KOBE Range Hoods
Brillia Series
CHX-30 Series
(400 CFM with LED Lights)
INSTALLATION INSTRUCTIONS
AND OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHX-30 Series(400 CFM-LED) and is the answer not in the manual?

Questions and answers

Summary of Contents for KOBE CHX-30 Series(400 CFM-LED)

  • Page 1 KOBE Range Hoods Brillia Series CHX-30 Series (400 CFM with LED Lights) INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
  • Page 2 3. Contact your merchant for product replacement due to shipping damages, cosmetic damages or defects. 4. For all other issues, call 1-877-BUY-KOBE (289-5623), or e-mail to info@koberangehoods.com NO RETURN, NO REFUND, NO EXCHANGE IF: 1. PRODUCT HAS BEEN INSTALLED 2.
  • Page 3: Table Of Contents

    [ENGLISH] - READ AND SAVE THESE INSTRUCTIONS - CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..................1 COMPONENTS OF PACKAGE....................3 INSTALLATION .......................... 4 OPERATING INSTRUCTIONS....................9 MAINTENANCE ........................10 SPECIFICATIONS ........................11 MEASUREMENTS & DIAGRAMS .....................12 PARTS LIST ..........................14 CIRCUIT DIAGRAM ........................16 TROUBLE SHOOTING ......................17 WARRANTY ..........................18 WARRANTY INFORMATION FORM ..................20 - READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING -...
  • Page 4: Important Safety Instructions

    Any repair carried out without the supervision of KOBE authorized agents will automatically void the warranty. KOBE will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood.
  • Page 5 What to Do In The Event Of a Range Top Grease Fire • SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
  • Page 6: Components Of Package

    {D} Round Exhaust Plate with damper – 1 {E} Rectangular Exhaust Plate with damper – 1 Light bulb – 2 {G} Parametric Panel – 1 FOR MORE INFORMATION, PLEASE VISIT OUR W EBSITE www.koberangehoods.com OR CONTACT KOBE RANGE HOODS AT (626) 775-8880.
  • Page 7: Installation

    INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation To calculate installation, please refer to TABLE 1. (All calculation in inches.) - FOR UNDER THE CABINET - TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Preferred Height of Counter Top to Hood Bottom (Recommended 27”...
  • Page 8 Figure 1 Preparation before Installation NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. • Decide the location of the venting pipe from the hood to the outside. Refer to Figure 1. • A straight, short venting run will allow the hood to perform more efficiently.
  • Page 9 Figure 7 Vent option installation 1. Choose the require vent option. NOTE: If the hood is to be installed as ductless application, please do not remove any duct knockout located at the top or the back of the hood. 2. For 7” Round vent installation only: Using a flat-head screwdriver to remove the 7”...
  • Page 10 Wiring to Power Supply SAFETY WARNING Figure 12 RISK OF ELECTRICAL SHOCK. THIS RANGE HOOD MUST BE PROPERLY GROUNDED. MAKE SURE THIS IS DONE BY SPECIALIZED ELECTRICIAN IN ACCORDANCE WITH ALL APPLICABLE NATIONAL LOCAL ELECTRICAL CODES. BEFORE CONNECTING WIRES, SWITCH POWER OFF AT SERVICE PANEL AND LOCK SERVICE PANEL TO PREVENT POWER FROM BEING SWITCHED ON ACCIDENTALLY.
  • Page 11 Figure 14 Final Assembly 7. To install the parametric panel: Align the parametric panel at the back of the unit. Refer to Figure 14. Push the unit upward, and slide the parametric panel forward into the notch to secure the panel. Refer to Figure 15. Flip the parametric panel upward until it clicks into place.
  • Page 12: Operation Instructions

    OPERATION INSTRUCTIONS Series: CHX30 Series (400 CFM – LED) Note: For best results, turn fan on prior to any preparation or cooking and keep fans running while cooking. Adjust speed as needed. To operate the fan function • Press button to choose from speed. o 1 = Low speed o 2 = Medium speed o 3 = High speed...
  • Page 13: Maintenance

    MAINTENANCE SAFETY WARNING NEVER PUT YOUR HAND INTO AREA HOUSING THE FAN WHILE THE FAN IS OPERATING. Cleaning Hood Surface CAUTION NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. DO NOT USE PAPER TOWEL ON STAINLESS STEEL. For optimal operation, clean range hood and all baffle/spacer/filter/oil tunnel/oil container regularly. *** Regular care will help preserve the appearance of the hood.
  • Page 14: Specifications

    SPECIFICATIONS Series CHX30 Series (400 CFM-LED) CONSUMPTION / AMPERE 0.82 Ampere VOLTAGE 120V 60Hz NUMBER OF MOTORS DESIGN 20-Gauge Seamless / Satin Finish with Glass Parametric panel or Stainless Steel Parametric panel EXHAUST Top 7” Round with damper Top 3-1/4” x 10” Rectangular with damper Rear 3-1/4”...
  • Page 15: Measurements & Diagrams

    MEASUREMENTS & DIAGRAMS All measurements in ( ) are millimeters. All inch measurements are converted from millimeters. Inch measurements are estimated. - FOR TOP VENTING - - FOR REAR VENTING -...
  • Page 16 - DIMENSIONS OF THE MODEL-...
  • Page 17: Parts List

    PARTS LIST SERIES: CHX30 SERIES (400 CFM) HOOD DESCRIPTION MODEL /SIZE PART NO. Motor Mounting Plate K-Y21-2355-P CHX3030PD (30”) K-Y20-1248-Q Hood Frame CHX3036PD (36”) K-Y20-1219-Q Recirculating Box K-Y36-0228 Light socket K-GF F005-00000 Push Button Control K-Y50-0087 Light Support K-Y20-1273-P CHX3030PD (30”) K-Y20-1278-Q Light / Control Panel CHX3036PD (36”)
  • Page 18 PART DIAGRAM FOR CHX30SERIES (400 CFM)
  • Page 19: Circuit Diagram

    CIRCUIT DIAGRAM SERIES: CHX30 SERIES (400 CFM) For models equipped with Push Control:...
  • Page 20: Trouble Shooting

    TROUBLE SHOOTING Issue Possible Cause Solution After Installation, The power is not on. Make sure the circuit breaker and the unit’s power is both motors and ON. Use a voltage meter to check the power supply. lights are not The wire connection is not secure. Check and tighten wire connection.
  • Page 21: Warranty

    TWO-YEAR LIMITED WARRANTY FOR PARTS AND LABOR ON KOBE PREMIUM/ BRILLIA SERIES: For two years from the date of your original invoice from a KOBE authorized dealer, we will, at our sole discretion, choose to repair or replace the product free of charge that failed due to manufacturing defects.
  • Page 22 3. Have the model number 4. Have the serial number 5. Have a description of the nature of any defect in the product or part TO REQUEST WARRANTY SERVICE, PLEASE CONTACT THE KOBE RANGE HOODS SERVICE CENTER: KOBE SERVICE CENTER...
  • Page 23: Warranty Information Form

    1. Date of purchase 2. Model No. 3. Serial No. For warranty service or spare parts purchase contact: KOBE Service Center Toll Free: 1-855-800-KOBE (5623) Email: kobe@adcoservice.com For service in Canada and to report a problem, please contact: Tel: 1-626-775-8880 Email: customer.service@koberangehoods.com...
  • Page 24 Arcadia, CA 91006 USA www.koberangehoods.com This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country. Using a KOBE hood overseas is at your own risk and will void your warranty.
