Simplex
®
6200 Series
Light Commercial / Residential Locks
Mechanical Features
Construction:
All metal; cast front housing; force-proof clutch-protected exterior thumbturn; interior reinforcing plate
with brass trim plate; fixed wrought brass interior knob
Installation:
ASA 161 door preparation with additional feature holes; 2
housing; 1" (25 mm) diameter cross bore for latch; 2 x
inverted if the existing auxiliary lock obstructs installation
Minimum stile
5" (127 mm)
requirement:
Door handing:
Factory-handed left; field reversible
Numeric pushbuttons:
Vandal resistant, 5 button, anodized aluminum, mechanical
Weight:
4.5 lbs. (2 kg)
Strike:
TS strike plate; DB (Deadbolt) strike box
Latch:
1
⁄
" (13 mm) throw latch, floating or flat face plate
2
Backset:
2
3
Door thickness:
1
3
Finishes:
60 Gold Tone, 67 Almond, 85 Black or 86 Gray powder paint
Control:
Combination change tool
Lock Operation
Combination code:
One code per lock made of any combination of one to five numbers (pressed individually
or simultaneously)
Code:
Thousands of possible combinations
Certification and Testing
Fire rating:
Three-hour UL / ULC Fire rating for "A" label doors
⁄
" (70 mm) or 2
3
⁄
" (60 mm) backset
4
8
⁄
" (35 mm) to 2
1
⁄
" (57 mm), wood or metal
8
4
1
⁄
" (54 mm) diameter through bore for
8
1
⁄
" holes for mounting bolts. The lock can be
4
37
