Page 1: User Guide
Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http://www. the upper right corner of our website. “Antes de operar su equipo lea cu idadosamente las instrucciones en este manual”...
Page 2: Compliance Information
The mark indicates the requirement NOT to dispose the equipment including any spent or discarded batteries or accumulators as unsorted municipal waste, but use the return and collection systems available. If the batteries, accumulators and button cells included with this equipment, display the chemical symbol Hg, ViewSonic PJL6223/PJL6233 Downloaded From projector-manual.com Viewsonic Manuals...
Page 3: Important Safety Instructions
A grounding type plug has two blades and a third grounding prong. The wide blade and the replacement of the obsolete outlet. accessible. When a cart is used, use caution when moving the cart/unit combination to avoid injury from tipping over. ViewSonic PJL6223/PJL6233 Downloaded From projector-manual.com Viewsonic Manuals...
Page 4: Declaration Of Rohs Compliance
Declaration of RoHS Compliance Technical Adaptation Committee (TAC) as shown below: Substance Proposed Maximum Concentration Actual Concentration Mercury (Hg) Cadmium (Cd) Polybrominated biphenyls (PBB) Polybrominated diphenyl ethers (PBDE) below: ViewSonic PJL6223/PJL6233 Downloaded From projector-manual.com Viewsonic Manuals...
Page 5: Copyright Information
The lamp in this product contains mercury which can be dangerous to you and the environment. Please use care and dispose of in accordance with local, state or federal laws. ViewSonic respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit ViewSonic website to learn more.
Page 6 User Guide Network Set-up and Operation PJ Network Manager for Windows Downloaded From projector-manual.com Viewsonic Manuals...
Page 7 User Guide Downloaded From projector-manual.com Viewsonic Manuals...
Page 8: Features And Design
Swedish, Finnish, Polish, Hungarian, Romanian, Closed Caption This is a printed version of the program sound or other information displayed on the screen. You can turn on the feature and switch the channels. (p.52) Note: Downloaded From projector-manual.com Viewsonic Manuals...
Page 9: Table Of Contents
Limited Warranty .....78 Trademarks Each name of corporations or products in this book is either a registered trademark or a trademark of its respective corporation. Downloaded From projector-manual.com Viewsonic Manuals...
Page 10: To The Owner
COMES IN CONTACT WITH OIL OR CHEMICALS, IT MAY BECOME DETERIORATED. CAUTION Not for use in a computer room as defined in the Standard for the Protection of Electronic Computer/Data Processing Equipment, ANSI/NFPA 75. READ AND KEEP THIS USER GUIDE FOR LATER USE. Downloaded From projector-manual.com Viewsonic Manuals...
Page 11: Safety Instructions
Never push objects of any kind into this projector through cabinet slots as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the projector. Downloaded From projector-manual.com Viewsonic Manuals...
Page 12: Installing The Projector In Proper Position
This may cause damage to the projector. For information Air Intake Vent about transporting the projector by courier or any other transport service, consult your dealer. is cooled enough. Downloaded From projector-manual.com Viewsonic Manuals...
Page 13: Compliance
THE SOCKET-OUTLET SHOULD BE INSTALLED NEAR THE EQUIPMENT AND EASILY ACCESSIBLE. Contents of package Your projector should come with the items shown below. Check that all the items are included. Require of your dealer immediately if any items are missing. (5) VGA Cable Downloaded From projector-manual.com Viewsonic Manuals...
Page 14: Part Names And Functions
⑮ Adjustable Foot Bottom ⑭ ⑮ Note: ⑪ Operation” . Kensington Security Slot This slot is for a Kensington lock used to deter theft of the projector. Kensington is a registered trademark of ACCO Brands Corporation. Downloaded From projector-manual.com Viewsonic Manuals...
Page 15: Rear Terminal
Connect the audio output signal from computer or video equipment connected to ② and ③ to this ④ AUDIO OUT (VARIABLE) This terminal outputs sound from AUDIO IN terminal. Never plug headphones into this jack. Downloaded From projector-manual.com Viewsonic Manuals...
Page 16: Top Control
(VOLUME –/+) buttons ⑥ MENU button ⑦ LAMP REPLACE indicator buttons) ⑧ WARNING indicator ③ AUTO SETUP button abnormal condition. search, Auto PC adj. and Auto Keystone functions) in the setting menu. ④ ON/STAND–BY button Downloaded From projector-manual.com Viewsonic Manuals...
Page 17: Remote Control
⑮ P-TIMER button ⑯ LAMP button ⑰ INFO. button ⑱ KEYSTONE button ⑲ SELECT button ⑳ COMPONENT button Select the COMPONENT input source. Note: To ensure safe operation, please observe the following precautions: or any chemical material. Downloaded From projector-manual.com Viewsonic Manuals...
Page 18: Remote Control Battery Installation
To retract the adjustable foot, lift the front of the projector and push and undo the foot lock latch. Keystone distortion of the projected image can be corrected Adjustable Foot Downloaded From projector-manual.com Viewsonic Manuals...
Page 19: Installation
(a) : Projection distance (from the projectior’s end) (b), (c) : Screen height (1024X768) (±10% ) T - 1 Screen Screen size Projection distance Screen height Type (a) min. (a) max inch inch inch inch inch 11.8 Downloaded From projector-manual.com Viewsonic Manuals...
Page 20: Connecting To A Computer
/COMPONENT IN either Computer input or Monitor output. (See Page Audio cable (stereo) AUDIO OUT (stereo) AUDIO IN Note: and the COMPUTER IN 2/MONITOR OUT terminals as input. not the COMPUTER IN 2/MONITOR OUT. cables. Downloaded From projector-manual.com Viewsonic Manuals...
Page 21: Connecting To Video Equipment
Composite Video and Audio Output Audio cable Audio (stereo) Video cable Audio Input cable (stereo) cable Audio cable VIDEO IN COMPUTER IN 1 AUDIO IN AUDIO IN (stereo) /COMPONENT IN AUDIO OUT (stereo) Note: cables. Downloaded From projector-manual.com Viewsonic Manuals...
Page 22: Connecting To Component Video And Rgb
(Cables are not supplied with this projector.) Audio Output Component Video Output pin Output (Y, Pb/Cb, Pr/Cr) Component cable Audio Input cable Audio cable Audio cable (stereo) VGA cable (stereo) AUDIO OUT (stereo) AUDIO IN Note: cables. Downloaded From projector-manual.com Viewsonic Manuals...
Page 23: Using The Ferrite Core
For the U.S.A. and Canada Ground Ground To power cord To the AC outlet. To the AC outlet. connector on your To the AC outlet. (200 - 240 V AC) (200 - 240 V AC) projector. (120 V AC) Downloaded From projector-manual.com Viewsonic Manuals...
Page 24: Basic Operation
Input signal guidance window On2, the input No signal Current Input setting:RGB Off is selected in the Display function, the Video/ PC selection window and the input signal guidance Is signal processed correctly? Is cable connected properly? Downloaded From projector-manual.com Viewsonic Manuals...
Page 25 PIN code. Note: code number is entered within three minutes after the turned off automatically. If you forget your PIN code, the projector can no longer be started. Downloaded From projector-manual.com Viewsonic Manuals...
Page 26: Turning Off The Projector
Wait until the POWER indicator stops blinking to turn on the projector again. indicator lights red. projector is turned on right after it turns off, it takes a while to start projecting. Downloaded From projector-manual.com Viewsonic Manuals...
Page 27: How To Operate The On-Screen Menu
Image 3 Image 4 Point The currently set item is or SELECT check marked. button The selected item is highlighted in orange. Dynamic Standard Real Blackboard(Green) Colorboard Image 1 Image 2 Image 3 Image 4 Downloaded From projector-manual.com Viewsonic Manuals...
Page 28: Menu Bar
Display the input source information: Input , H-sync freq., V-sync freq., Screen, Language, Lamp status, Lamp counter , Power management, Key lock, PIN code lock and Remote control ⑨ Network ⑩ Guide The key operation is displayed. Downloaded From projector-manual.com Viewsonic Manuals...
Page 29: Zoom And Focus Adjustment
The keystone adjustment can be remote control once more while the keystone Reduce the upper width Reduce the lower width with the Point button. with the Point button. adjustment will be canceled. input signal. Downloaded From projector-manual.com Viewsonic Manuals...
Page 30: Sound Adjustment
Mute function On or Off. The dialog Press the Point button to turn up the volume; press the Point button to turn down the volume. Sound Menu Mute Off. When the sound is turned off, On is displayed. Press Downloaded From projector-manual.com Viewsonic Manuals...
Page 31: Remote Control Operation
Press the D.ZOOM buttons on the remote control to enter to LAMP button lamp mode for changing the brightness on the screen. High ... Brighter than the Normal mode. Normal ..Normal brightness Eco .... Downloaded From projector-manual.com Viewsonic Manuals...
Page 32 SCREEN button IMAGE button P-TIMER button Press the IMAGE button on the remote control to select a NO SHOW button IMAGE button details. SCREEN button Note: See the previous page for the description of other buttons. Downloaded From projector-manual.com Viewsonic Manuals...
Page 33: Computer Input
RGB input source and then Computer Computer 1 Component RGB(Scart) S-video Note: When the Input Search function is set to On1 or On2 in the Auto setup function, the input signal will be searched Downloaded From projector-manual.com Viewsonic Manuals...
Page 34: Computer System Selection
Menu. Use the Point buttons to select Input and then press the Point Use the Point buttons to select System and then press the Point Use the Point buttons to select the desired system can be selected. Downloaded From projector-manual.com Viewsonic Manuals...
Page 35: Auto Pc Adjustment
Display area V with the Auto PC Adjustment function. When the image Reset Mode free is not provided properly with this operation, manual Store 480i, 576i, 480p, 576p, 720p,1035i or 1080i is selected in the Downloaded From projector-manual.com Viewsonic Manuals...
Page 36: Manual Pc Adjustment
When the image has dark bars, try this adjustment. Display area H Use the Point displayed by this projector. Display area V Use the Point buttons to adjust the vertical area displayed by this projector. Downloaded From projector-manual.com Viewsonic Manuals...
Page 37 Note: Display area (H/V) cannot be selected when 480i, 576i, 480p, 576p, 720p, 1035i or 1080i is selected in the When input computer signal to the projector, PC adjust will become available. Downloaded From projector-manual.com Viewsonic Manuals...
Page 38: Image Mode Selection
Colorboard Image 1 color from the preset four colors. Image 2 Image 3 Image 1–4 Image 4 For viewing with the user preset image mode in the Image input source. Downloaded From projector-manual.com Viewsonic Manuals...
Page 39 Blackboard(Green) or Colorboard To reset the adjusted data, select Reset and press the is selected in Image select, Color temp. will change to Blackboard or Colorboard. Yes. All adjustments will return to their previous figures. Downloaded From projector-manual.com Viewsonic Manuals...
Page 40: Screen Size Adjustment
720p, 1035i, or 1080i higher than it, reset the resolution to the lower before connecting to the projector. True, Full, and Digital zoom +/– are disabled and cannot be displayed when 480i, 576i, 480p or 576p is Downloaded From projector-manual.com Viewsonic Manuals...
Page 41 576p is selected in the PC System Menu the D.ZOOM Digital zoom +/- cannot be selected when Full or True is selected. Custom is selected, the Digital source from the Input Source Selection Menu (see page buttons. Downloaded From projector-manual.com Viewsonic Manuals...
Page 42: Video Input
When the input source is coming from video S-video equipment connected to the COMPUTER IN S-VIDEO. Auto Note: When the Input Search function is set to On1 or On2 in Computer the Auto setup function, the input signal will be searched Downloaded From projector-manual.com Viewsonic Manuals...
Page 43 COMPUTER Component. When the input source is coming from video RGB (Scart) equipment connected to the COMPUTER (Scart). S-video Note: When the Input Search function is set to On1 or On2, Downloaded From projector-manual.com Viewsonic Manuals...
Page 44: Video System Selection
If the projector cannot reproduce proper video image, select a specific component video signal format from among 480i, 576i, 480p, 576p, 720p, 1035i, and 1080i. Note: The AV System Menu cannot be selected when selecting RGB (Scart). Downloaded From projector-manual.com Viewsonic Manuals...
Page 45 Image 1–4 For viewing with the user preset image mode in the Image video input source. Downloaded From projector-manual.com Viewsonic Manuals...
Page 46 White balance Red, Green or Blue is adjusted, the Color temp. level will change to User. PAL, SECAM, PAL-M or PAL-N Blackboard(Green) or Colorboard is selected in Image select, Color temp. will change to Blackboard or Colorboard. Downloaded From projector-manual.com Viewsonic Manuals...
Page 47 Yes. Stored data can be called up by selecting an Image (1–4) in the appears and then select Yes. Note: Noise reduction and Progressive cannot be selected when 480p, 576p, 720p, 1035i or 1080i is selected Downloaded From projector-manual.com Viewsonic Manuals...
Page 48 Reset to display Note: Normal is set Yes. automatically. Scale H/V and Position H/V is limited depending on the input signal. Wide cannot be operated when 720p, 1035i or 1080i is selected in the AV Downloaded From projector-manual.com Viewsonic Manuals...
Page 49: Setting
This function is used to change the position of the Menu position and press the button as follows. the top left the top right the center the bottom left the bottom right the top left ..Downloaded From projector-manual.com Viewsonic Manuals...
Page 50 Auto PC Adjustment function. When the image is not provided properly with Input search, Auto PC adj. and Auto Keystone cannot be this operation, manual adjustments are required set Off at the same time. Downloaded From projector-manual.com Viewsonic Manuals...
Page 51 The factory default setting is in this option. Off ......Power off? No signal for Power management Please wait ... Arrows for the True function in the Downloaded From projector-manual.com Viewsonic Manuals...
Page 52 Logo select and Capture functions cannot be selected. Computer 2 Direct on Network Standby mode Logo select among following options. User ..Show the image you captured. Default Default ..Off ... Nothing is shown on the screen. Default Downloaded From projector-manual.com Viewsonic Manuals...
Page 53 Off ... The screen logo can be changed freely from On ... The screen logo cannot be changed without a If you want to change the Logo PIN code lock setting, below. The initial Logo PIN code factory. Downloaded From projector-manual.com Viewsonic Manuals...
Page 54 PIN code change. Current Logo PIN code appears, use the Point buttons to enter the correct Next choose Yes Current Logo PIN code hand. If you lost the number, you could no longer change ---- Exit Downloaded From projector-manual.com Viewsonic Manuals...
Page 55 Terminal function is not available when selecting Computer 2 to the input source. Change the input source to the others Standby mode (Computer 1, and so on) so that the Terminal function will Standby mode Downloaded From projector-manual.com Viewsonic Manuals...
Page 56 AC power cord to a wall outlet. Note: Be sure to turn off the projector properly (see “Turning Off the incorrect sequence, the Direct on function will not work properly. Downloaded From projector-manual.com Viewsonic Manuals...
Page 57 Restart to resume Count up or Count down. Reset ....Reset to return to the following value; Stop or Cancel the P-timer via Remote Control Count up Count down ... Timer that you set Exit ....... button for a few seconds. Downloaded From projector-manual.com Viewsonic Manuals...
Page 58 When the input signal is Component (for adjustment and the system is set to Auto, Color available. setting conditions. is not available. Color Press the Point buttons to select Off, CC1, CC2, CC3 or CC4, and then Downloaded From projector-manual.com Viewsonic Manuals...
Page 59 Press and hold both the MENU and IMAGE buttons together for 5 seconds or more. After changing the code, make sure the remote control operates properly. Note: switch the code on the remote control to fit the code on the projector. Downloaded From projector-manual.com Viewsonic Manuals...
Page 60 Whenever you change the PIN code lock setting or the code at the factory. If you want to change the PIN code lock setting, press appears. When the projector is locked with the PIN code, the Security icon appears on the guide. Downloaded From projector-manual.com Viewsonic Manuals...
Page 61 Change the PIN code lock setting Use the Point buttons to select Off, On1 or On2, Change the PIN code Change the PIN code PIN code change buttons to enter the correct code. The New PIN code Current PIN code Downloaded From projector-manual.com Viewsonic Manuals...
Page 62 Lamp counter....This item shows the total accumulated time of the lamp usage. Lamp counter reset..button to choose Lamp counter reset. Select Yes in the confirmation counter, and then choose Yes in reset lamp counter. Downloaded From projector-manual.com Viewsonic Manuals...
Page 63 Factory default messages in chronological order. Note: warning log records will be deleted. Factory default User logo, PIN code lock, Logo PIN code lock, Lamp counter and Filter counter to the factory default settings. Downloaded From projector-manual.com Viewsonic Manuals...
Page 64: Information
Off, Ready or Shut down, and Timer are displayed. Key lock The selected Key lock icon is displayed. PIN code lock Off or On1 or On2 is displayed. Remote control The selected remote code is displayed. Downloaded From projector-manual.com Viewsonic Manuals...
Page 65: Maintenance And Cleaning
If the projector WARNING lights cannot be turned on and the WARNING indicator still lights red, unplug the AC power cord and contact the service center. CAUTION AC POWER CORD CONNECTED UNDER AN Downloaded From projector-manual.com Viewsonic Manuals...
Page 66: Cleaning The Filters
Point buttons to select Filter counter reset and Select Yes, then Filter counter Reset? another confirmation appears. Select Yes to continue. Yes to Select Yes again reset the Filter counter. to reset the Filter counter. Downloaded From projector-manual.com Viewsonic Manuals...
Page 67: Attaching The Lens Cap
AC power cord is unplugged high due to the lamps. In addition, there is a risk that the internal parts may be damaged not only by the flammable air spray but also by the cold air. Downloaded From projector-manual.com Viewsonic Manuals...
Page 68: Lamp Replacement
Replace the lamp with a new one and secure the three Close the lamp cover and secure the screw. Connect the AC power cord to the projector and turn on the projector. Reset the lamp replacement counter. Screw Downloaded From projector-manual.com Viewsonic Manuals...
Page 69: Lamp Handling Precautions
Inappropriate attempts to service the unit by anyone, especially those who are not appropriately trained to do so, may result in an accident or injury caused by pieces of broken glass. Downloaded From projector-manual.com Viewsonic Manuals...
Page 70: Appendix
Image is Left/Right reversed. Image is Top/Bottom reversed. Picture is not bright enough. Contrast or Brightness is adjusted properly. See Image mode is approaching. Replace the lamp with a new one promptly. See page Downloaded From projector-manual.com Viewsonic Manuals...
Page 71 Capture function does not work. Auto setup does not work properly. Make sure Off is not selected at any function of Auto setup. See page Auto keystone function does not Manual. Press work even when the projector is tipped. Downloaded From projector-manual.com Viewsonic Manuals...
Page 72 High voltages are used to operate this projector. Do not attempt to open the cabinet. If problems still persist after following all operating instructions, contact the dealer where you purchased the how to obtain service. Downloaded From projector-manual.com Viewsonic Manuals...
Page 73 Mode 5 Reset Yes/No Store Image 1 Mode 7 Image 2 Screen Normal True Store Mode 1 Wide Mode 2 Full Custom Custom adj. Scale Mode 5 H&V On/Off Position Mode 7 Common Yes/No Reset Yes/No Downloaded From projector-manual.com Viewsonic Manuals...
Page 74 Screen Normal reset Yes/No Wide Filter counter Filter counter Custom Timer Custom adj. Scale Filter counter reset Yes/No H&V On/Off Warning log Position Factory default Yes/No Common Yes/No Reset Yes/No Information Input Source Information Display Downloaded From projector-manual.com Viewsonic Manuals...
Page 75: Indicators And Projector Condition
If the projector is turned off again, unplug the AC power cord and contact the dealer or the service center for service and checkup. Do not leave the projector on. It may cause an electric Downloaded From projector-manual.com Viewsonic Manuals...
Page 76: Compatible Computer Specifications
XGA 7 WXGA 12 WUXGA 1 WUXGA 2 (Interlace) XGA 11 XGA 12 (Interlace) UXGA 1 UXGA 2 XGA 15 SXGA 1 SXGA 2 (Interlace) (Interlace) (Interlace) Note: The specifications are subject to change without notice. Downloaded From projector-manual.com Viewsonic Manuals...
Page 77: Technical Specifications
(Not including protrusions) Panel Resolution Signal Compatibility Color System Optical Information Interface /Computer In 2/Monitor Out Audio Input Jack /Component Input Jack Audio Power Operating Environment Remote Control The specifications are subject to change without notice. panels. Downloaded From projector-manual.com Viewsonic Manuals...
Page 78: Pj Link Notice
Appendix PJ Link Notice Projector Input Parameter RGB 2 Computer 1 Component RGB (Scart) RGB 5 Computer 2 RGB 1 Video Video VIDEO 2 Downloaded From projector-manual.com Viewsonic Manuals...
Page 79: Configurations Of Terminals
Terminal: Analog RGB (Mini D-sub 15 pin) Red Input/Output Green Input/Output Ground (Vert.sync.) Blue Input/Output Ground (Red) Vert. sync. Ground (Green) Ground (Blue) CONTROL PORT CONNECTOR (D-sub 9 pin) Serial R X D T X D LAN TERMINAL Downloaded From projector-manual.com Viewsonic Manuals...
Page 80 Appendix Dimensions Unit: mm(inch) Screw Holes for Ceiling Mount 86.5(3.41) 250.5(9.86) 20.0 141.5(5.57) 80.5(3.17) (0.79) 4.3(0.17) 19.0(0.75) 80.5(3.17) 86.5(3.41) 90.0(3.54) 109.0(4.30) 118.0(4.65) 133.8(5.27) 48.7(1.92) 54.2(2.13) 57.6(2.27) 37.3(1.47) 89.3(3.51) 241.4(9.50) 178.7(7.04) Downloaded From projector-manual.com Viewsonic Manuals...
Page 81: Serial Control Interface
ENTER VIDEO MUTE OFF FREEZE ON FREEZE OFF Computer 1 Analog RGB Image Standard Computer 1 Scart Image Real Computer 1 Component Image Cinema Auto PC ADJ. Image 1 PRESENTATION TIMER Image 2 Blackboard Dynamic Downloaded From projector-manual.com Viewsonic Manuals...
Page 82 Temperature Read ( For each sensor, two digit and the tenth place numbers are displayed with a space between each temperature.) Communication failure local dealer for further information of other commands. Downloaded From projector-manual.com Viewsonic Manuals...
Page 83: Customer Support
Macau www.hk.viewsonic.com service@hk.viewsonic.com Middle East ap.viewsonic.com/me/ Contact your reseller service@ap.viewsonic.com service.us@viewsonic.com Puerto Rico & Virgin Islands www.viewsonic.com soporte@viewsonic.com Singapore/Malaysia/Thailand www.ap.viewsonic.com service@sg.viewsonic.com South Africa Contact your reseller service@ap.viewsonic.com www.viewsoniceurope.com/uk/ United Kingdom www.viewsoniceurope.com/uk/ United States www.viewsonic.com service.us@viewsonic.com Downloaded From projector-manual.com Viewsonic Manuals...
Page 84: Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components.
Page 85 Limitation of implied warranties: Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based upon opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages.
Page 86: Mexico Limited Warranty
Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use relationships, or other commercial loss, even if advised of the possibility of such damages.
Page 87 Distrito Federal: Guadalajara, Jal.: SERVICRECE, S.A. de C.V. Guerrero Acapulco Monterrey: GS Computación (Grupo Sesicomp) Global Product Services MERIDA: Oaxaca, Oax.: CENTRO DE DISTRIBUCION Y SERVICIO, S.A. de C.V. Tijuana: FOR USA SUPPORT: ViewSonic Corporation Downloaded From projector-manual.com Viewsonic Manuals...
Page 88 Network Set-up and Operation Downloaded From projector-manual.com Viewsonic Manuals...
Page 89 Downloaded From projector-manual.com Viewsonic Manuals...
Page 90 CAUTION IN USING NETWORK FUNCTION We assume no responsibility for the loss or damage of data, or damage of the computer caused by using this projector. Making back-up copies of valuable data in your computer is recommended. Downloaded From projector-manual.com Viewsonic Manuals...
Page 91 Setting up the projector ............................39 Screen setting ...............................39 Setting 1..................................40 Setting 2..................................40 Setting 3..................................41 Information..................................42 Chapter 5 Appendix ....................43 Examples of connection ............................44 Use of telnet..................................46 Web browser setting..............................48 Examples: OS/Browsers .............................49 Q&A ......................................53 Downloaded From projector-manual.com Viewsonic Manuals...
Page 92: Chapter 1 Preparation
Chapter 1 Preparation Describes features and operating environment of this projector. Downloaded From projector-manual.com Viewsonic Manuals ViewSonic...
Page 93: Features
SNMP manag- Trap ing software. Refer to the You received owner's manual of the "PJ a Trap. Net work Manager" sup - Trap SNMP Manager plied separately for further details. Downloaded From projector-manual.com Viewsonic Manuals...
Page 94: Required Operating Environment For Computers
If you do not use the function E-mail Alert, this application is not required. Network specifications of the projector LAN Terminal Data communication standards 10Base-T (10Mbps) / 100Base-TX compatible Protocol TCP/IP Downloaded From projector-manual.com Viewsonic Manuals...
Page 95 Other product or brand names in this manual are registered trademarks or trademarks of their respective owners. * Unauthorized use of a part or whole of the contents in this manual is prohibited. * The contents of this manual are subject to change without notice. Downloaded From projector-manual.com Viewsonic Manuals...
Page 96: Flow Of Installation
So it is not required to install the software into your computer. For PJ Network Manager function, it is required to install the software. Please see the own- er's manual of "PJ Network Manager Function". Downloaded From projector-manual.com Viewsonic Manuals...
Page 97 Chapter 1 Preparation Downloaded From projector-manual.com Viewsonic Manuals...
Page 98: Chapter 2 Setup Procedures
Chapter 2 Setup Procedures Describes how to configure the network. Downloaded From projector-manual.com Viewsonic Manuals ViewSonic...
Page 99: Connecting To The Lan Line
SELECT button. Then the Menu will disappear, the “Please wait...” mes- sage will appear, and switching operation will start. Switching will take a while and the projector’s LINK/ACT Lamp will be on or blink, and after completing the operation, the “Please wait...” message will disappear. Downloaded From projector-manual.com Viewsonic Manuals...
Page 100 *1 Set "On" only when the DHCP server is available on your network environment. *2 Set [255.255.255.255] if the network does not provide the gateway (router). *3 Set [255.255.255.255] if you do not use the function E-mail alert. Downloaded From projector-manual.com Viewsonic Manuals...
Page 101: Network Pin Code
Select "Network information" in the Network menu and press Point or SELECT button to show LAN setting environment of the currently selected projector. (The description below is an example and different from what will be shown.) * The numerical value is a setting example. Downloaded From projector-manual.com Viewsonic Manuals...
Page 102: Network Factory Default
3. Another confirmation box appears and select "Yes" and then press SELECT button. 4. All the wired LAN settings will go back to the factory default settings. For details, refer to “Wired LAN factory default settings” (p.16). Downloaded From projector-manual.com Viewsonic Manuals...
Page 103: Wired Lan Factory Default Settings
Wired LAN factory default settings SELECTED LAN Parameter LAN 1 LAN 2 LAN 3 DHCP IP ADDRESS 169.254.100.100 192.168.100.100 192.168.100.100 SUBNET MASK 255.255.0.0 255.255.255.0 255.255.255.0 GATEWAY ADDRESS 255.255.255.255 255.255.255.255 255.255.255.255 DNS ADDRESS 255.255.255.255 255.255.255.255 255.255.255.255 Downloaded From projector-manual.com Viewsonic Manuals...
Page 104: Chapter 3 Basic Setting And Operation
Describes basic operations and settings for controlling the projec- tor by using the web browser. It is required that computer and projector is connected to the network and the network address is properly configured. Downloaded From projector-manual.com Viewsonic Manuals ViewSonic...
Page 105: Login The Setting Page Of The Projector
* The entering User Name must be "user" and it can not be changed. [Note] When accessing the projector for the first time or the Network PIN code "0000" is set, the auto-login will be performed and the next main setting page is displayed. Downloaded From projector-manual.com Viewsonic Manuals...
Page 106: Display Of Main Setting Page
Main setting page in the display Sub menu tab Switches the sub menu tab. Setting page Main menu Displays the control and For selection of control and setting items according to setting items of the projector. the selected menu. Downloaded From projector-manual.com Viewsonic Manuals...
Page 107: How To Use The Setting Page
Each item has a valid setting range. The setting value exceeding this becomes invalid. Some control items can not be used depending on the selecting input mode or functions of the projector you use. In this case, the values of those items are indicated with "---". Downloaded From projector-manual.com Viewsonic Manuals...
Page 108 How to use the setting page Radio button setting Select an item by selecting a radio button. Check box setting Select items by ticking on check boxes. Downloaded From projector-manual.com Viewsonic Manuals...
Page 109: Initial Setting
Model name ..Indicates the model name of the projector Network PIN code ..Sets the Network PIN code to login the setting page ( p.23) PJLink.......Switches PJLink password authentication. (ON, OFF) ( p.23) Password....Password for PJLink function ( p.23) Downloaded From projector-manual.com Viewsonic Manuals...
Page 110: Network Pin Code Setting
PJLink Class 1 and is verified conformance with PJLink Standard Class 1. Projector Input PJLink Input Parameter Computer 2 RGB 1 Computer 1 RGB 2 Component RGB 3 S-video RGB 4 RGB (Scart) RGB 5 Video Video VIDEO 2 Downloaded From projector-manual.com Viewsonic Manuals...
Page 111: Network Configuration
* If you make incorrect settings, you cannot find out the new network settings. Be careful to set up them correctly, otherwise you cannot connect to the projector. It is recommended to make a note of them. Downloaded From projector-manual.com Viewsonic Manuals...
Page 112: E-Mail Setting
Password .........Enter SMTP password. (up to 63 characters) POP server.......Enter server name or IP address of the POP server. (up to 60 characters) POP server port ....Enter Port number of the POP server. (from 1 to 65535) Downloaded From projector-manual.com Viewsonic Manuals...
Page 113 The projector does not send message to the address set in "Administrator address" text box. If you want to send e-mails to the administrator address, enter the administrator address into "Add address" text box. Downloaded From projector-manual.com Viewsonic Manuals...
Page 114 Standby in proper user operation" signifies that the projector is turned on by using the web browser and then it is turned into standby with ON/STANDBY button on the top control or the remote control. Up to 99,999 hours can be set for use time. Downloaded From projector-manual.com Viewsonic Manuals...
Page 115: Examples: Type And Contents Of Alert Mail
This alert mail will not be sent when unchecking the mail sending condi- tion "When PJ lamp replacement time is reached". Downloaded From projector-manual.com Viewsonic Manuals...
Page 116: Snmp Setting
Community name(refer)..Enter community name (read only). Default name is "public". Trap Item Description Community name......Enter community name to send "Trap". Default name is "public". Trap address........Enter IP address of the SNMP manager computer to receive "Trap". Downloaded From projector-manual.com Viewsonic Manuals...
Page 117 Standby in proper user operation" signifies that the projector is turned on by using the web browser and then it is turned into standby with ON/STANDBY button on the top control or the remote control. Up to 99,999 hours can be set for the time setting. Downloaded From projector-manual.com Viewsonic Manuals...
Page 118: Chapter 4 Controlling The Projector
Chapter 4 Controlling the Projector Describes controlling and setting of the projector by using the web browser. Downloaded From projector-manual.com Viewsonic Manuals ViewSonic...
Page 119: Power Control And Status Check
Power control ..Controls the projector power by clicking the "ON" or "Standby" button. The projector cannot be turned on while the projector is on cooling down. The web browser checks and updates the projector's condition every 30 seconds automatically. Downloaded From projector-manual.com Viewsonic Manuals...
Page 120 If you set this as Eco, then the network part will be turned off when you turn off the projector. Consequently, you cannot turn on/off the projector via the networks. Downloaded From projector-manual.com Viewsonic Manuals...
Page 121: Control
For further information , refer to the projector's owner's manual. When the projector is in standby, all the controlling items are inactive. Downloaded From projector-manual.com Viewsonic Manuals...
Page 122: System
* The selectable scanning systems are 480i, 576i, 480p, 576p, 720p, 1035i and 1080i. If the mode (Mode1 to Mode10) which is stored in the item "PC Adjustment" ( p.38) is available, they are also listed together with the above mode. Downloaded From projector-manual.com Viewsonic Manuals...
Page 123: Sound
This function is to adjust the sound of the projector. The values in the text box repre- sent the current control value or status. Item Description Volume ....Adjusts the sound volume from the speaker. (0 ~ 31) Mute......Suppresses the sound. (ON, OFF) Downloaded From projector-manual.com Viewsonic Manuals...
Page 124: Image Adjustment
Cinema Real Blackboard(Green) The mark " " means that the available image mode in the Colorboard selected input source. The error message appears when Image1 - 4 selecting the disabled image mode indicated with "*". Downloaded From projector-manual.com Viewsonic Manuals...
Page 125: Pc Adjustment
Mode Store..Stores the PC adjustment values. Select a mode no. [Mode1 - Mode10] from the pull-down menu. Mode Free ....Clear the PC adjustment values. Select a mode no. [Mode1 - Mode10] from the pull- down menu. Downloaded From projector-manual.com Viewsonic Manuals...
Page 126: Setting Up The Projector
Normal True The mark " " means that the available screen mode in Wide the selected input source system. The error message Full appears when selecting the disabled screen mode indi- Custom cated with "*". Downloaded From projector-manual.com Viewsonic Manuals...
Page 127: Setting 1
*The specified time can be set 1 to 30 min. Direct on....Sets the power-on mode when the AC cord is connected to the outlet. (ON, OFF) Lamp control..Selects lamp control mode. (High, Normal, Eco) Downloaded From projector-manual.com Viewsonic Manuals...
Page 128: Setting 3
No show....Sets the black out image temporarily. (ON, OFF) Freeze......Sets the image to freeze mode. (ON, OFF) Closed caption..Sets the closed caption function. Closed caption...Sets the closed caption mode. (OFF, CC1, CC2, CC3, CC4) Color .....Sets the color of the contents. (Color, White) Downloaded From projector-manual.com Viewsonic Manuals...
Page 129: Information
Lamp off (Lamp is being used over a specified use time, replace lamp Gray/Red immediately) Lamp failure (Lamp failure, check lamp condition) Red/Blue with X Lamp failure (Lamp failure and lamp is being used over a specified use Red/Red with X time, replace lamp immediately) Downloaded From projector-manual.com Viewsonic Manuals...
Page 130: Chapter 5 Appendix
Chapter 5 Appendix Connection examples Use of telnet Web browser setting Q & A Downloaded From projector-manual.com Viewsonic Manuals ViewSonic...
Page 131: Examples Of Connection
Default Gateway : 0.0.0.0 : 0.0.0.0 Computer Name: PC10 IP Address : 192.168.0.10 Subnet Mask : 255.255.255.0 Default Gateway : When the projector is connected to the computer directly without hub, the STP cross cable should be used. Downloaded From projector-manual.com Viewsonic Manuals...
Page 132 Subnet Mask : 255.255.255.0 Subnet Mask : 255.255.255.0 Default Gateway : 192.168.10.1 Default Gateway : 192.168.10.1 Default Gateway : 192.168.10.1 Default Gateway : 192.168.10.1 : 192.168.201.1 : 192.168.201.1 : 192.168.201.1 : 192.168.201.1 Network Group: 192.168.10.x Downloaded From projector-manual.com Viewsonic Manuals...
Page 133: Use Of Telnet
> telnet [return] 2. The telnet application will start and the following window will be displayed. Type as below to connect the projector. > open 192.168.1.201 10000 [return] * Use the IP address assigned to the projector. Downloaded From projector-manual.com Viewsonic Manuals...
Page 134 4 times continuously, the communication will be disconnected automatically. Please try again for the connection. If the password or any command is not entered for more than 30 seconds, the communication will be disconnected automatically. Please try again for the connection. Downloaded From projector-manual.com Viewsonic Manuals...
Page 135: Web Browser Setting
There are various ways to change your browser preferences depending on the version or applica- tions. Please see the setting instructions on next page for example and also refer to on-line help of your web browser. Downloaded From projector-manual.com Viewsonic Manuals...
Page 136: Windows Xp Professional
Select Internet Options from Tools menu on the web browser and then select Security tab and click Customize Level… button. On the security setting window, scroll down and find the Scripting item, make sure that "Enable" is selected in item Active Scripting. Downloaded From projector-manual.com Viewsonic Manuals...
Page 137 If you connect the projector to the computer directly with STP cross cable, this must be unchecked. To designate proxy settings that will not use the proxy server when accessing the projector installed in the local area network, enter the IP address or domain name here. Downloaded From projector-manual.com Viewsonic Manuals...
Page 138 STP cross cable, this must be selected. To designate proxy settings that will not use the proxy server when accessing the projector installed in the local area net- work, enter the IP address or domain name here. Downloaded From projector-manual.com Viewsonic Manuals...
Page 139 If you connect the projector to the computer directly with STP cross cable, they must be unchecked. To designate proxy settings that will not use the proxy server when accessing the projector installed in the local area network, enter the IP address or domain name here. Downloaded From projector-manual.com Viewsonic Manuals...
Page 140: Q&A
(Connect to the company’s network from the branch office or maintenance office by using private line.) Use of internet (Connect to the company’s network from your home, branch office or some other places by using the internet.) Downloaded From projector-manual.com Viewsonic Manuals...
Page 141 Can I register the setting page as a web browser "Favorites" or "Bookmarks"? Please add "Login" page to your "Favorites" or "Bookmarks". Do not add the speci- fied setting page because it will not be able to perform the password authentica- tion correctly. Downloaded From projector-manual.com Viewsonic Manuals...
Page 142 SMTP server is located in your LAN (Local Area Network), the address should be set to the SMTP server in your LAN. The SMTP server located outside of your LAN may not be available for security reason. For further information please contact your network administrator ( p.25). Downloaded From projector-manual.com Viewsonic Manuals...
Page 143 Can I control the projector by using the telnet application? Possible. Please refer to the item "Use of telnet" ( p.46 - 47). What is the MAC address assigned to the projector? The MAC address is displayed in "Network information" menu ( p.14). Downloaded From projector-manual.com Viewsonic Manuals...
Page 144 For further information please consult your local dealer. The version number of the firmware is indicated on the lower part of the "Initial set- ting" page. Version of the firmware Downloaded From projector-manual.com Viewsonic Manuals...
Page 145 PJ Network Manager for Windows Downloaded From projector-manual.com Viewsonic Manuals...
Page 146 Storing the management file......................28 Information saved to the registry ....................28 Registering the target information from the defined file at once......29 Format of the defined file........................30 Example of the defined file.........................30 Login to the target equipment ......................31 Downloaded From projector-manual.com Viewsonic Manuals...
Page 147: Chapter 1 Introducing
* Unauthorized use of a part or whole of the contents in this manual is prohibited. * The contents of this manual are subject to change without notice. Downloaded From projector-manual.com Viewsonic Manuals...
Page 148: Operating Environment
This manual does not provide the description of basic operation and functions for comput- er, web browser, projector and network. For instructions about each piece of equipment or application software, please refer to the respective manual. Downloaded From projector-manual.com Viewsonic Manuals...
Page 149: Chapter 2 Set Up
Chapter 2 Set up Downloaded From projector-manual.com Viewsonic Manuals ViewSonic SNMP Manager Software...
Page 150: Pj Network Manager Installation
To remove the PJ Network Manager software from your computer, perform it with "Add & Remove Programs" on the control panel. (In case of Windows Vista or Windows 7, use "Programs and Features" from the control panel.) Downloaded From projector-manual.com Viewsonic Manuals...
Page 151: Chapter 3 Basic Operation
Chapter 3 Basic Operation Downloaded From projector-manual.com Viewsonic Manuals ViewSonic SNMP Manager Software...
Page 152: Launching And Quitting Pj Network Manager
Event indication.... Indicates the event (ALERT, TRAP, SYSERR) when the event happened. *1 The file in which the Monitor target information and event log information are stored. Refer to item "Storing the management file" ( p.28) for further details. Downloaded From projector-manual.com Viewsonic Manuals...
Page 153: Quitting Pj Network Manager
Command history display Displays all of command history. Tool bar Switches tool bar on or off. Help Version information Displays version of software. What's Target Target indicates the network equipment which provides an SNMP agent function . Downloaded From projector-manual.com Viewsonic Manuals...
Page 154: Name Of The Button On The Tool Bar
Connection error (Target has been disconnected from the network) Acquisition error (Target has been disconnected from the network, or does not provide SNMP function.) Unknown (Target monitoring is not operating) Downloaded From projector-manual.com Viewsonic Manuals...
Page 155: Addition Of The Target
Target deletion can be executed by selecting Target deletion from Target menu. It cannot perform the target addition, editing and deletion during the target monitoring. Up to 200 targets can be registered. Up to 255 characters can be used for target name and community. Downloaded From projector-manual.com Viewsonic Manuals...
Page 156: Setting Up The Warning Value
PJ Network Manager starts polling the target in a sequential from the top of the status list and displays the results on the status list. Downloaded From projector-manual.com Viewsonic Manuals...
Page 157: When Happens The Alert On The Target
Trap is the event predefined by the SNMP agent. If the predefined event ( "When PJ lamp is off", "When internal PJ power circuit is failed" etc. ) happens, target sends trap information to the SNMP manager. Downloaded From projector-manual.com Viewsonic Manuals...
Page 158: Stopping Monitoring The Target
"---" will not set the group. The projectors setting different network passwords cannot be set to the same group. It is nec- essary for the projectors in the same group to set to the same password. Downloaded From projector-manual.com Viewsonic Manuals...
Page 159: Setting Up The Password Of Telnet
Commands batch processing dialog box will be checked. Click OK button. The commands are carried out to all the targets of the same group. The commands also work for the target which is not set to a group. Downloaded From projector-manual.com Viewsonic Manuals...
Page 160: Setting Timer For Targets
When selecting multiple targets, timers are set to all the selected targets. Timer Items Description Execution date......Sets up the Timer execution date. (everyday or a day) Execution time Sets up the Timer execution time. (hh:mm:ss) ......Action ........Sets up the events. Downloaded From projector-manual.com Viewsonic Manuals...
Page 161: Setting Up Default Setting
Event reception process..Sets up the treatment when the event (ALERT, TRAP, SYSERR) happens on the target. For further information, refer to the item "About event treatment" ( p.26). p Sound warning alarm p Send e-mail p Display warning dialog Downloaded From projector-manual.com Viewsonic Manuals...
Page 162 Up to 10 addresses can be set up for the destination mail address. For the contents of the mail, refer to item "About event treatment" ( p.26). Downloaded From projector-manual.com Viewsonic Manuals...
Page 163: Customizing The Status List
*Filter time........Use time of airfilter *Option Box filter time........Use time of option box filter The values in parentheses are typical value and they differ depending on the connected equipment. The [*] next to the column name indicates alert items. Downloaded From projector-manual.com Viewsonic Manuals...
Page 164 *1 Set up the installed date when the PJ Network Manager is newly introduced. There are some un-available columns depending on the products. The value of un-available col- umn is displayed in blank or with "---". Downloaded From projector-manual.com Viewsonic Manuals...
Page 165 Select Font setting from System menu. The font setup window will appear. Select your desired type face, style and size on the window. Customized font property is applied to all the windows of the setting. Downloaded From projector-manual.com Viewsonic Manuals...
Page 166: Viewing The Alert Information
To export the alert information as text file (CSV file), click Export button. Column width can be changed with dragging the right edge of the column. The column order can be changed with drag and drop the column. Column can not be deleted. Downloaded From projector-manual.com Viewsonic Manuals...
Page 167: Viewing The Event Log
It switches ascending or descending order by clicking the column name each time. Column width can be changed by dragging the right edge of the column. The column order can be changed with drag and drop the column. Column cannot be deleted. Downloaded From projector-manual.com Viewsonic Manuals...
Page 168: Description Of Event, Type, Warning Column, Warning Value
*1 When PJ Network Manager could not send mail or acquire the memory, no message is displayed in "Warning column" and "Warning value". For further details of each warning column and value, refer to the next page. Downloaded From projector-manual.com Viewsonic Manuals...
Page 169 Up to 1000 of events can be stored. If it exceeds 1000 events, the oldest event is deleted and the latest event is added. The event log can be saved to the management file. This Warning column is not available for some projector's model types. Downloaded From projector-manual.com Viewsonic Manuals...
Page 170: About Event Treatment
Windows Firewall, the send e-mail function is not available. When using this mail function, you need to cancel the block for PJ Network Manager application. For the further details of Windows Firewall, see Windows help on your computer. Downloaded From projector-manual.com Viewsonic Manuals...
Page 171: Viewing The Command History
Column cannot be deleted. Up to 1000 of events can be stored. If it exceeds 1000 events, the oldest event is deleted and the latest event is added. Downloaded From projector-manual.com Viewsonic Manuals...
Page 172: Storing The Management File
Status list information .... Display status column, column width and column order Event log list information..Column width and order of the event log list Font set up........Font setting value (Type face, size and style) Downloaded From projector-manual.com Viewsonic Manuals...
Page 173: Registering The Target Information From The Defined File At Once
* If there is an error in the imported defined file, the error information will be indicated on the Result column. Retry importing after correcting the defined file. Click OK button to execute the registration. Target batch registration is not available during Target monitoring. Downloaded From projector-manual.com Viewsonic Manuals...
Page 174: Format Of The Defined File
The table below shows the example of the defined file provided with the target informa- tion. Save this file as the CSV file. Target name IP address Community Proj_01 192.168.0.1 public Proj_02 192.168.0.2 public Proj_03 192.168.0.3 public Proj_04 192.168.0.6 public Proj_05 192.168.0.7 public PDP_01 192.168.0.8 public FPD_10 192.168.0.9 public Downloaded From projector-manual.com Viewsonic Manuals...
Page 175: Login To The Target Equipment
You can control and set up the projector remotely by using the web browser. For the fur- ther information of instruction, see the separated network owner's manual. Login by dou- ble clicking An example of the login page. Downloaded From projector-manual.com Viewsonic Manuals...
Page 176 Downloaded From projector-manual.com Viewsonic Manuals...

This manual is also suitable for:

Pjl6233

ViewSonic PJL6223 User Manual

Table of Contents

Table of Contents

Chapter 1 Preparation

Chapter 2 Setup Procedures

Chapter 3 Basic Setting and Operation

Chapter 4 Controlling the Projector

Chapter 5 Appendix

Pj Network Manager for Windows

Quick Links

User Guide

Chapters

Related Manuals for ViewSonic PJL6223

Summary of Contents for ViewSonic PJL6223

This manual is also suitable for:

Table of Contents
