  • Page 1 User Manual PROMETHEUS XVII...
  • Page 2: Notice

    THX and the THX logo are trademarks of THX LTD. in the U.S. and/or other countries. Eluktronics and the Eluktronics logo are trademarks of ELUKTRONICS, INC in the U.S. and/or other countries. THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Notice ...................... 2 Preface ....................5 1.1 Regulations Information..............6 1.2 Safety Instructions ................10 1.3 Important Warranty Void Notice............11 1.4 Release History ................12 Getting to know the basics ..............13 2.1 Product Specification ............... 14 2.2 Preparing your Computer ...............
  • Page 4 4.1 About BIOS Setup ................36 4.1.1 When to Use BIOS Setup ? ............36 4.1.2 How to Run BIOS Setup ? ............36 4.2 BIOS Setup Menu................38 4.2.1 Main Menu ..................38 4.2.2 Advanced Menu ................40 4.2.3 Security Menu................41 4.2.4 Boot Menu ..................
  • Page 5: Preface

    Chapter 1 Preface English Notebook Manual...
  • Page 6: Regulations Information

    1.1 Regulations Information CE compliance ¤ This device is classed as a technical information equipment (ITE) in class B and is intended for use in living room and office. The CE-mark approves the conformity by the EU-guidelines: - EMC Directive 2014/30/EU, - Low Voltage Directive 2014/35/EU(equals A2 : 2013) , - RF Directive 2014/53/EU SAR/DAS refers to the rate at which the body absorbs RF energy.
  • Page 7 Rechargeable Battery Notice Do NOT 1. Throw into fire or a hot oven, or mechanically crush or cut a battery 2. Throw or immerse into water 3. Heat to more than 60°C 4. Attempt to repair or disassemble 5. Leave in an extremely low air pressure environment 6.
  • Page 8 FCC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 9 RF Exposure Information(SAR) This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Commu- nications Commission of the U.S. Government. The exposure standard employs a unit of measurement known as the Specific Absorption Rate, or SAR.
  • Page 10: Safety Instructions

    1.2 Safety Instructions Do not apply heavy pressure to the computer or subject it to any form of strong impact as this can damage the computer's components or otherwise cause it to malfunction. Never cover or block the air vents including those located at the base of the computer.
  • Page 11: Important Warranty Void Notice

    WARNING: Damage caused by any modification to the thermal system performed by anyone other than Eluktronics will not be covered under warranty. As a standard, the Prometheus XVII is produced with an advanced thermal design which provides excellent heat dissipation. It is strongly discouraged to attempt any thermal changes on your own.
  • Page 12: Release History

    1.4 Release History Version Date Revision Initial release 1/2021 English Notebook Manual...
  • Page 13: Getting To Know The Basics

    Chapter 2 Getting to know the basics English Notebook Manual...
  • Page 14: Product Specification

    2.1 Product Specification This User’s Manual provides technical information of instructions and illustrations on how to operate this notebook for the customer. Please read this manual carefully before using this notebook. ・Physical Characteristic Dimension  392.9*260*24.9mm 2.55kg +/- 5% ・CPU Supported Processor ...
  • Page 15 ・I/O Port DC-in USB Type A @Right side x2: USB 3.1 (Gen1) X2 (Power off mode support USB power, but w/o bc1.2 protocol ) USB Type A @Left side x1: USB 3.1 (Gen2) X1 (Power off mode support USB power, but w/o bc1.2 protocol ) USB Type C x1 @Rear side x1: USB 3.1 Gen2 + DP (Power off mode support USB power, but w/o bc1.2 protocol ) RJ45...
  • Page 16 ・Webcam Infrared capability for facial recognition camera  1. IR Camera with two dedicated microphones ・Communication Port  *Supports 10/100/1000/2500Mb/sec *PCI-E interface *Power Down Mode D1~D3 support *PCIe ASPM L1.1, L1.2 support *UI for network package management Wireless LAN +BT ...
  • Page 17 ・Input Keyboard  Membrane KB 340*109.2*3.6mm/single zone RGB Backlight Pointing Device  TDB5297 Outline: 154*100* 0.6 mm AA: 150*94.6 mm Mylar Enable/Disable area :10mmx10mm Palm Rejection: Supported ・Power AC Adapter  Automatic Voltage adjustment between 100 and 240VAC 50/60Hz, 230 Watts (19.5V/11.8A), 3 Pins Battery ...
  • Page 18: Preparing Your Computer

    2.2 Preparing your Computer Connect the AC adapter’s DC output plug to the DC IN jack. The display panel can be opened to a wide range of angles for optimal viewing. Press the power button to turn on your notebook computer. English Notebook Manual...
  • Page 19: Product Overview

    2.3 Product Overview Please become familiar with each component before you operate the computer. Top-Open View English Notebook Manual...
  • Page 20 Camera Status LED The Camera Status LED helps you see whenever the camera is powered on. Upright Camera A device that allows you to record video or take photographs with your computer. This used to be located at the bottom of the screen and was great for realizing it's time to cut your nose hair.
  • Page 21 Power/Battery/Caps Lock LED Indicator Power ON: White Suspend: Blinking White Power Off: OFF Charging : Blinking White Battery Low (<6%): Blinking Amber Charging finish : OFF Caps Lock Status LED Default: ON (White) RGB Light bar Smart lighting color control of your Light Bar. Keyboard The keyboard provides keys with comfortable travel Touchpad/Click pad...
  • Page 22 Right Side View Card Reader USB3 interface, SD/SDHC/SDXC, UHS-I speed Connecter: Full SD size USB Port (Gen1) Connects a USB device (such as a Flash drive, keyboard or mouse) into this jack. With charging function. Vents The thermal vents are designed to cool the internal components and avoid overheating.
  • Page 23 Left Side View Vents The thermal vents are designed to cool the internal components and avoid overheating. USB Port (Gen2) Connects a USB device (such as a USB flash drive, keyboard or mouse) into this jack. With charging function. Mic-In Jack Connect a microphone into this jack.
  • Page 24 Bottom Side View Vents The thermal vents are designed to cool the internal components and avoid overheating. Speakers Enjoy some tunes. CAUTION: To prevent the possibility of heat-related injuries or overheating the computer, it is recommended to use the computer on a hard, flat surface. English Notebook Manual...
  • Page 25 Compartment View RAM  SSD   RAM  SSD(Option)   4 Cell BATTERY English Notebook Manual...
  • Page 26 Front Side View Back Side View Vents The thermal vents are designed to cool the internal components and avoid overheating. Kensington® Lock Port To be secured using Kensington® Lock Port security products. English Notebook Manual...
  • Page 27 USB Type-C Port USB Type-C / DP / USB Power Delivery - Does not support charging of the PC. HDMI port Connect to an external monitor, or home theater system. Network Jack This jack lets you connect to a LAN. Power Connector Connects the AC adapter into this connector.
  • Page 28: Getting Started

    Chapter 3 Getting started English Notebook Manual...
  • Page 29: Ac Adapter

    3.1 AC Adapter It is recommended to connect the AC adapter and use the AC power for your first use to allow the battery to completely charge. Connect the AC adapter when you need to charge the battery or you want to operate from AC power.
  • Page 30: Knowing The Keyboard

    3.2 Knowing the Keyboard The following defines the colored hot keys on the Keyboard. The colored commands can only be accessed by first pressing and holding the function key while pressing a key with a colored command. English Notebook Manual...
  • Page 31: Keyboard Functions

    3.2.1 Keyboard Functions To activate these functions, press the hot key associated with the desired function as below : Function Keys Keypad Function Description Press this key combination (Fn+F1) Suspend: to enter sleep mode. Windows Press this key combination (Fn+F2) Windows to turn Lock/On .
  • Page 32 Function Keys Keypad Function Description Keyboard Press this key combination (Fn+F6) Brightness Keyboard to decrease brightness of down: Keyboard Press this key combination (Fn+F7) Brightness Keyboard. to increase brightness of Press this key combination (Fn+F8) MUTE: to enter MUTE mode. Press this key combination (Fn+F9) Volume to enter Volume down mode.
  • Page 33 Function Keys Search For a full list of Windows keyboard Charm : shortcuts, please visit the Microsoft (Optional) official website https://support.microsoft.com/en-us/ English Notebook Manual...
  • Page 34: Using The Touchpad / Clickpad

    3.3 Using the touchpad / clickpad The touchpad / clickpad is a rectangular electronic device located just below your keyboard. This is a very large touchpad and is the first to offer the ability to disable half of the touchpad to better assist you with typing based on how your hands may lie.
  • Page 35: Bios Setup

    Chapter 4 BIOS setup English Notebook Manual...
  • Page 36: About Bios Setup

    The screenshots and setting options in this chapter are for your references only. The actual setting screens and options on your notebook will likely be different because the CEO at Eluktronics is the man and he tries his best to find ways to safely provide a more exciting PC experience for you.
  • Page 37: Bios Setup Menu

    4.2 BIOS Setup Menu Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. Select the tags to enter the other menus. Main Menu Shows the system overview about memory size and the system time and date. This page contains your BIOS and EC version which may be something our support staff will ask you for in the event you're encountering a technical issue.
  • Page 38: Main Menu

    4.2.1 Main Menu ・System Time This item allows you to set the system time. There is a small internal (CMOS) battery which is designed to maintain your system clock. It is designed to maintain time even when the PC is powered down or in sleep mode. The time format is [hour:minute:second].
  • Page 39 Day of the week, from Sun to Sat, which is determined by BIOS (read-only). The month from 01 (January) to 12 Month (Month) (December). Date (Date) The date from (01) to (31). Year The year can be adjusted. ・Total Memory This allows you to see the total amount of memory.
  • Page 40: Advanced Menu

    4.2.2 Advanced Menu ・NVMe Device This presents your NVMe Device info. ・Wake on LAN/WLAN Enable/Disable from Modern Standby(S0i3) with LAN/WLAN Device English Notebook Manual...
  • Page 41: Security Menu

    4.2.3 Security Menu ・Change Administrator Password When this item is selected, a message box shall appear on the screen as below: Enter New Password Type a maximum of 20-digit password and press [Enter]. The password typed now will replace any previously set password from CMOS memory.
  • Page 42 Select Change User Password to give or to abandon password setting same as Change Administrator Password item above. Note that Administrator Password field allows users to enter and change the settings of the BIOS SETUP UTILITY, while User Password field only allows users to enter the BIOS SETUP UTILITY without having the authorization to make any changes.
  • Page 43: Boot Menu

    4.2.4 Boot Menu ・Boot Configuration Configure Settings during System Boot. ・Set Boot Priority (1st/2nd/3rd/..Boot) Specifies the boot sequence from the available devices. A device enclosed in parenthesis has been disabled in the corresponding type menu. ・ Hard Disk Drive / USB HardDisk Drive Specifies the Boot Device Priority sequence.
  • Page 44: Exit Menu

    4.2.5 Exit Menu ・Save Changes and Reset Exit system setup after saving the changes. F4 key can be used for this operation. ・Discard Changes and Exit Exit system setup without saving any changes. ESC key can be used for this operation. ・Restore Defaults Restore/Load Defaults values for all the setup options.
