- Page 1 Owner’s Manual Ceiling Fan Installation Instructions For 5EXR60XXD-L Series Fans READ AND SAVE THESE INSTRUCTIONS Total fan weight with light...
-
Page 2: Installation
Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70- 1999), including fire-rated construction. - Page 3 Remove keeper from cross pin and Secure mounting neck to the mounting plate Lift mounting neck to mounting Plate and align then cross pin from yoke. Replace with four screws to become a complete mount- screws. ing bracket. keeper on cross pin and save. Loosen lock nuts and screws on yoke Remove three screws from fan as Place upper glass over the fan body.
- Page 4 Safety cable installation Safety Cable Lag Screw safety cable washer lock 3” lag washer screw Fan and light kit combinations over 35 lbs, Raise fan with downrod assembled to in both flush and downrod mode the safety cable must be installed into the house struc- the ceiling bracket and hang fan Install 6 x 15 watt candelabra base ture beams using the 3”...
- Page 5 To install with- out light kit go CA 12 entré to step 33. To install with light kit go to Aver tacte step 34. vous Twist lower cover plate into place by Replace 1 screw removed and tighten twisting in direction of arrow. all 3 screws securely.
-
Page 6: Fan Speed
Transmitter Controller Features: LED LIGHT Increases Speed FAN REVERSE (Press once to change direction of the fan)Fanmust be running to reverse. Memory Feature FAN OFF SETTING UPLIGHT ON/OFF SET- (Turns fan off only) TING AND DIMMER (Press and hold to dim light infinitively) DOWNLIGHT ON/OFF SETTING AND DIMMER... -
Page 7: Troubleshooting
Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet.
