- Page 1 Owner’s Manual Ceiling Fan Installation Instructions Flush Mount -No light kit Downrod with light kit Flush Mount -Light kit Downrod without light kit For 5WS52XXD-L Series Fan READ AND SAVE THESE INSTRUCTIONS Total fan weight with lights...
-
Page 2: Installation
Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70- 1999), including fire-rated construction. - Page 3 House Blue Black Black White White Green Ground Make wire connections to the power source using wire nuts provided. Make sure that no filiments are outside Connect black and blue wire from fan Securely attached the mounting plate of the wirenut. After making the wire connections, the to Black or (Hot) wire from house.
- Page 4 Install switch cap with fitter onto fan Remove the finial, finial cap, hex nut, Connect plug from motor to the plug using 3 screws removed from step and rubber washer from the fitter. from the switch cap. 17 and tighten securely. Install 2x40 watt candelabra bulbs.
- Page 5 The studs on the mounting plate pro- Remove the cotter and keeper pins Thread leadwires and safety cable trude through the slots in the motor and save for later use. through the mounting plate. bracket .Securely tighten the lock- nuts onto the threaded studs. Thread leadwires and safety cable Insert downrod into yoke.
- Page 6 House Blue Black Black White White Green Ground Make wire connections to the power source using wire nuts provided. Make sure that no filiments are outside Connect black and blue wire from fan to Black or (Hot) wire from house. of the wirenut.
-
Page 7: Troubleshooting
Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet.
