- Page 1 Owner’s Manual Ceiling Fan Installation Instructions For 8ATR44XXD-L Series Fans READ AND SAVE THESE INSTRUCTIONS Total fan weight with light...
-
Page 2: Installation
Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70- 1999), including fire-rated construction. - Page 3 Install upper glass over downrod Install canopy over downrod. Tighten both yoke set screws and onto fan body. Caution: Replace pin and ball onto lock nuts to further secure downrod. downrod. Safety cable installation Safety Cable Lag Screw safety cable washer lock 3”...
- Page 4 Install glass to fan using the 3 ball Attach blade assembly to arms from screws provided. motor housing using screws and Install glass to fan. washers provided. Tighten screws securely. HAND HELD INSTALL WALL MOUNT INSTALL Remove cover by snaping off from top or bot- Install wall control unit to outlet box tom.
-
Page 5: Fan Speed
Remote Control Transmitter Features: FAN REVERSE LED LIGHT (Press once to change direction of MEDIUM SPEED the fan)Fanmust be running to reverse. HIGH SPEED LOW SPEED FAN OFF SETTING UPLIGHT ON/OFF SET- (Turns fan off only) TING AND DIMMER (Press and hold to dim light infinitively) DOWNLIGHT ON/OFF SETTING AND DIMMER... -
Page 6: Troubleshooting
Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart.
