MULTI
PURPOSE
SAW
500W
INSTRUCTION MANUAL
SPECIFICATIONS
Input:
500W
Voltage:
230-240V ~ 50Hz
No Load Speed:
500-3000 /min
Stroke Length:
12mm
Blade Fitment:
Universal
Cutting Capacity:
Timber 100mm
Aluminium 6mm
Mild Steel 3mm
Weight:
2.5kg
ozito.com.au
WHAT'S IN THE BOX
Multi-purpose Saw
Blades x 3
Hex Key
Spare Brushes
MSW-3000
Advertisement
Table of Contents
Related Manuals for Ozito MSW-3000
Summary of Contents for Ozito MSW-3000
- Page 1 Blades x 3 INSTRUCTION MANUAL SPECIFICATIONS Input: 500W Voltage: 230-240V ~ 50Hz Hex Key No Load Speed: 500-3000 /min Stroke Length: 12mm Blade Fitment: Universal Cutting Capacity: Timber 100mm Aluminium 6mm Mild Steel 3mm Weight: 2.5kg ozito.com.au Spare Brushes MSW-3000...
- Page 2 SETUP & PREPARATION KNOW YOUR PRODUCT MULTIPURPOSE SAW 1. FITTING BLADES 1 Universal Blade 4 Safety Lock-off Switch Before you make any adjustments, make sure the power cord 2 Front Handle 5 On/off Trigger is disconnected from the electricity supply. 3 Variable Speed Dial 6 Rear Handle with Sure Grip 1.
- Page 3 ONLY SUPPLY SUFFICIENT PRESSURE TO 1. Scroll through the variable ALLOW THE BLADE TO DO THE CUTTING. DO speed dial to select the NOT FORCE THE OPERATION. BLADES COULD BE appropriate speed for the DAMAGED IF EXCESSIVE PRESSURE IS APPLIED. material being cut. MSW-3000...
-
Page 4: Carbon Brushes
Always replace both carbon brushes at the same time. Or contact Ozito customer service Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the multipurpose saw by an unauthorised person or by Australia 1800 069 486 mishandling of the multipurpose saw. - Page 5 Model No. MSW-3000 24 25 26 27 31 32 35 36 10 11 12 13 14 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No.
- Page 6 Replace the extension Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and lead if damaged or defective.
- Page 7 • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO 0513 Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
