When tow-starting, it is important that you
observe the safety instructions
Y
( page 238) and the legal requirements in
each respective country.
X
Switch on the hazard warning lamps
Y
( page 96).
X
Fit the towing eye (
X
Secure the rigid towing bar or the towing
rope.
X
Depress and hold the brake pedal.
X
Turn the key to position 2 in the ignition
lock.
X
Depress the clutch pedal fully, engage
second gear and keep the clutch pedal
fully depressed.
X
Release the brake pedal.
X
Tow-start the vehicle.
X
Release the clutch pedal slowly; do not
depress the accelerator pedal while
doing so.
X
When the engine is started, immediately
depress the clutch pedal fully and select
neutral.
X
Pull over at a suitable place and stop the
vehicle safely, paying attention to road
and traffic conditions.
X
Secure the vehicle against rolling away
with the parking brake.
X
Remove the rigid towing bar or towing
rope.
X
Remove the towing eye (
X
Switch off the hazard warning lamps.
Electrical fuses
Important safety notes
G
WARNING
If you manipulate, bridge or replace a
faulty fuse with a fuse of a higher amper-
age, the electric cables could be overloa-
ded. This may result in a fire. There is a
risk of an accident and injury.
Y
page 239).
Y
page 240).
Always replace faulty fuses with specified
new fuses of the correct amperage.
! Only use fuses that have been approved
for smart vehicles and which have the
correct fuse rating for the system con-
cerned. Components or systems could
otherwise be damaged.
The fuses in your vehicle serve to discon-
nect faulty circuits. If a fuse blows, all the
components on the circuit and their func-
tions will fail.
Blown fuses must be replaced with fuses of
the same rating, which you can recognise by
the colour and fuse rating. The fuse ratings
are listed in the fuse allocation chart
Y
( page 243).
If the newly inserted fuse also blows, have
the cause traced and rectified at a quali-
fied specialist workshop, e.g. a Mercedes-
Benz Service Centre.
Before replacing a fuse
X
Secure the vehicle against rolling away
Y
( page 138).
X
Switch off all electrical consumers.
X
Turn the key to position 0 in the ignition
lock and remove it (
cator lamps in the instrument cluster
must be off.
The fuses are located in various fuse boxes:

Fuse box in the front area

R
Fuse box in the glove compartment
R
Fuse box in the front area
Pay attention to the "Important safety
Y
notes" ( page 241).
G
WARNING
If the windscreen wipers start to move when
the service cover is open, you could become
caught up in the wiper rods. There is a risk
of injury.
Electrical fuses
Y
page 121). All indi-
