Simplex ® 1000 Series
Heavy-Duty Lock
1
2
3
4
5
7 3 ⁄ "
8
(187 )
mm
3 1 ⁄ "
8
(79 )
mm
Front Exterior
Example
1 0
Model Locking Device
Build the model number with the desired options
Locking Device
Model
101 1
1
Combination entry ⁄ " (13 mm)
2
throw latch
102
floating face plate
Combination entry
5
Key override
3
⁄ " (19 mm)
4
103
throw latch
Combination entry
beveled face plate
Passage mode
104
Combination entry
Passage mode
Key override
Items supplied with the lock:
- Standard & ASA strikes
- Installation instructions
2 3 ⁄ "
8
(60 )
mm
3 13 ⁄ "
16
(97 )
mm
Side Exterior
1 0 2 1 B
Key Override
Key Override
Compatible with removable core
cylinders (not supplied).
A
ASSA
B
Best & Compatibles (6 or 7-pin length)
C
Corbin/Russwin
M
Medeco* / Yale (6-pin length)
*5-pin Medeco cylinder requires a
special knob spacer. Request spacer
when ordering, part number 201569
(supplied free of charge)
R
Sargent
S
Schlage
- Full-scale template
- Combination change access key
9"
(229 )
mm
3 1 ⁄ "
4
(83 )
mm
Back Interior
- -
2 6 D 4 1
-
Finishes
03
Bright Brass (605)
05
Antique Brass (609)
026
Bright Chrome (625)
Available for models 101
and 102 only.
26D
Satin Chrome (626)
- All hardware required for a complete installation
13
Model 1011 Model 1021
• Combination Entry • Combination Entry
• Key Override
Model 1031 Model 1041
• Combination Entry • Combination Entry
• Passage • Key Override
• Passage
-
4 1
Finish Packaging
Packaging
41
1 per box
Locks
shipped
5 per case
