1.1 Hardware Description
1.1.1 NR-1100 Series
1.
Power button
2.
LED indicators: HDD
3.
USB 2.0 x1 (Support auto video backup)
4.
USB 2.0 x1
5.
Power connector
6.
USB 3.0 x 2
7.
DVI-I
8.
eSATA x 1
9.
HDMI x 1
10. Gigabit LAN
11. USB 2.0 x 2
12. Audio mic input (reserved)
13. Audio output (reserved)
Figure 1-1. Front & Rear View of NR-1100 Series
