Pc Camera Audio Setup - Eluktronics PRO17SE User Manual

Modules
6
Figure 6 - 6
Audio Setup for PC
Camera
6 - 12 PC Camera Module

PC Camera Audio Setup

If you want to capture video & audio with your camera, it is necessary to setup the
audio recording options in Windows.
1. Go to the Control Panel.
2. Click Sound (Hardware and Sound) and click Recording (tab).
3. Right-click hold and release Microphone (Realtek High Definition Audio) and
make sure the item is not disabled.
4. Double-click Microphone (or select Properties from the right-click menu).
5. Click Levels (tab), and adjust the Microphone and Microphone Boost sliders to
the level required.
6. Click OK and close the control panels.
Right-click
