Simplex
®
3100 Series
Narrow Stile Lock
Mechanical Features
Construction:
Heavy-duty American zinc-case mortise; all metal; cast front housing
Installation:
Retrofits Adams Rite 4510 / 4710 mortise latch preparations. Through bolt installation restricts forcible
removal of the front housing.
Door handing:
Factory-handed; not field reversible
Numeric pushbuttons:
Vandal resistant, 5 button, plus Enter button, anodized aluminum, mechanical
Weight:
8 lbs. (3.6 kg)
Stile width:
1
7
Stile thickness:
1
3
Strike:
Compatible to Adams Rite
Latch:
Mortise latch, heavy-duty
Backset:
31
⁄
32
Finishes:
Satin Chrome 26D (626); 55 (695) Duranodic
Control:
Combination change tool and wrench
Lock Operation
Combination code:
One code per lock made of any combination of one to five numbers (pressed individually
or simultaneously)
Code:
Thousands of possible combinations
Emergency access:
Mechanical Key override
Certification and Testing
Accessibility standard: Americans with Disabilities Act (ADA) compliant push / pull paddles
Environmental
Highly weather resistant
operating conditions:
Durability:
Conforms to ANSI 156.5
Warranty:
1 year
⁄
" (48 mm) minimum, 2" (51 mm) maximum required for mounting
8
⁄
" (44 mm) maximum
4
5
⁄
" (19 mm) thick bolt with dead latch
8
" (25 mm) or 1
1
⁄
" (29 mm)
8
23
