  • Page 1 SIMPLEX ® 3000 SERIES Drive Assembly Installation Instructions...

  • Page 2: Table Of Contents

    • safety goggles Warnings and Cautions Important: Carefully inspect windows, doorframe, door, etc. to ensure that the recommended procedures will not cause any damage. Kaba Access Control’s warranty does not cover damages caused by installation. Caution: Wear safety glasses when preparing door.

  • Page 3: Hardware Disassembly

    A. HARDWARE DISASSEMBLY FIGURE 1 Adams-Rite Cam Plug in A-1 Remove Adams-Rite face plate from Cylinder Hole edge of door exposing the cylinder set Narrow Part #4580 Stile screws (See Figure 1). Adams-Rite Adams-Rite A-2 Loosen the cylinder set screw (securing Cam Plug Dead Latch Part #4580...

  • Page 4: Cam Plug Handing

    B. STILE PREPARATION FOR COMBINATION SIDE OF DOOR FIGURE 3 Narrow Stile Install Adams-Rite cam plug Adams-Rite #4580 to the Adams-Rite dead Dead Latch latch. Snug tighten the cylinder Cardboard Template Assembly ⁄ " B.S.—R.H. set screw (See Figure 1). See Part #64145 Adams-Rite Section E-1 for final screw...

  • Page 5: Stile Preparation For Trim Plate Side Of Door

    C. STILE PREPARATION FOR TRIM PLATE SIDE OF DOOR FIGURE 5 (Trim plate assembly is included in lock housing box marked 3001 or 3002). Narrow Stile Secure an Adams-Rite cam plug #4580 to the trim plate side of the dead latch assembly. Note: Installation of this cam plug will require the opposite handing as used on the combination lock side of the door.
  • Page 6 (1) year. Kaba Access Control will repair or replace, at our discretion, locks found by Kaba Access Control analysis to be defective during this period. Our only liability,...
  • Page 9 Notes...

  • Page 10: Drill Lock And Trim Plate Mounting Holes

    D. DRILL LOCK AND TRIM PLATE MOUNTING HOLES FIGURE 7 Adams-Rite D-1 Remove Adams-Rite cam plug(s) Cam Plug in and Adams-Rite dead latch assembly Cylinder Hole Narrow Part #4580 from door (See Figure 7). (This will Stile prevent chips from entering the Adams-Rite Adams-Rite latch.)

  • Page 11: Hardware Assembly

    E. HARDWARE ASSEMBLY FIGURE 9 Adams-Rite Cam Plug in Re-install Adams-Rite dead latch assembly. Cylinder Hole Re-install Adams-Rite cam plug or plugs Narrow Part #4580 Stile (Do not tighten cylinder set screw) (See Adams-Rite Figure 9). Adams-Rite Cam Plug Dead Latch Part #4580 E-2 Locate the drive assembly on lock side of Assembly...
