OSD MENU *
EXPOSURE
LENS
SHUTTER
BLC
AGC
MAX-DR
STARIGHT
EXIT JUMP
COLOR
WB MODE
R-Y GAIN
B-Y GAIN
DAY & NIGHT
Day & Night Mode
C-SUP
A-SUP
EXIT JUMP
(D2367WD, D2367WTIR)
DC (0~100) / MANUAL / VIDEO. (DC Lens is recommended.)
1/60, 1/100FLC, 1/120 ~ 1/100000
OFF / ON
BLC (Back Light Compensation)
HIGH / MIDDLE / LOW / OFF
Auto Gain Control
OFF /ON (0~ 20) (Electronic Wide Dynamic Range)
OFF / AUTO (x2 ~ x256)
x32 is recommended.
EXIT / SAVE&EXIT / FACTORY SET
AWC / ATW / MANUAL / PUSH LOCK
0 ~ 100
0 ~ 100
AUTO/ COLOR/ BW / EX-CONT
COLOR --> BW: Switching fromcolor to BW; if the number is higher, the camera will only switch during a
super low light condition.
BW --> COLOR: Switching from BW to color; this number should always be lower than COLOR --> BW.
Read Time: Time interval to switch from Color to BW.
COLOR
B&W: BURST (OFF/ON); There is less noise when the BURST is OFF.
Color Suppression: Color will be reduced at low illumination, if the C-SUP Level is higher. 0 ~ 100 (Not Available
(Not Available when 3D-DNR is On.)
ApertureSuppression: The sharpness of the edges will be reduced at low illumination, if A-SUP Level is higher. 0 ~ 100
(Not Available when 3D-DNR is On.)
EXIT / SAVE&EXIT / FACTORY SET
