Eluktronics MECH-15HS User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Eluktronics MECH-15HS

Advertisement

Table of Contents
loading

Related Manuals for Eluktronics MECH-15HS

Summary of Contents for Eluktronics MECH-15HS

  • Page 1 User Manual Eluktronics MECH-15HS...

  • Page 2: Notice

    Notice The information in this user’s manual is protected by copyright laws, all parts of this manual, including the products and software described in it, can not be reproduced, transmitted, transcribed, stored in a retrieval system, nor translated into any language. THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS OR OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Notice ...................... 2 Preface ....................5 1.1 Regulations Information..............6 1.2 Safety Instructions ................7 1.3 Conventions for this Manual .............. 8 1.4 Release History ................. 9 Getting to know the basics ..............10 2.1 Product Specification ............... 11 2.2 Preparing your Computer ...............
  • Page 4 4.1 About BIOS Setup ................33 4.1.1 When to Use BIOS Setup ? ............33 4.1.2 How to Run BIOS Setup ? ............33 4.2 BIOS Setup Menu................34 4.2.1 Main Menu ..................36 4.2.2 Advanced Menu ................38 4.2.3 Security Menu................40 4.2.4 Boot Menu ..................

  • Page 5: Preface

    Chapter 1 Preface Notebook Manual...

  • Page 6: Regulations Information

    1.1 Regulations Information CE compliance ¤ This device is classed as a technical information equipment (ITE) in class B and is intended for use in living room and office. The CE-mark approves the conformity by the EU-guidelines: - EMC Directive 2014/30/EU, - Low Voltage Directive 2014/35/EU(equals A2 : 2013) , - R&TTE Directive 1999/5/EC The unit can be operated at an ambient temperature of max.

  • Page 7: Safety Instructions

    1.2 Safety Instructions Do not apply heavy pressure to the computer or subject it to any form of strong impact as this can damage the computer's components or otherwise cause it to malfunction. Never cover or block the air vents including those located at the base of the computer.

  • Page 8: Conventions For This Manual

    1.3 Conventions for this Manual CAUTION : This message contains important information that must be followed for safe operation. NOTE : This message contains information for special situations. Notebook Manual...

  • Page 9: Release History

    1.4 Release History Version Date Revision Initial release 09.2017 Notebook Manual...

  • Page 10: Getting To Know The Basics

    Chapter 2 Getting to know the basics Notebook Manual...

  • Page 11: Product Specification

    2.1 Product Specification This User’s Manual provides technical information of instructions and illustrations on how to operate this notebook for the customer. Please read this manual carefully before using this notebook. ・Physical Characteristic Dimension  386.9 x 270 x 35.6mm; Weight: 3.0Kg ・CPU Support Processor ...
  • Page 12 ・I/O Port DC-in 2.0 x 2 + 3.0 x 3 3.1 x 1 (Type C, no Audio and Video support) RJ45 Card Reader x 1 (2 in 1 Card reader connector type) DP port HDMI Audio out & Mic in x 1 (FAN full speed ON/OFF) Quick launch button ・Audio...
  • Page 13 ・Input Keyboard  15.6” Pointing Device  PS2 Touch Pad with 2 buttons 92X52mm ・Display  15.6" FHD, 16:9, Glare or AG ・Communication Port  10/100/1000 Mb/Sec Wireless LAN  M.2 2230 w/ PCIE interface IEEE802.11b/g/n support; AC mode support ・Webcam HD webcam ...
  • Page 14 ・Power AC Adapter  Automatics Voltage adjustment between 100 and 240VAC 50/60Hz, 230 Watts (19.5V/11.8A), 3 Pins Battery  Li-ion 18650 Battery, hard pack, Removable, 6 cells (High power 3S2P 4300mAh ; or Normal 3S2P 4400mAh) CAUTION: MODEL IS DESIGNED TO USE WITH THE DC INPUT: 19.5V/11.8A Please use the genuine adapter based on the rating of your PC's model and BIOS.

  • Page 15: Preparing Your Computer

    2.2 Preparing your Computer Connect the AC adapter’s DC output plug to the DC IN jack. The display panel can be opened to a wide range of angles for optimal viewing. Press the power button to turn on your notebook computer. Notebook Manual...

  • Page 16: Product Overview

    2.3 Product Overview Please become familiar with each component before you operate the computer. Top-Open View NOTE: The product’s finish, color, I/O port, indicator location, and specification will depend upon the specific model which was advertised to be included. CAUTION:When you are not using the computer, keep the LCD- screen closed to protect it from dust.
  • Page 17 Webcam A device that allows you to record video or take photographs with your computer. Power Button Press this button to turn the computer's power on or off. Power indicator *Power ON: ON *Suspend: Slow / Smooth, Blinking Red *FAN full speed: ON *Power Off: OFF Charging &...
  • Page 18 Keyboard The keyboard provides keys with comfortable travel. Touchpad/Click pad Touch-sensitive pointing device which functions like the mouse. Left and right touchpad/Clickpad buttons The left and right buttons function like the left and right buttons on a standard mouse. Bottom Side View NOTE :The product’s thermal vent design may vary depending on the model and internal hardware in which you purchased.
  • Page 19 CAUTION: Your laptop generates heat while under heavy load. To avoid potential injury, do not place the laptop on any exposed body parts. Battery Lock 1 and 2 - Spring The spring battery lock 1 and 2 are used to keep the battery pack secured.
  • Page 20 If you intend to modify or upgrade your SSD, RAM or WLAN parts, please contact Eluktronics at support@Eluktronics.com. The use of unauthorized parts will not void your warranty. However, any aftermarket or third party part must be removed before requesting warranty assistance.
  • Page 21 Left Side View Right Side View Audio Out Jack Connects amplified speakers, headphones or microphone into this jack. Mic In Jack Connects amplified speakers, headphones or microphone into this jack. USB Ports Connects an USB device. (such as USB Zip drive, keyboard or mouse) into this jack. 2 in 1 Card Reader Insert Memory Card.
  • Page 22 Front Side View Stereo speakers Produce stereo sound. Back Side View Vents The thermal vents are designed to cool the internal components and avoid overheating. Power Connector Connects the AC adapter into this connector. Notebook Manual...
  • Page 23 HDMI port Supports high-definition digital video connections. Network Jack This jack allows you to connect to a Local Area Network (LAN) connection. Display Port Connected to the screen, or home theater system. USB Port Connects an USB device (such as USB Zip drive, keyboard or mouse) into this jack.

  • Page 24: Getting Started

    Chapter 3 Getting started Notebook Manual...

  • Page 25: Ac Adapter

    3.1 AC Adapter Please plug in the AC adapter for initial use of your notebook until your battery levels are verified to provide sufficient power. The AC adapter should be plugged back in as soon as your PC indicates the battery level is low. If the battery is continuously utilized past the point of indication of a low battery, it can affect the longevity of your battery.

  • Page 26: Knowing The Keyboard

    3.2 Knowing the Keyboard The following defines the colored hot keys on the Keyboard. The colored commands can only be accessed by first pressing and holding the function key while pressing a key with a colored command. NOTE: The number of keys available on your keyboard will depend on the country/region in which the keyboard was designed and built.

  • Page 27: For Keyboard Users

    3.2.1 For keyboard users To activate these functions, press the hot key associated with the desired function as below : Function Keys Keypad Function Description Press this key combination (Fn+F1) Suspend: to enter sleep mode. Press this key combination (Fn+F2) Home to turn Home Lock/On .
  • Page 28 Function Keys Keypad Function Description Keyboard Press this key combination (Fn+F6) Brightness Keyboard to decrease brightness of down: Keyboard Press this key combination (Fn+F7) Brightness Keyboard. to increase brightness of Press this key combination (Fn+F8) MUTE: to enter MUTE mode. Press this key combination (Fn+F9) Volume to enter Volume down mode.
  • Page 29 Function Keys Keypad Function Description Search Press this key combination (Windows Charm : logo key+Q) to open the search (Optional) charm and search apps. Settings Press this key combination (Windows Charm : logo key+I) to open the settings (Optional) charm. Share Press this key combination (Windows Charm :...

  • Page 30: Using The Touchpad / Clickpad

    3.3 Using the touchpad / clickpad The touchpad / clickpad is a rectangular electronic panel located just below your keyboard. You can use the static-sensitive panel of the touchpad / clickpad and slide it to move the cursor. You can use the buttons below the touchpad as left and right mouse buttons.

  • Page 31: Windows 10 Touchpad Usage

    3.3.1 Touchpad Usage Touch Pad Gesture Modern touchpad gesture: A modern touchpad should support the core touch gestures described in the following table. Item Gesture name Gesture left click/double click one finger move cursor tap+slide scroll/pan two finger pinch/zoom three finger multitasking gesture Notebook Manual...

  • Page 32: Bios Setup

    Chapter 4 BIOS setup Notebook Manual...

  • Page 33: About Bios Setup

    4.1 About BIOS Setup 4.1.1 When to Use BIOS Setup ? You may need to run the BIOS Setup when: ・ An error message appears on the screen during the system booting up and is requested to run SETUP. ・ You want to change the default settings for customized features. ・You want to reload the default BIOS settings.

  • Page 34: Bios Setup Menu

    4.2 BIOS Setup Menu Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. Select the tags to enter the other menus. Main Menu Show system overview about memory size,setting of system time and date. Advanced Menu To select the XD feature enable or disable XD feature only work with Intel platform + Windows.

  • Page 35: Main Menu

    4.2.1 Main Menu ・System Time This item allows you to set the system time. There is a small internal (CMOS) battery which is designed to maintain your system clock. It is designed to maintain time even when the PC is powered down or in sleep mode. The time format is [hour:minute:second].
  • Page 36 Day of the week, from Sun to Sat, which is determined by BIOS (read-only). The month from 01 (January) to 12 Month (Month) (December). Date (Date) The date from 01 to 31. Year (Year) The year can be adjusted by users. ・Total Memory This allows you to see the total amount of memory.

  • Page 37: Advanced Menu

    4.2.2 Advanced Menu Wake on LAN • Enable/Disable integrated LAN to wake the system. Serial ATA HDD • It will show AHCI SATA HDD info. Notebook Manual...
  • Page 38 ・NVMe Device Enable/Disable integrated NVMe to wake the system. ・Intel Virtualization Technology When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. ・RAID mode reminder Please update strip size in BIOS to 128K in order for RAID to optimize performance.

  • Page 39: Security Menu

    4.2.3 Security Menu ・Change Administrator Password When this item is selected, a message box shall appear on the screen as below: Enter New Password Type a maximum of 20-digit password and press [Enter]. The password typed now will replace any previously set password from CMOS memory.
  • Page 40 Select Change User Password to give or to abandon password setting same as Change Administrator Password item above. Note that Administrator Password field allows users to enter and change the settings of the BIOS SETUP UTILITY, while User Password field only allows users to enter the BIOS SETUP UTILITY without having the authorization to make any change.

  • Page 41: Boot Menu

    4.2.4 Boot Menu ・Boot Configuration Configure Settings during System Boot. ・LAN Remote Boot [Disable]: Boot from LAN or not. ・Set Boot Priority (1st/2nd/3rd/..Boot) Specifies the boot sequence from the available devices. A device enclosed in parenthesis has been disabled in the corresponding type menu.

  • Page 42: Exit Menu

    4.2.5 Exit Menu ・Save Changes and Reset Exit system setup after saving the changes.F4 key can be used for this operation. ・Discard Changes and Exit Exit system setup without saving any changes. ESC key can be used for this operation. ・Restore Defaults Restore/Load Defaults values for all the setup options.
