- Page 1 FPM-30 Flat Panel Monitor with 10.4" Color TFT LCD Display...
-
Page 2: Copyright Notice
Copyright Notice This document is copyrighted by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd., reserves the right to make improvements to the products described in this manual at any time. Specifications are thus subject to change without notice. -
Page 3: Table Of Contents
Contents Chapter 1 Introduction ........1 Checklist ................. 2 Introduction ................2 Specifications ................3 Flat Panel Displays ..............4 Connectors ................5 Connection Diagram .............. 6 Dimensions ................7 Chapter 2 System Setup .......9 Wall Mounting ..............10 Panel Mounting ..............11 Exploded Diagram ............... -
Page 4: Chapter 1 Introduction
Introduction This chapter includes: • Checklist • Introduction • Specifications • Flat Panel Displays • Connectors • Connector Diagram • Dimensions Chapter 1 Introduction... -
Page 5: Checklist
• Screw Bag Introduction Advantech's FPM-30 series flat panel monitors are a state-of-the-art alternative to conventional CRT monitors. They offer the traditional advantages of flat panel displays — small-size, light weight and low power consumption — with the added security of a rugged NEMA4/12 (IP52/56) compliant design. -
Page 6: Specifications
Specifications General • Construction: Heavy-duty aluminum and steel chassis • Front panel: NEMA 4/12 (IP 52/56) • Control: One waterproof brightness/contrast adjustment knob (monochrome series only) • Mounting: Panelmount or wallmount • Dimensions: Width: 13.0" (330 mm) Height: 9.5" (242 mm) Depth: 2.0"... -
Page 7: Flat Panel Displays
Flat Panel Displays Model FPM-30CT FPM-30M Display Type TFT Color LCD Mono LCD Size (diagonal) 10.4" 10.4" Max. Resolution 640 x 480 640 x 480 Max. Colors 256 K Colors 64 Greyscale levels Viewing Angle 90º 50º Dot Size (mm) 0.33 x 0.33... -
Page 8: Connectors
Connectors The following connectors are situated on the left hand side of the FPM-30. Also refer to the diagram overleaf. Video I/O Port (DB-44) This connector links the FPM-30 to the PCA-6653 display card. The figure below shows how to connect the DB-44 to the PCA-6653. Note: The Display card provides power to the FPM-30;... -
Page 9: Connection Diagram
Connection Diagram FPM-30 User's Manual... -
Page 10: Dimensions
Dimensions Unit: mm Chapter 1 Introduction... - Page 11 FPM-30 User's Manual...
-
Page 12: Chapter 2 System Setup
System Setup This chapter includes: • Wall Mounting • Panel Mounting • Exploded Diagram Chapter 2 System Setup... -
Page 13: Wall Mounting
Wall Mounting When the FPM-30 assembly is complete, the unit may be mounted in a panel or wall. Mounting brackets and fix brackets are supplied for convenient wall mounting. The screw holes are used to secure the large mounting bracket to the wall. Connect the FPM-30 to the bracket using the three screws included. -
Page 14: Panel Mounting
Panel Mounting A cutout can be made to accommodate panel mounting. Four panelmount brackets are included with the FPM-30. Slide the unit backwards into the panel opening. Attach the four mounting brackets by inserting the screws into the keyhole slots on the PC cover. Use the screws to secure the brackets to the cover. -
Page 15: Exploded Diagram
Exploded Diagram Remove the six screws as shown, then lift the rear panel from the unit. Internal components are as shown below. FPM-30 User's Manual...
