individually tape off the ends of any unused wires to prevent electrical short circuit). 1-800-221-0932 www.metraonline.com Dremel tool © COPYRIGHT 2001 METRA ELECTRONICS CORPORATION rev. 4-10-08...
- Page 2 ALL VEHICLES Fig. A Dash cavity Fig. B Disconnect the negative battery terminal to prevent an accidental short circuit. Place your index fingers on the inner edges of the a/c vents (shown above) and push inward. Grasp the exposed lip of each vent opening and pull out on the radio trim bezel. Remove the dash trim bezel.
