VisuaLink 128/384 Quick Installation Guide
Chapter 1 Introduction
1.1 General
NT1
(One for 128)
(Three for 384)
NDA-24232 Issue 2.0
This chapter provides general identification, installation, shipping and receiving
information for the VisuaLink 128/384. The system consist of four major
components, the equipment cabinet, the television monitor, the video camera and
the VisuaLink 128/384 unit with remote control and cable bundle.
Depending on the system application ordered, anywhere from one to four major
components (boxes) could be shipped
POWER
LINE
POWER
B1
Figure 1-1: Rollabout 128/384 System
Note: This system contains five (5) major components: equipment cabinet,
television monitor, video camera, NT1(s) and VisuaLink 128 or
VisuaLink 384 unit with remote control.
HEADSET
B2
Chapter 1
Power Switch
VisuaLink 128/384
Power Strip
Page 1-1
