  • Page 3 Preface Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. Version 2.0 Disclaimer The information in this document is subject to change without notice.

  • Page 4: Declaration Of Conformity

    Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation Canadian Department of Communications This class B digital apparatus meets all requirements of the Canadian Interference-causing Equipment Regulations.

  • Page 5: Table Of Contents

    T T T T T ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS Preface Chapter 1 Introducing the Motherboard Introduction....................1 Feature......................2 Motherboard Components................4 7 7 7 7 7 Chapter 2 Installing the Motherboard Safety Precautions..................7 Choosing a Computer Case...............7 Installing the Motherboard in a Case............7...
  • Page 6 Power Management Features............34 PCI/Plug and Play Setup.............35 BIOS Security Features..............36 CPU PnP Setup................36 Hardware Monitor...............37 Load Optimal Defaults..............38 Save Changes and Exit..............38 Discard Changes and Exit............38 Chapter 4 39 39 Using the Motherboard Software About the Software CD-ROM..............39 Auto-installing under Windows 98/ME/2000/XP........39 Running Setup................40 Manual Installation..................42 Utility Software Reference...............42...

  • Page 7: Introducing The Motherboard

    Chapter 1 Introducing the Motherboard Introduction Thank you for choosing the P4M800PRO-M motherboard. This motherboard is a high performance, enhanced function motherboard that supports the LGA775 socket for Intel® Core™ 2 Duo/Pentium D/Pentium 4/Celeron D processors for high-end business or per- sonal desktop markets.

  • Page 8: Feature

    Feature Processor This motherboard uses an LGA775 type of Intel® Core™ 2 Duo/Pentium D/Pentium 4/Celeron D that carries the following features: • Accommodates Intel® Core™2 Duo/Pentium D/Pentium 4/Celeron D proces- sors • Supports a system bus (FSB) of 1066/800/533 MHz •...
  • Page 9 Onboard LAN (Optional) The onboard LAN controller provides either of the following features: • Integrates 10/100/1000 transceiver • Supports PCI v.2.3, 32-bit, 33/66 MHz • Crossover Detection & Auto-Correction • Wake-on-LAN and remote wake-up support • Supports 10 Mb/s and 100 Mb/s N-way Auto-negotiation operation •...

  • Page 10: Motherboard Components

    Motherboard Components Introducing the Motherboard...
  • Page 11 Table of Motherboard Components LABEL COMPONENT 1 CPU Socket LGA775 socket for Intel® Core™2 Duo/ Pentium D/Pentium 4/Celeron D CPUs 2 CPU_FAN CPU cooling fan connector 3 DDRII1~2 240-pin DDR2 SDRAM slots 4 DDR1~2 184-pin DDR SDRAM slots 5 ATX1 Standard 24-pin ATX power connector 6 IDE1 Primary IDE channel...
  • Page 12 Memo Introducing the Motherboard...

  • Page 13: Installing The Motherboard

    Chapter 2 Installing the Motherboard Safety Precautions • Follow these safety precautions when installing the motherboard • Wear a grounding strap attached to a grounded device to avoid damage from static electricity • Discharge static electricity by touching the metal case of a safely grounded object before working on the motherboard •...

  • Page 14: Checking Jumper Settings

    Do not over-tighten the screws as this can stress the motherboard. Checking Jumper Settings This section explains how to set jumpers for correct configuration of the motherboard. Setting Jumpers Use the motherboard jumpers to set system configuration options. Jumpers with more than one pin are numbered.

  • Page 15: Checking Jumper Settings

    Checking Jumper Settings The following illustration shows the location of the motherboard jumpers. Pin 1 is labeled. Jumper Settings Jumper Description Type Setting (default) 1-2: NORMAL 2-3: CLEAR 3-pin CLR_CMOS Clear CMOS Before clearing the CMOS, make sure to CLR_CMOS turn off the system.

  • Page 16: Connecting Case Components

    Connecting Case Components After you have installed the motherboard into a case, you can begin con- necting the motherboard components. Refer to the following: Connect the CPU cooling fan cable to CPU_FAN. Connect the system cooling fan connector to SYS_FAN. Connect the case switches and indicator LEDs to the PANEL1.

  • Page 17: Atx 24-Pin Power Connector

    CPU_FAN: CPU FAN Power Connector Signal Name Function System Ground Power +12V +12V Sense Sensor CPU FAN control Users please note that the fan connector supports the CPU cooling fan of 1.1A~2.2A (26.4W max.) at +12V. SYS_FAN: System cooling FAN Power Connector Signal Name Function System Ground...

  • Page 18: Front Panel Connector

    Front Panel header The front panel header (PANEL1) provides a standard set of switch and LED headers commonly found on ATX or micro-ATX cases. Refer to the table below for information: Signal Function Signal Function FP PWR/SLP *MSG LED(+) HD_LED_P Hard disk LED(+) HD_LED_N Hard disk LED(-) FP PWR/SLP *MSG LED(-) RST_SW_N Reset Switch(-)

  • Page 19: Installing Hardware

    Installing Hardware Installing the Processor Caution: When installing a CPU heatsink and cooling fan make sure that you DO NOT scratch the motherboard or any of the surface-mount resistors with the clip of the cooling fan. If the clip of the cooling fan scrapes across the motherboard, you may cause serious damage to the motherboard or its components.

  • Page 20: Cpu Installation Procedure

    CPU Installation Procedure The following illustration shows CPU installation components. Read and follow the instructions shown on the sticker on the CPU cap. B. Unload the cap · Use thumb & forefinger to hold the lifting tab of the cap. ·...

  • Page 21: Installing Memory Modules

    Installing Memory Modules This motherboard accommodates four memory modules. It can support two 184-pin unbuffered DIMMs, DDR 400/333/266 or two 240-pin DDR2 533/400. The total memory support capacity is 2 GB. Users please note that DDR & DDR2 can’t both be applied at the same time on this motherboard.
  • Page 22 Table A: DDR (memory module) QVL (Qualified Vendor List) The following DDR400 memory modules have been tested and qualified for use with this motherboard. Module Name Size Vendor APACER AM3A568ACT05A CORSAIR PLATNUM CMX256-3200C2PT GEIL G208L364D1TG5NKT3C GEIL GE08L3264D1WL5NKT3H71 GEIL GL3L32G88TG-5A Hynix HY5DU56822BT-D43 256 MB Kingston Winbond...
  • Page 23 Table B: DDR2 (memory module) QVL (Qualified Vendor List) The following DDR2 memory modules have been tested and qualified for use with this motherboard. Type Size Vendor Module Name Hynix HYMP532U646-E3 AA 256 MB Nanya NT256T64UH4A0F-5A CL3 DDR2 400 Samsung M378T3253FG0-CCC Hynix HYMP564U648-E3 AA...

  • Page 24: Installing A Hard Disk Drive/Cd-Rom/Sata Hard Drive

    Installing a Hard Dish Drive/CD-ROM/SATA Hard Drive This section describes how to install IDE devices such as a hard disk drive and a CD-ROM drive. About IDE Devices Your motherboard has two IDE channels interface. An IDE ribbon cable supporting two IDE devices is bundled with the motherboard.
  • Page 25 About SATA Connectors Your motherboard features two SATA connectors supporting a total of two drives. SATA , or Serial ATA (Advanced Technology Attachment) is the standard interface for the IDE hard drives which are currently used in most PCs. These connectors are well designed and will only fit in one orientation.

  • Page 26: Installing A Floppy Diskette Drive

    Installing a Floppy Diskette Drive The motherboard has a floppy diskette drive (FDD) interface and ships with a diskette drive ribbon cable that supports one or two floppy diskette drives. You can install a 5.25-inch drive and a 3.5-inch drive with various capacities. The floppy diskette drive cable has one type of connector for a 5.25-inch drive and another type of connector for a 3.5-inch drive.

  • Page 27: Installing Add-On Cards

    Installing Add-on Cards The slots on this motherboard are designed to hold expansion cards and connect them to the system bus. Expansion slots are a means of adding or enhancing the motherboard’s features and capabilities. With these efficient facilities, you can increase the motherboard’s capabili- ties by adding hardware that performs tasks that are not part of the basic system.
  • Page 28 Follow these instructions to install an add-on card: Remove a blanking plate from the system case corresponding to the slot you are going to use. Install the edge connector of the add-on card into the expansion slot. Ensure that the edge connector is correctly seated in the slot. Secure the metal bracket of the card to the system case with a screw.

  • Page 29: Connecting Optional Devices

    Connecting Optional Devices Refer to the following for information on connecting the motherboard’s optional devices: USB3~4: Front Panel USB headers The motherboard has four USB ports installed on the rear edge I/O port array. Additionally, some computer cases have USB ports at the front of the case. If you have this kind of case, use auxiliary USB connector to connect the front-mounted ports to the motherboard.
  • Page 30 AUDIO1: Front Panel Audio header This header allows the user to install auxiliary front-oriented microphone and line-out ports for easier access. Signal Name Function AUD_MIC Front Panel Microphone input signal AUD_GND Ground used by Analog Audio Circuits AUD_MIC_BIAS Microphone Power AUD_VCC Filtered +5V used by Analog Audio Circuits AUD_F_R...
  • Page 31 IRDA: Infrared header (Optional) The motherboard supports an Infrared (IRDA) data port. Infrared ports allow the wireless exchange of information between your computer and similarly equipped devices such as printers, laptops, Personal Digital Assistants (PDAs), and other computers. Signal Name Description No Pin IRRX...

  • Page 32: Connecting I/O Devices

    Connecting I/O Devices The backplane of the motherboard has the following I/O ports: PS2 Mouse Use the upper PS/2 port to connect a PS/2 pointing device. PS2 Keyboard Use the lower PS/2 port to connect a PS/2 keyboard. Parallel Port (LPT1) Use LPT1 to connect printers or other parallel communications devices.

  • Page 33: Using Bios

    Chapter 3 Using BIOS About the Setup Utility The computer uses the latest American Megatrends BIOS with support for Windows Plug and Play. The CMOS chip on the motherboard contains the ROM setup instructions for configuring the motherboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system’s configura- tion status and provides you with options to set system parameters.

  • Page 34: Bios Navigation Keys

    Press DEL/F1 to enter SETUP Press the delete key or F1 to access the BIOS Setup Utility. CMOS Setup Utility -- Copyright (C) 1985-2005, American Megatrends, Inc. Standard CMOS Setup CPU PnP Setup Advanced Setup Hardware Monitor Features Setup Load Optimal Defaults Power Management Features Save Changes and Exit PCI / Plug and Play Setup...

  • Page 35: Updating The Bios

    Updating the BIOS You can download and install updated BIOS for this motherboard from the manufacturer’s Web site. New BIOS provides support for new peripherals, improvements in performance, or fixes for known bugs. Install new BIOS as follows: If your motherboard has a BIOS protection jumper, change the setting to allow BIOS flashing.

  • Page 36: Standard Cmos Setup

    Standard CMOS Setup This option displays basic information about your system. CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc. Standard CMOS Setup System Time 00: 01: 16 Help Item System Date Wed 08/23/2006 Primary IDE Master Hard Disk Primary IDE Slave Not Detected Use [ENTER], [TAB]...
  • Page 37 Quick Boot (Enabled) If you enable this item, the system starts up more quickly because of the elimination of some of the power on test rutines. 1st/2nd/rd Boot Device Use this item to determine the device order the computer used to look for an operating system to load at start-up time.

  • Page 38: Features Setup

    Vanderpool Technology (Enabled) This item enables or disables the Vanderpool Technology. When disabled, forcess the VT function will close. BIOS Protect (Disabled) This item enables or disables the BIOS protection function. Press <Esc> to return to the main menu setting page. Features Setup This page sets up some parameters for peripheral devices connected to the system.
  • Page 39 ECP Mode DMA Channel (DMA3) Use this item to assign the DMA Channel under ECP Mode function. Parallel Port IRQ (IRQ7) Use this item to assign IRQ to the parallel port. OnBoard PCI IDE Controller (Both) Use this item to enable or disable either or both of the onboard Primary and Secondary IDE channels.

  • Page 40: Power Management Features

    Power Mangement Features This page sets up some parameters for system power management operation. CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc. Power Management Features Help Item ACPI Aware O/S Power Management Enabled ACPI Enhanced Efficiency Disabled Enable/Disable Suspend Time Out Disabled ACPI support for...

  • Page 41: Pci/Plug And Play Setup

    Restore on AC/Power Loss (Power Off) This item defines how the system will act after AC power loss during system operation. When you set to Off, it will keep the system in Off state until the power button is pressed. Press <Esc>...

  • Page 42: Bios Security Features

    BIOS Security Features This page helps you install or change a password. CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc. BIOS Security Features Help item Security Settings _____________________________________________________ Supervisor Password : Not Installed Install or Change the password. Change Supervisor Password Press Enter Enter : Select...

  • Page 43: Hardware Monitor

    Manufacturer (Intel) This item indicates the brand of the CPU installed in your system. Ratio Actual Value (8) This item indicates the ratio actual value of the CPU installed in your system. CPU Over-clocking Func. (Disabled) This item decides the CPU over-clocking function/frequencyinstalled in your system. If the over-clocking fails, please turn offthe system power.

  • Page 44: Load Optimal Defaults

    System Hardware Monitor These items display the monitoring of the overall inboard hardware health events, such as system&CPU temperature, CPU & DIMM voltage, CPU & system fan speed,...etc. Shutdown Temperature (Disabled) This item enables users to set the maximum temperature the system can reach before powering down.

  • Page 45: Using The Motherboard Software

    Chapter 4 Using the Motherboard Software About the Software CD-ROM The support software CD-ROM that is included in the motherboard package contains all the drivers and utility programs needed to properly run the bundled products. Below you can find a brief description of each software program, and the location for your motherboard version.

  • Page 46: Running Setup

    Setup Tab Setup Click the Setup button to run the software installation program. Select from the menu which software you want to install. Browse CD The Browse CD button is the standard Windows command that allows you to open Windows Explorer and show the contents of the support Before installing the software from Windows Explorer, look for a file named README.TXT, INSTALL.TXT or something similar.
  • Page 47 Click Next. The following screen appears: Check the box next to the items you want to install. The default options are recommended. Click Next run the Installation Wizard. An item installation screen appears: Follow the instructions on the screen to install the items. Drivers and software are automatically installed in sequence.

  • Page 48: Manual Installation

    Manual Installation Insert the CD in the CD-ROM drive and locate the PATH.DOC file in the root directory. This file contains the information needed to locate the drivers for your motherboard. Look for the chipset and motherboard model; then browse to the directory and path to begin installing the drivers.

  • Page 49: Via Vt8237 Sata Raid Setup Guide

    Chapter 5 VIA VT8237 SATA RAID Setup Guide VIA RAID Configurations The motherboard includes a high performance Serial ATA RAID controller integrated in the VIA VT8237 Southbridge chipset. It supports RAID 0, RAID 1 and JBOD with two indepen- dent Serial ATA channels. RAID: (Redundant Array of Independent Disk Drives) use jointly several hard drives to increase data transfer rates and data security.
  • Page 50 Either end of the Serial ATA data cable can be connected to the SATA hard disk or the SATA connector on the motherboard. Install the Serial ATA hard disks into the drive bays. Connect one end of the Serial ATA cable to the motherboard’s primary Serial ATA connector (SATA1).
  • Page 51 Create Array In the VIA RAID BIOS utility main menu, select Create Array then press the <Enter> key. The main menu items on the upper-left corner of the screen are replaced with create array menu options. RAID 0 for performance Select the second option item Array Mode, then press the <Enter>...
  • Page 52 Select Start Create Process and press <Enter> to setup hard disk for RAID system. The following confirmation appears: The same confirmation message appears when the Auto Setup for Performance option is selected. Press “Y” to confirm or “N” to return to the configuration options. RAID 1 for data protection Select the second option item Array Mode, then press the <Enter>...
  • Page 53 Delete Array In the VIA RAID BIOS utility main menu, select Delete Array then press the <Enter> key. The focus is directed to the list of channel used for IDE RAID arrays. Press the <Enter> key to select a RAID array to delete. The following confir- mation message appears.
  • Page 54 Duplicate Critical RAID 1 Array When booting up the system, BIOS will detect if the RAID 1 array has any inconsistencies between user data and backup data. If BIOS detects any inconsistencies, the status of the disk array will be marked as critical, and BIOS will prompt the user to duplicate the RAID 1 in order to ensure the backup data consistency with the user data.
  • Page 55 1. Power off and Check the Failed Drive: This item turns off the computer and replaces the failed hard drive with a good one. If your computer does not support APM, you must turn off your computer manually. After replacing the hard drive, boot into BIOS and select Choose replacement drive and rebuild to rebuild the broken array.

  • Page 56: Installing Raid Software & Drives

    Windows XP installation. Existing Windows XP Driver Installation Insert the ECS CD into the CD-ROM drive. The CD will auto-run and the setup screen will appear. Under the Driver tab, click on VIA SATA RAID Utility.
  • Page 57 VIA SATA RAID utility • RAID0 and RAID1 functions Insert the ECS CD and click on the Setup to install the software. The InstallShield Wizard will begin automatically for installation. Click on the Next button to proceed the installation in the welcoming window.

  • Page 58: Using Via Raid Tool

    Put a check mark in the check box to install the feature you want. Then click Next button to proceed the installation. Using VIA RAID Tool Once the installation is complete, go to Start---> Programs---> VIA---> raid_tool.exe to enable VIA RAID Tool. After the software is finished installation, it will automati- cally started every time Windows is initiated.
  • Page 59 The main interface is divided into two windows and the toolbar above contain the main functions. Click on these toolbar buttons to execute their specific functions. The left windowpane displays the controller and disk drives and the right windowpane displays the details of the controller or disk drives.
  • Page 60 Click on the plus (+) symbol next to Array 0--RAID 0 to see the details of each disk. You may also use the same button to view the statuses of Array 0-- RAID 1. VIA VT8237 SATA RAID Setup Guide...
  • Page 61 Click on the plus (+) symbol next to Array 0; RAID 1 to see the details of each disk. VIA VT8237 SATA RAID Setup Guide...
  • Page 62 Memo VIA VT8237 SATA RAID Setup Guide...
  • Page 63 Caractéristiques Processeur La carte mère utilise un type LGA775 d’Intel® Core™2 Duo/Pentium D/Pentium 4/ Celeron D comportant les caractéristiques suivantes : • Reçoit des processeurs Intel® Core™ 2 Duo/Pentium D/ Pentium 4/ Celeron D • Prend en charge un bus système (FSB) de 1066/800/533 MHz •...
  • Page 64 LAN interne (optionnel) Cette carte mère prend en charge les chipsets LAN suivants : • Emetteur-récepteur 10/100/1000 intégré • Prend en charge PCI v2.3, 32 bits, 33/66-MHz • Détection de croisement & Correction auto • Prise en charge de Réveil par LAN et réveil distant •...
  • Page 65 Feature Prozessor Das Mainboard verwendet einen LGA775 Typ Intel® Core™2 Duo/ Pentium D/Pentium 4/ Celeron D mit den folgenden Eigenschaften: • Nimmt Intel® Core™2 Duo/ Pentium D/Pentium 4/ Celeron D Prozessoren auf • Unterstützt einen Systembus (FSB) mit 1066/800/533MHz • Unterstützt eine CPU mit „Hyper-Threading“...
  • Page 66 Integriertes LAN (optional) Dieses Mainboard kann einen der folgenden LAN-Chipsätze unterstützen: • Enthält 10/100/1000 Transceiver • Unterstützung von PCI v2.3, 32-Bit, 33/66-MHz • Crossover Detection & Auto-Correction • Unterstützung für Wake-on-LAN und Remote Wake-up • Unterstützt den Betrieb bei 10 Mb/s und 100 Mb/s N-Way Auto-Negotiation •...
  • Page 67 Caratteristiche Processore La scheda madre utilizza un tipo LGA775 di processore Intel® Core™2 Duo / Pentium D/ Pentium 4 / Celeron D che offre le seguenti caratteristiche: • Alloggia processori Intel® Core™2 Duo / Pentium D/Pentium 4 / Celeron D •...
  • Page 68 integrata (opzionale) La scheda madre offre supporto per uno dei seguenti chipset LAN: • Transceiver 10/100/1000 integrato • Supporta PCI v2.3, 32-bit, 33/66-MHz • Rilevazione e crossover e autocorrezione • Supporto di funzionalità Wake-on-LAN e riattivazione remota • Supporto di NWay Auto-negotiation a 10 Mb/s e 100 Mb/s •...
  • Page 69 Característica Procesador La placa principal usa un tipo LGA775 de Intel® Core™2 Duo/Pentium D/Pentium 4/ Celeron D que lleva las sigtes. características: • Acomoda procesadores Intel® Core™2 Duo/Pentium D/Pentium 4/ Celeron D • Soporta un bus de sistema (FSB) de 1066/800/533MHz •...
  • Page 70 LAN Abordo (optativo) Esta placa principal puede soportar uno de los sigtes. chipset LAN: Transceptor 10/100/1000 integrado • • Soporta PCI v2.3, 32-bit, 33/66-MHz • Detección Cruzada & Autocorrección • Soporte de Despertar-en-LAN y Despertar remoto • Soporta operación de Autonegociación N-Way de 10 Mb/s y 100 Mb/s •...
  • Page 71 Características Processador Esta motherboard usa um tipo de Intel® Core™2 Duo/Pentium D/Pentium 4/ Celeron D LGA775 que possui as seguintes características: • Acomoda processadores Intel® Core™2 Duo/Pentium D/Pentium 4/ Celeron D • Suporta um bus de sistema (FSB) de 1066/800/533MHz •...
  • Page 72 Onboard LAN (opcional) Esta motherboard poderá suportar qualquer um dos seguintes conjuntos de chips LAN: • Transreceptor integrado 10/100/1000 • Suporta PCI v2.3, 32-bit, 33/66-MHz • Detecção Crossover & Auto Correcção • Suporte Wake-on-LAN e wake-up remoto • Suporta operação de Auto-negociação N-Way 10 Mb/s e100 Mb/s •...
  • Page 73 機能 プロセッサ 本マザーボードは LGA775タイプのIntel® Core™2 Duo/Pentium D/Pentium 4/ Celeron D を利用するもので、下記の特徴を持っています： • Intel® Core™2 Duo/Pentium D/Pentium 4/ Celeron Dプロセッサに対応 • 1066/800/533 MHzのシステムバス(FSB)をサポート • “ハイパースレッド” 技術をサポート ハイパースレッド（HT） 技術というのは、オペレーションシステムに2つのプロセッサが 存在すると認識させることで、実際には2つのスレッドを1つのプロセッサで同時に執行さ せ、平行利用を可能とする技術です。 チップセット P4M800PRO Northbridge (NB)と VT8237 Southbridge (SB)チップセットは、実証 された信頼性と性能を持つ革新的で拡張性のあるアーキテクチャに基づいています。 P4M800PRO • 高性能のノースブリッジチップセットを搭載、Intel® Core™2 Duo/Pentium (NB) D/Pentium 4/ Celeron D プロセッサおいての1066/800/533 MHz FSB を...
  • Page 74 オンボードLAN (オプション) 当マザーボードは次のLANチップセットのいずれかを搭載しております： • 10/100/1000 トランシーバーを搭載済み • PCI v2.3, 32-bit, 33/66-MHzへの対応 • クロスオーバー検出機能と自動修正機能を搭載 • Wake-on-LANと遠隔 wake-upとの機能をサポート • 10 Mb/s と 100 Mb/s N-way自動ネゴシエーション操作をサポート • 半/全二重の機能をサポート • Wake-On-LAN (WOL) と遠隔wake-up機能をサポート • 10/100/1000 トランシーバーを搭載 • PCI v2.3, 32-bit, 33/66-MHzへの対応 • IEEE 802.3、IEEE802.3u および IEEE802.3abに完全対応 拡張オプション...
  • Page 75 특성 프로세서 본 마더보드는 Intel® 코어 2 듀오/팬티엄 D/팬티엄 4/ 셀러론 D 의 LGA775 타입을 사 ™ 용하였으며 다음과 같은 특성을 지닌다. • Intel® 코어 2 듀오/팬티엄 D/팬티엄 4/ 셀러론 D 프로세서 사용 ™ • 1066/800/533MHz 의 시스템 버스 (FSB) 지원 •...
  • Page 76 보드 내장 LAN (선택 사항) 본 마더보드는 다음과 같은 LAN 칩셋을 지원합니다: • 통합 10/100/1000 트랜시버 • PCI v2.3, 32-bit, 33/66-MHz 지원 • Crossover Detection 및 Auto-Correction • Wake-on-LAN 및 원격 wake-up 지원 • 10 Mb/s 및 100 Mb/s N-Way Auto-negotiation 작업 지원 •...
  • Page 77 功能 處理器     C ore ™ 2 Duo/Pentium D/Pentium 4/ Celeron D ， 本主機板可安裝一個 LGA775型式之Intel® 並具有如下特色：     C ore ™ 2 Duo/Pentium D/Pentium 4/ Celeron D • 支援 Intel® 處理器 • 支援高達1066/800/533MHz之前端匯流排(FSB) • 支援使用超執行緒(Hyper-Threading)技術之處理器 利用“超執行緒(HT)”技術，可使作業系統在相當於裝上了兩具處理器的狀態下運...
  • Page 78 內建區域網路 (選購) 本主機板搭載有如下其中一種LAN晶片組： • 整合有10/100/1000 收發器 • 支援PCI v2.3, 32位元, 33/66-MHz • 具有跳接線偵測及自動修正功能 • 支援區域網路喚醒功能及遠距喚醒功能 • 支援 10 Mb/s 及100 Mb/s N-way 自動協商運作 • 支援半/全雙工功能 • 支援區域網路喚醒(Wake-On-LAN)及遠端喚醒功能 • 整合有10/100/1000 收發器 • 支援PCI v2.3, 32位元, 33/66-MHz • 具有跳接線偵測及自動修正功能 擴充選項 本主機板包括下列擴充選項： • 1 個AGP插槽...
  • Page 79 功能 处理器 此主板使用 LGA775 型 Intel® Core™2 Duo/Pentium D/Pentium 4/ Celeron D 处理 器，具有以下特点： • 支持 Intel® Core™2 Duo/Pentium D/Pentium 4/ Celeron D 处理器 • 支持 1066/800/533 MHz 系统总线 (FSB) • 支持“多线程”技术 CPU “多线程”技术可以让操作系统认为自己连接了两个处理器，允许两个线程并行运 行，每个线程位于同一处理器中的单独“逻辑”处理器中。 芯片组 P4M800PRO 北桥 (NB) 和 VT8237R Plus 南桥 (SB) 芯片组是基于一种新型的、可 扩展的架构，能提供已经证明的可靠性和高性能。...

  • Page 80: Onboard Lan

    Onboard LAN（可选） 此主板支持以下任何一种 LAN 芯片组： • 集成 10/100/1000 收发器 • 支持 PCI v2.3，32-位，33/66-MHz • 跨接检测和自动校正 • 支持 LAN 和远程唤醒 • 支持 10 Mb/s 和 100 Mb/s N 路自协商工作 • 支持半双工/全双工工作 • 支持 LAN 唤醒(WOL)功能和远程唤醒功能 • 集成 10/100/1000 收发器 • 支持 PCI v2.3，32-位，33/66-MHz •...
  • Page 81 Характеристики Процессор Материнская плата построена для процессоров типа LGA775 Intel® Core™2 Duo/ Pentium D/Pentium 4/ Celeron D и обладает следующими свойствами: • Размещает процессоры Intel®Core™ 2 Duo/Pentium D/Pentium 4/Celeron D • Поддерживает системные шины (FSB) с частотой 1066/800/533MHz • Поддерживает технологию CPU “Hyper-Threading” Технология...
  • Page 82 Встроенный сетевой адаптер LAN (опционально) Встроенный сетевой адаптер LAN обладает следующими характеристиками: • Интегрированный трансивер 10/100/1000 • Поддеркжа PCI v2.3, 32-бит, 33/66-MГц • Детекция и автокоррекция Crossover • Функция Wake-on-LAN и удаленного пробуждения Поддерживает автоматическое определение скорости и режима • соединения...
  • Page 83 Cechy Procesor Płyta główna posiada podstawkę typu LGA775, która jest przystosowana do obsługi procesorów Intel® Core™2 Duo/Pentium D/Pentium 4/ Celeron D i posiada następujące właściwości: • Dostosowana do procesorów: Intel® Core™ 2 Duo/Pentium D/ Pentium 4/ Celeron D • Obsługuje szynę systemowa (FSB) 1066/800/533MHz •...
  • Page 84 Zintegrowana obsługa sieci LAN (opcjonalnie) Zintegrowana obsługa sieci LAN posiada następujące właściwości: • Zintegrowany terminal nadawczo-odbiórczy 10/100/1000 • Obsluguje 32 bitowe PCI w wersji 2.3 o częstotliwościach 33/66-MHz • Detekcja Crossover i autokorekcja • Obsługuje Wake-on-LAN i zdalne wake-up • Obsluguje N-drożne automatycznie ustalane operacje z szybkościami 10 Mb/s i 100 Mb/s Zdolność...
  • Page 85 Vlastnosti Procesor Tato základní deska používá typ LGA775 Intel® Core 2 Duo/Pentium D/Pentium 4/Celeron D , který má následující vlastnosti: • Určená pro procesory Intel® Core™ 2 Duo/ Pentium D/Pentium 4/Celeron D • Podporuje taktování systémové sběrnice (FSB) na frekvenci 1066/800/533 •...
  • Page 86 Vestavění síťové rozhraní LAN (volitelně) Vestavěné síťové rozhraní LAN nabízí následující možnosti: • Integrovaný transceiver 10/100/1000 • Podpora rozhraní PCI v2.3, 32bitové, 33/66 MHz • Detekce přeslechu a automatická korekce • Podpora funkce Wake–on–LAN a vzdálené aktivace • Podpora 10 Mb/s a 100 Mb/s N–cestného automatického přepínání provozu •...
  • Page 87 Caracteristici Procesorul Placa de bază utilizează Intel® Core™2 Duo/Pentium D/Pentium 4/ Celeron D de tip LGA775 cu următoarele caracteristici: • Acomodează procesoare Intel® Core™2 Duo/Pentium D/ Pentium 4/ Celeron D • Funcţionează cu bus sistem (FSB) de 1066/800/533 MHz • Este compatibilă...
  • Page 88 Onboard LAN (opţional) Onboard LAN are următoarele caracteristici: • Unitate de emisie/recepţie 10/100/1000 integrat • Suportă PCI, versiunea 2.3, de 32 biţi, la 33/66 MHz • Detectare tranziţie şi corectare automată • Suport pentru funcţiile Wake-on-LAN şi trezire la distanţă •...
  • Page 89 Спецификация Процесор Тази дънна платка използва сокет LGA775 за процесори Intel® Core™2 Duo/ Pentium D/Pentium 4/ Celeron D и поддържа следните спецификации: • поддръжка на процесори Intel® Core™ 2 Duo/Pentium D/ Pentium 4/ Celeron D • поддръжка на системна шина със скорост 1066/800/533MHz •...
  • Page 90 Интегриран мрежов контролер (опция) Спецификация на интегрирания мрежов контролер: • Интегриран 10/100/1000 контролер • поддръжка на PCI v2.3, 32-bit, 33/66-MHz • Автоматично разпознаване и конфигурация • Поддръжка на функции Wake-on-LAN и remote wake-up • поддръжка на 10 Mb/s и 100 Mb/s, N-Way Auto-negotiation operation •...
  • Page 91 Jellemző Processzor Az alaplap LGA775 típusú Intel® Core™2 Duo/Pentium D/Pentium 4/ Celeron D processzort használ, a következő tulajdonságokkal: • Intel® Core™2 Duo/Pentium D/Pentium 4/ Celeron D processzorokkal működik • 1066/800/533 MHz sebességű rendszerbuszt (FSB) támogat • Támogatja a „Hyper-Threading” technológiát használó központi egységeket A „Hyper-Threading”...
  • Page 92 Alaplapon levő LAN (választható) Az alaplapon levő LAN jellemzői: • Integrált 10/100/1000 adó-vevő • Támogatja a 32 bites, 33/66 MHz-es PCI 2.3-as változatát • Rendszerváltás érzékelés és automatikus javítás • A Wake-on-LAN és a távoli ébresztés funkciók támogatása • 10 Mb/s és 100 Mb/s N-Way automatikus beállítással •...
