LED on RJ-45 Connection at Rear Panel
LED LED Position
LAN1 Link/Activity
LAN2 (Right LED)
LAN1 Speed
LAN2 (Left LED)
*USB BACKUP will start and beep after 3 seconds user presses BACKUP button.
**To turn off NVR, user needs to press power button at least 2 seconds.
Note: Once users press reset button, configuration of Camera Setting, Recording
Settings, Event & Action Setting, E-Mail Settings, and Server Settings will reset to
default. It is advised to backup system configurations. For more information, refer to
detail information in user manual
LED/State
Off LAN Link is not established
Yellow LAN Link is established
Yellow Blinking LAN activity is occurring
Off 10Mbps connection or no connection
Green 100Mbps connection
Orange 1000Mbps connection
5.6.3 Save/Load Configuration.
10
Indicate
