User Manual
THINN-15

Advertisement

Table of Contents
loading

Related Manuals for Eluktronics THINN-15

Summary of Contents for Eluktronics THINN-15

  • Page 1 User Manual THINN-15...

  • Page 2: Notice

    Notice The information in this user’s manual is protected by copyright laws, all parts of this manual, including the products and software described in it, can not be reproduced, transmitted, transcribed, stored in a retrieval system, nor translated into any language. THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS OR OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Notice ...................... 2 Preface ....................5 1.1 Regulations Information..............6 1.2 Safety Instructions ................9 1.3 Important Warranty Void Notice ............10 1.4 Release History ................11 Getting to know the basics ..............12 2.1 Product Specification ............... 13 2.2 Preparing your Computer ...............
  • Page 4 4.1 About BIOS Setup ................34 4.1.1 When to Use BIOS Setup ? ............34 4.1.2 How to Run BIOS Setup ? ............34 4.2 BIOS Setup Menu................36 4.2.1 Main Menu ..................36 4.2.2 Advanced Menu ................38 4.2.3 Security Menu................40 4.2.4 Boot Menu ..................

  • Page 5: Preface

    Chapter 1 Preface English Notebook Manual...

  • Page 6: Regulations Information

    1.1 Regulations Information CE compliance ¤ This device is classed as a technical information equipment (ITE) in class B and is intended for use in living room and office. The CE-mark approves the conformity by the EU-guidelines: - EMC Directive 2014/30/EU, - Low Voltage Directive 2014/35/EU(equals A2 : 2013) , - RF Directive 2014/53/EU The unit can be operated at an ambient temperature of max.
  • Page 7 FCC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 8 FCC Information This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Commu- nications Commission of the U.S. Government. The exposure standard employs a unit of measurement known as the Specific Absorption Rate, or SAR.

  • Page 9: Safety Instructions

    1.2 Safety Instructions Do not apply heavy pressure to the computer or subject it to any form of strong impact as this can damage the computer's components or otherwise cause it to malfunction. Never cover or block the air vents including those located at the base of the computer.

  • Page 10: Important Warranty Void Notice

    WARNING: Damage caused by any modification to the thermals performed by anyone other than Eluktronics will not be covered under warranty. As a standard, the THINN-15 is produced with an advanced stock thermal system which has excellent heat dissipation. It is strongly discouraged to attempt any thermal changes on your own.

  • Page 11: Release History

    1.4 Release History Version Date Revision Initial release 07/2020 English Notebook Manual...

  • Page 12: Getting To Know The Basics

    Chapter 2 Getting to know the basics English Notebook Manual...

  • Page 13: Product Specification

    2.1 Product Specification This User’s Manual provides technical information of instructions and illustrations on how to operate this notebook for the customer. Please read this manual carefully before using this notebook. ・Physical Characteristic Dimension  356.4*233.73*16.8 mm 1.55kg +/- 5% ・CPU Support Processor ...
  • Page 14 ・I/O Port DC-in USB 3.1 X 2 (Gen1) USB type C 3.1 X 1 (Gen1) USB 2.0 X 1 RJ45 HDMI Audio out & Mic in Card reader ・Audio Audio Codec  *Azalia standard support / *D3 mode support Speaker/MIC ...
  • Page 15 ・Input Keyboard  Membrane KB, backlight support, Traveling: 1.4mm Pointing Device  TDA1470 (114.5*70*0.8mm) ・Communication Port  *Supports 10/100/1000 Mb/Sec *DSM (Deep sleep mode) support Wireless LAN +BT  *M.2 2230 w/ PCI-E interface (Intel WiFi 6 AX series) IEEE 802.11 a/b/g/n/ac/ax support. ・Webcam Infrared capability for facial recognition camera ...
  • Page 16 ・Power AC Adapter  Automatics Voltage adjustment between 100 and 240VAC 50/60Hz, 90 Watts ( (19V / 4.74A) Battery  Li-polymer battery, soft pack, 6cells (3S2P 7900mAh) 91.24 Wh CAUTION: MODEL IS DESIGNED TO USE WITH DC INPUT: 90 Watts ( (19V / 4.74A) English Notebook Manual...

  • Page 17: Preparing Your Computer

    2.2 Preparing your Computer Connect the AC adapter’s DC output plug to the DC IN jack. The display panel can be opened to a wide range of angles for optimal viewing. Press the power button to turn on your notebook computer. English Notebook Manual...

  • Page 18: Product Overview

    2.3 Product Overview Please become familiar with each component before you operate the computer. Top-Open View English Notebook Manual...
  • Page 19 Camera Status LED The Camera Status LED shows the Camera status. Camera A device that allows you to record video or take photographs with your computer. Infrared capability for facial reconition camera Can be used to identify and authenticate user to unlock notebook, conduct payment and other security functions.
  • Page 20 Charging & Battery indicator Charging(Power ON): White Charging(Power Off): White Battery Low (<6%): White (3 Sec/Cycle) Charging finish : OFF Battery Full: OFF Keyboard keyboard Membrane (The keyboard legend will depend on the spec / region) Touchpad/Click pad Touch-sensitive pointing device which functions like the mouse. English Notebook Manual...
  • Page 21 Right Side View USB Port (USB Type C) Supports 90W Type-C Adaptor 19V/4.7A Connects an USB Type C device such as keyboard or mouse into this jack. USB Ports Connects an USB device. (such as USB Zip drive, keyboard or mouse) into this jack. HDMI port Connected to the screen, or home theater system.
  • Page 22 Left Side View Kensington® Lock Port To be secured using Kensington® Lock Port security products. Network Jack This jack lets you connect to a LAN. USB Ports Connects an USB device. (such as USB Zip drive, keyboard or mouse) into this jack. Audio Out Jack Connects amplified speakers, headphones or microphone into this jack.
  • Page 23 Bottom Side View Vents The thermal vents are designed to cool the internal components and avoid overheating. Speakers English Notebook Manual...
  • Page 24 RAM / SSD / WLAN Compartment View English Notebook Manual...
  • Page 25 Front Side View Back Side View Vents The thermal vents are designed to cool the internal components and avoid overheating. English Notebook Manual...

  • Page 26: Getting Started

    Chapter 3 Getting started English Notebook Manual...

  • Page 27: Ac Adapter

    3.1 AC Adapter It is recommended to connect the AC adapter and use the AC power for your first use to allow the battery to completely charge. Connect the AC adapter when you need to charge the battery or you want to operate from AC power.

  • Page 28: Knowing The Keyboard

    3.2 Knowing the Keyboard The following defines the colored hot keys on the Keyboard. The colored commands can only be accessed by first pressing and holding the function key while pressing a key with a colored command. English Notebook Manual...

  • Page 29: For Keyboard Users

    3.2.1 For keyboard users To activate these functions, press the hot key associated with the desired function as below : Function Keys Keypad Function Description Press this key combination (Fn+F1) Suspend: to enter sleep mode. Windows Press this key combination (Fn+F2) Windows to turn Lock/On .
  • Page 30 Function Keys Keypad Function Description Keyboard Press this key combination (Fn+F6) Brightness Keyboard to decrease brightness of down: Keyboard Press this key combination (Fn+F7) Brightness Keyboard. to increase brightness of Press this key combination (Fn+F8) MUTE: to enter MUTE mode. Press this key combination (Fn+F9) Volume to enter Volume down mode.
  • Page 31 Function Keys Keypad Function Description Search Press this key combination (Windows Charm : logo key+Q) to open the search (Optional) charm and search apps. Settings Press this key combination (Windows Charm : logo key+I) to open the settings (Optional) charm. Share Press this key combination (Windows Charm :...

  • Page 32: Using The Touchpad / Clickpad

    3.3 Using the touchpad / clickpad The touchpad / clickpad is a rectangular electronic panel located just below your keyboard. Tap the left corner twice to enable or disable (White light) touchpad functionality. You can use the static-sensitive panel of the touchpad / clickpad and slide it to move the cursor. You can use the buttons below the touchpad as left and right mouse buttons.

  • Page 33: Bios Setup

    Chapter 4 BIOS setup English Notebook Manual...

  • Page 34: About Bios Setup

    4.1 About BIOS Setup 4.1.1 When to Use BIOS Setup ? You may need to run the BIOS Setup when: ・ An error message appears on the screen during the system booting up and is requested to run SETUP. ・ You want to change the default settings for customized features.

  • Page 35: Bios Setup Menu

    4.2 BIOS Setup Menu Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. Select the tags to enter the other menus. Main Menu Show system overview about memory size and setting of system time and date. Advanced Menu To select the XD feature enable or disable XD feature only work with Intel platform + Windows.

  • Page 36: Main Menu

    4.2.1 Main Menu ・System Time This item allows you to set the system time. There is a small internal (CMOS) battery which is designed to maintain your system clock. It is designed to maintain time even when the PC is powered down or in sleep mode. The time format is [hour:minute:second].
  • Page 37 Day of the week, from Sun to Sat, which is determined by BIOS (read-only). The month from 01 (January) to 12 Month (Month) (December). Date (Date) The date from 01 to 31. Year (Year) The year can be adjusted by users. ・Total Memory This allows you to see the total amount of memory.

  • Page 38: Advanced Menu

    4.2.2 Advanced Menu Wake on LAN • Enable/Disable integrated LAN to wake the system. Serial ATA HDD • It will show AHCI SATA HDD info. ・NVMe Device It will show NVMe Device info. English Notebook Manual...
  • Page 39 ・Intel Virtualization Technology When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. ・RAID mode reminder Please update strip size in BIOS to 128K in order for RAID to optimize performance. English Notebook Manual...

  • Page 40: Security Menu

    4.2.3 Security Menu ・Change Administrator Password When this item is selected, a message box shall appear on the screen as below: Enter New Password Type a maximum of 20-digit password and press [Enter]. The password typed now will replace any previously set password from CMOS memory.
  • Page 41 Select Change User Password to give or to abandon password setting same as Change Administrator Password item above. Note that Administrator Password field allows users to enter and change the settings of the BIOS SETUP UTILITY, while User Password field only allows users to enter the BIOS SETUP UTILITY without having the authorization to make any change.

  • Page 42: Boot Menu

    4.2.4 Boot Menu ・Boot Configuration Configure Settings during System Boot. ・LAN Remote Boot [Disable]: Boot from LAN or not. ・Set Boot Priority (1st/2nd/3rd/..Boot) Specifies the boot sequence from the available devices. A device enclosed in parenthesis has been disabled in the corresponding type menu.

  • Page 43: Exit Menu

    4.2.5 Exit Menu ・Save Changes and Reset Exit system setup after saving the changes.F4 key can be used for this operation. ・Discard Changes and Exit Exit system setup without saving any changes. ESC key can be used for this operation. ・Restore Defaults Restore/Load Defaults values for all the setup options.
