RECIPROCATING
SAW
850W
INSTRUCTION MANUAL
SPECIFICATIONS
Motor:
850W
No Load Speed:
800-3000spm
Stroke Length:
24mm
Blade Fitment:
Tool-free
Cutting Capacities:
Timber 210mm
Aluminium 20mm
Non Alloy Steel 10mm
Weight:
3.5kg
ozito.com.au
WHAT'S IN THE BOX
Reciprocating Saw
Timber Cutting Blade
Metal Cutting Blade
Kit Box
RSW-5100
Advertisement
Table of Contents
Related Manuals for Ozito RSW-5100
Summary of Contents for Ozito RSW-5100
- Page 1 Reciprocating Saw 850W Timber Cutting Blade INSTRUCTION MANUAL SPECIFICATIONS Metal Cutting Blade Motor: 850W No Load Speed: 800-3000spm Stroke Length: 24mm Blade Fitment: Tool-free Cutting Capacities: Timber 210mm Aluminium 20mm Non Alloy Steel 10mm Weight: 3.5kg Kit Box ozito.com.au RSW-5100...
-
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION RECIPROCATING SAW 1. INSERTING & REMOVING BLADES 1 Pivoting Shoe (Adjustable) 4 Variable Speed Dial 2 Blade Holder 5 On/Off Trigger WARNING: Ensure the tool is disconnected from the power supply 3 Locking Button 6 Lock-on Button before performing any of the following operations. -
Page 3: Operation
OPERATION 2. ADJUSTING THE PIVOT SHOE 3. CONTROLS The tool is recommended for use with a residual current If the blade loses its cutting efficiency in one place along its cutting device with a rated residual current of 30mA or less. edge, you can reposition the pivoting shoe to utilize a sharper, unused portion of the blades cutting edge. - Page 4 3. Keep the adjustable pivot shoe firmly against the workpiece throughout the cut. NOTE: DO NOT ALLOW THE TOOL TO BOUNCE. IF THE PIVOT SHOE IS HELD AWAY FROM THE WORK PIECE DURING OPERATION, STRONG VIBRATION AND/OR TWISTING MAY OCCUR CAUSING THE BLADE TO SNAP DANGEROUSLY. RSW-5100...
-
Page 5: Maintenance
Carbon Brush Holder (set) SPRSW5100-12 Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the reciprocating saw by an unauthorised person or by Speed Controller SPRSW5100-02 mishandling of the reciprocating saw. - Page 6 66 67 63 64 65 60 61 62 58 59 22 23 24 19 20 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No.
-
Page 7: Electrical Safety
Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock. -
Page 8: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO 0313 Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
