Simplex ® 8100 Series
Heavy-Duty Lock
Mechanical Features
Construction: Cast front housing; brass unified trim plate; fixed cast ADA - compliant levers
Installation:
Standard (86) mortise preparation.
Door handing: Factory-handed; not field reversible
Numeric pushbuttons:
Vandal resistant, 5 button, anodized aluminum, mechanical
Minimum stile 5" (127 mm)
requirement:
Weight:
9.8 lbs. (3.7 kg)
Strike: 4 7
Latch:
1" (25 mm) optional deadbolt;
Backset: 2 3
Key override:
Compatible with major manufacturers of removable cores: ASSA, Best and Compatibles (6 or 7-pin
length), Corbin / Russwin, Medeco / Yale (6-pin length), Sargent, Schlage
Door thickness: 1 3
Finishes:
Bright Brass 03 (605); Antique Brass 05 (609); Satin Chrome 26D (626)
Control:
DF5 keys or thumbturn for passage and lockout
Lock Operation
Combination code:
One code per lock made of any combination of one to five numbers (pressed individually
or simultaneously)
Code: Thousands of possible combinations
Emergency access:
Optional mechanical key override
Certification and Testing
Accessibility standard: Americans with Disabilities Act (ADA) for lever equipped lock
Fire rating: Three-hour UL / ULC Fire rating for "A" label doors
Environmental Highly weather resistant
operating conditions:
Durability: Conforms to ANSI 156.13
Warranty:
1 year
⁄ " (124 mm) L x 1 1 ⁄ " (32 mm) W x
8 4
3 ⁄ " (19 mm) two-piece anti-friction latch; accommodates
4
⁄ " (70 mm)
4
⁄ " (44 mm) to 2 1 ⁄ " (57 mm)
4 4
1 ⁄ " (6 mm) Deadbolt / Latch mortise strike plate
4
18
1 ⁄ " (13 mm) throw
2
