  • Page 1 User Manual MAX-17...

  • Page 2: Notice

    Notice The information in this user’s manual is protected by copyright laws, all parts of this manual, including the products and software described in it, can not be reproduced, transmitted, transcribed, stored in a retrieval system, nor translated into any language. THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS OR OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Notice ...................... 2 Preface ....................5 1.1 Regulations Information..............6 1.2 Safety Instructions ................9 1.3 Important Warranty Void Notice ............10 1.4 Release History ................11 Getting to know the basics ..............12 2.1 Product Specification ............... 13 2.2 Preparing your Computer ...............
  • Page 4 4.1 About BIOS Setup ................35 4.1.1 When to Use BIOS Setup ? ............35 4.1.2 How to Run BIOS Setup ? ............35 4.2 BIOS Setup Menu................36 4.2.1 Main Menu ..................37 4.2.2 Advanced Menu ................39 4.2.3 Security Menu................41 4.2.4 Boot Menu ..................

  • Page 5: Preface

    Chapter 1 Preface English Notebook Manual...

  • Page 6: Regulations Information

    1.1 Regulations Information CE compliance ¤ This device is classed as a technical information equipment (ITE) in class B and is intended for use in living room and office. The CE-mark approves the conformity by the EU-guidelines: - EMC Directive 2014/30/EU, - Low Voltage Directive 2014/35/EU(equals A2 : 2013) , - RF Directive 2014/53/EU The unit can be operated at an ambient temperature of max.
  • Page 7 FCC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 8 RF Exposure Information(SAR) This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Commu- nications Commission of the U.S. Government. The exposure standard employs a unit of measurement known as the Specific Absorption Rate, or SAR.

  • Page 9: Safety Instructions

    1.2 Safety Instructions Do not apply heavy pressure to the computer or subject it to any form of strong impact as this can damage the computer's components or otherwise cause it to malfunction. Never cover or block the air vents including those located at the base of the computer.

  • Page 10: Important Warranty Void Notice

    NOTE: Upgrading memory and/or storage can be easily accessed and modified on your MAX-17. However, modifying your thermals is NOT worth the serious risk of voiding your warranty or more importantly damaging your PC. An accidental bend of the heatsink or incorrect torque of the screws would be counteractive to the advanced compound you apply.

  • Page 11: Release History

    1.4 Release History Version Date Revision Initial release 11/2019 CPU & GPU Refresh 03/2020 English Notebook Manual...

  • Page 12: Getting To Know The Basics

    Chapter 2 Getting to know the basics English Notebook Manual...

  • Page 13: Product Specification

    2.1 Product Specification This User’s Manual provides technical information of instructions and illustrations on how to operate this notebook for the customer. Please read this manual carefully before using this notebook. ·Physical Characteristic Dimension  391.4*260.8*19.1~20.0mm 2kg+/-5% ·CPU Support Processor ...
  • Page 14 ·I/O Port DC-in USB 3.1 X 2 (Gen1) USB 3.1 X 1 (Gen2) USB type C 3.1 (TBT3) X 1 RJ45 HDMI Audio out & Mic in USB3.0 Interface Card reader -Support Micro SD /SDHC/SDXC card -SDCard support up to UHS-I ·Audio Audio Codec ...
  • Page 15 ·Input Keyboard  Membrane KB(333X104mm) travel=1.4mm backlight = 4 zone RGB Pointing Device  Glass Precision Touchpad Outline: 130.0*72.5mm +/- 0.15mm ·Communication Port  *RTL8111GS-CG *Supports 10/100/1000 Mb/Sec *PCI-E interface *DSM (Deep sleep mode) support Wireless LAN +BT  *M.2 2230 w/ CNVI interface *IEEE802.11 a/b/g/n/+ac support ·Webcam Infrared capability for facial recognition camera...
  • Page 16 ·Power AC Adapter  Automatic Voltage adjustment between 100 and 240V AC 50/60Hz, 230 Watts , (19.5V/11.8A) 3 Pins Battery Options  Li-polymer battery, soft pack, 4-cell (4100mAh) 62.32 Wh Li-polymer battery, soft pack, 6-cell (7900mAh) 91.24 Wh CAUTION: MODEL IS DESIGNED TO USE WITH THE DC INPUT: 230 Watts , (19.5V/11.8A) - THE USE OF ANYTHING LOWER CAN CAUSE DAMAGE TO HARDWARE English...

  • Page 17: Preparing Your Computer

    2.2 Preparing your Computer Connect the AC adapter’s DC output plug to the DC IN jack. The display panel can be opened to a wide range of angles for optimal viewing. Press the power button to turn on your notebook computer. English Notebook Manual...

  • Page 18: Product Overview

    2.3 Product Overview Please become familiar with each component before you operate the computer. Top-Open View NOTE: The product’s color/ LED color, I/O port, indicator location, and specifi- cation will depend upon the actually shipping product. English Notebook Manual...
  • Page 19 Camera Status LED The Camera Status LED shows the Camera status. Camera A device that allows you to record video or take photographs with your computer. Infrared capability for facial recognition camera can be used to identify and authenticate user to unlock notebook, conduct payment and other security functions.
  • Page 20 Power Button Press this button to turn the computer's power on or off. Power ON: White Suspend: White, Slow / Smooth, Blinking White (3Sec/Cycle) Power Off: OFF Office/Game/Beast Mode Switch On screen display. Office mode: Off (default) Gaming mode: White LED Half Meter Beast mode: White LED Full Meter Caps Lock Status LED Default: ON (White)
  • Page 21 Right Side View Card Reader Insert Memory Card. USB3.0 Interface -Support Micro SD /SDHC/SDXC card -SDCard supports up to UHS-I USB Port (USB 3.1) Connects an USB device (such as USB Zip drive, keyboard or mouse) into this jack. With charging function. Vents The thermal vents are designed to cool the internal components and avoid overheating.
  • Page 22 Left Side View Kensington® Lock Port To be secured using Kensington® Lock Port security products. Vents The thermal vents are designed to cool the internal components and avoid overheating. USB Port (USB 3.1 support BC 1.2 ) Connects an USB device (such as USB Zip drive, keyboard or mouse) into this jack.
  • Page 23 Bottom Side View NOTE : The product’s thermal vent image can vary based on GPU configuration. Vents The thermal vents are designed to cool the internal components and avoid overheating. Speaker English Notebook Manual...
  • Page 24 RAM / SSD / WLAN Compartment View BATTERY 62WHr BATTERY 91WHr English Notebook Manual...
  • Page 25 Front Side View Light bar Smart lighting color control of light bar. English Notebook Manual...
  • Page 26 Back Side View Vents The thermal vents are designed to cool the internal components and avoid overheating. Thunderbolt 3 (USB Type C 3.1) Thunderbolt™ 3 technology is 8x faster than USB 3.0 and provides 4x more video bandwidth than HDMI 1.41 helping you work and play more efficiently.

  • Page 27: Getting Started

    Chapter 3 Getting started English Notebook Manual...

  • Page 28: Ac Adapter

    If damage is determined to have been caused by utilization of an unauthorized power supply, it will not be protected under warranty. Eluktronics does offer additional adapters for sale if needed. DC IN CAUTION: The use of inferior extension cords may result in damage to your notebook.

  • Page 29: Knowing The Keyboard

    3.2 Knowing the Keyboard The following defines the colored hot keys on the Keyboard. The colored commands can only be accessed by first pressing and holding the function key while pressing a key with a colored command. NOTE: The number of keys available on your keyboard will depend on the country/region in which the keyboard was designed and built.

  • Page 30: For Keyboard Users

    3.2.1 For keyboard users To activate these functions, press the hot key associated with the desired function as shown below: Function Keys Keypad Function Description Press this key combination (Fn+F1) Suspend: to enter sleep mode. Windows Press this key combination (Fn+F2) Windows to turn Lock/On .
  • Page 31 Function Keys Keypad Function Description Keyboard Press this key combination (Fn+F6) Brightness Keyboard to decrease brightness of down: Keyboard Press this key combination (Fn+F7) Brightness Keyboard. to increase brightness of Press this key combination (Fn+F8) MUTE: to enter MUTE mode. Press this key combination (Fn+F9) Volume to enter Volume down mode.
  • Page 32 Function Keys Keypad Function Description Search Press this key combination (Windows Charm : logo key+Q) to open the search (Optional) charm and search apps. Settings Press this key combination (Windows Charm : logo key+I) to open the settings (Optional) charm. Share Press this key combination (Windows Charm :...

  • Page 33: Using The Touchpad / Clickpad

    3.3 Using the touchpad / clickpad The touchpad / clickpad is a rectangular electronic panel located just below your keyboard. Click twice left corner will open or close (Green light) touchpad functionality.You can use the static-sensitive panel of the touchpad / clickpad and slide it to move the cursor. You can use the buttons below the touchpad as left and right mouse buttons.

  • Page 34: Bios Setup

    Chapter 4 BIOS setup English Notebook Manual...

  • Page 35: About Bios Setup

    4.1 About BIOS Setup 4.1.1 When to Use BIOS Setup ? You may need to run the BIOS Setup when: · An error message appears on the screen during the system booting up and is requested to run SETUP. · You want to change the default settings for customized features.

  • Page 36: Bios Setup Menu

    4.2 BIOS Setup Menu Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. Select the tags to enter the other menus. Main Menu Show system overview about memory size and setting of system time and date. Advanced Menu To select the XD feature enable or disable XD feature only work with Intel platform + Windows.

  • Page 37: Main Menu

    4.2.1 Main Menu ·System Time This item allows you to set the system time. There is a small internal (CMOS) battery which is designed to maintain your system clock. It is designed to maintain time even when the PC is powered down or in sleep mode. The time format is [hour:minute:second].
  • Page 38 Day of the week, from Sun to Sat, which is determined by BIOS (read-only). The month from 01 (January) to 12 Month (Month) (December). Date (Date) The date from 01 to 31. Year (Year) The year can be adjusted by users. ·Total Memory This allows you to see the total amount of memory.

  • Page 39: Advanced Menu

    4.2.2 Advanced Menu English Notebook Manual...
  • Page 40 Wake From Sleep(S3) With USB Devices: • Enable/Disable wake from sleep(S3) with USB devices Serial ATA HDD • It will show AHCI SATA HDD info. ·NVMe Device It will show NVMe Device info. ·Intel Virtualization Technology When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology.

  • Page 41: Security Menu

    4.2.3 Security Menu · Thunderbolt Security Level [User Authorization / Secure Connect/ Display Port only / USB Docking Only / Unknow Status] ·Change Administrator Password When this item is selected, a message box shall appear on the screen as below: Enter New Password Type a maximum of 20-digit password and press [Enter].
  • Page 42 Select Change User Password to give or to abandon password setting same as Change Administrator Password item above. Note that Administrator Password field allows users to enter and change the settings of the BIOS SETUP UTILITY, while User Password field only allows users to enter the BIOS SETUP UTILITY without having the authorization to make any change.

  • Page 43: Boot Menu

    4.2.4 Boot Menu ·Boot Configuration Configure Settings during System Boot. ·LAN Remote Boot [Disable]: Boot from LAN or not. ·Set Boot Priority (1st/2nd/3rd/..Boot) Specifies the boot sequence from the available devices. A device enclosed in parenthesis has been disabled in the corresponding type menu.

  • Page 44: Exit Menu

    4.2.5 Exit Menu ·Save Changes and Reset Exit system setup after saving the changes.F4 key can be used for this operation. ·Discard Changes and Exit Exit system setup without saving any changes. ESC key can be used for this operation. ·Restore Defaults Restore/Load Defaults values for all the setup options.
