- Page 1 P P P GRASS COLLECTION PECO PECO PECO PECO PECO SYSTEM DESIGNED FOR: MODEL# 23031501-02 & 23031504-05 (BOB-CAT) 43031501-02 & 43031504-05 (BUNTON) OPERATOR’S MANUAL ASSEMBLY OPERATION MAINTENANCE MANUAL PART#: Q0348 $4.00 REV: 0...
-
Page 2: Table Of Contents
PECO GRASS COLLECTION SYSTEM TABLE OF CONTENTS SECTION PAGE SECTION PAGE Safety - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2... -
Page 3: Safety Alert Symbols
SAFETY WARNING! NEVER operate the mower unless the discharge guard and either the deflector assembly or the vacuum collector adapter are fastened securely in place. WARNING! Do not work around the mower deck boot or the blower area until you are certain that the mower blades and the blower impeller have stopped rotating. -
Page 4: Warranty
PECO elects, without charge if the defect appears within 90 days from the date of installation of such part or before the expiration of the original warranty period, whichever is later. -
Page 5: Introduction And Description
1-1 Introduction NOTE: The mower’s exhaust radiates heat from the We are pleased to have you as a PECO customer. Your muffler which can be potentially drawn through the air collection system has been designed to give you a low intake. -
Page 6: Outer Engine Mount Tube Installation
2-3 Engine Mount Arm Assembly Installation Slide the engine mount arm assembly P#(A0318) (Figure 2-3) into the outer engine mount tube. Secure the engine mount arm assembly using (1) detent pin P#(J0248). 2-2 Outer Engine Mount Tube Figure 2-3 Installation Before installing the outer engine mount tube, first install the lower mount assembly. -
Page 7: Boot Installation
2-5 Boot Installation 2-6 Upper Frame Assembly Installation To mount the boot plate P#(B0079) to the boot P#(E1030), use (2) 3/8”-16 x 1” carriage bolts P#(K1182) NOTE: During this step, it is suggested that two people and (2) 3/8”-16 flange nuts P#(K1215). Make certain that install the upper frame to the lower mount tube. -
Page 8: Exploded Parts Views And Assemblies
Exploded View Of The A0551 - Bagger Assembly (2) K1144 - 5/16”-18 x 1” CARRIAGE BOLT (6) K1142 - 5/16”-18 x 3/4” CARRIAGE BOLT (4) K1010 - 1/4”-20 x 5/8” CARRIAGE BOLT (1) V0002 - PLASTIC TOP (2) K1126 - 1/4”-20 (1 LEFT, 1 RIGHT) FLANGE NUT B0237 - PIVOT... - Page 9 2006 AND BELOW A0687 UNIT ASSEMBLY 8” x 48” 6” x 28” A0619 (5.5HP) LOWER HOSE HB0258 UPPER HOSE 70” THROTTLE HARDWARE ASSEMBLY A0620 (6HP) 70” THROTTLE V1054 ASSEMBLY 6” PLASTIC INLET J6006 A0551 7”-8” ASSEMBLY HOSE CLAMPS G0003 4 CU. FT. COLLECTION C0011 BAGS...
- Page 10 2007 MODELS A0990 UNIT ASSEMBLY 7” x 48” 6” x 28” A0619 (5.5HP) LOWER HOSE HB0331 UPPER HOSE 70” THROTTLE HARDWARE ASSEMBLY A0620 (6HP) 70” THROTTLE V1054 ASSEMBLY 6” PLASTIC INLET J6006 A0551 7”-8” ASSEMBLY HOSE CLAMPS G0003 4 CU. FT. COLLECTION BAGS C0011...
-
Page 11: Blower Cone Installation
2-8 Blower Cone Installation 2-9 Impeller Blade Removal/Replacement Thread (1) 5/16”-18 jam nut P#(K0120) onto each end of (2) 5/16”-18 x 2-1/2” HHCS P#(K0125). Now partially To Remove: First remove the center bolt (#1), washer thread the bolts into each of the two tabs located on the (#2) and spacer (#3) from the taper-lock bushing (#5). -
Page 12: Length Of Hose Adjustment
2-10 Length Of Hose Adjustment 2-13 Lower Hose To Boot Installation Take the unattached end of the lower hose and slide it The hoses in steps 2-11 and 2-12 must be cut to fit your over the circular end of the boot. Use the lower hose machine. -
Page 13: Throttle Cable Installation
2-15 Throttle Cable Installation To install the throttle cable kit to the ROPS (roll over Figure 2-15c protection system), place the 3/8” U-Bolt P#(K0136) onto the ROPS with the threads facing the front of the mower. Next slide on the throttle mount plate assembly P#(A0666) with the rivets also facing toward the front of the mower. -
Page 14: Installation/Removal Of Collection Bags
2-16 Installation/Removal Of Figure 2-16b Plastic Top Collection Bags To install the bag onto the bag ring, first make sure the bag ring end caps are fastened to the bag ring. Place the seam openings of the bag onto the bag ring openings and turn the bag until the slot bracket in the bag ring is protruding from the opening in the bag (Figure 2-16a). -
Page 15: Operating Instructions
* Remember that horsepower requirements will vary with PECO parts. the mowing conditions such as type and height of turf grass, moisture content, amount of leaves, whether the After Each Use: terrain is flat or sloped, etc. -
Page 16: Parts And Service
Turn any PECO Lawn Vac into a total SECTION V lawn grooming tool with the PECO PARTS AND SERVICE Wand Kit! 5-1 Parts And Service Information With your PECO Wand Attachment you will double the ability of your PECO Lawn Vac. -
Page 17: Safety Decals
SAFETY DECALS To promote safe operation, PECO supplies safety decals on all products manufactured. Damage can occur to safety decals either through shipment, use or reconditioning. Contact your local Service Center for replacement decals. Part #: R1057 Part #: R1054... - Page 19 NOTES...
- Page 20 P P P PECO PECO PECO PECO PECO P.O. BOX 1197 ARDEN, NORTH CAROLINA 28704 (800) 438-5823 OR (828) 684-1234 FAX: (828) 684-0858 EMAIL: peco@lawnvac.com WEBSITE: www.lawnvac.com...
