Detailed Set Up Instructions

The easiest way to set up the DSL-302G ADSL Modem is to simply insert the Installation CD into the CD-ROM
drive of a computer you intend to use with the device, launch the automatic installation software and follow the
instructions as they are presented.
You will need some information from your ISP or ADSL service provider about your account, and some
information about your computer or LAN. For your convenience, a table listing the required information is
presented below. It is recommended that you record this information in the table provided, or some other secure
place, in case
Installation Overview
The steps listed here are a summary of the procedure used to access the management software and configure the
Modem without using the automatic installation software.
1. Install the USB driver and Ethernet diagnostic utility on your computer.
2. Restart your computer.
3. Connect the modem to your computer and the ADSL telephone line and power it on as described in the
previous section.
4. If you are using the USB port to connect the modem to your computer, the USB driver you installed
above will now find the modem and establish the connection. Once the connection is made, the USB
connection will appear in the Windows Control Panel as an Ethernet NIC.
5. If you are using the Ethernet port to connect the modem to your computer, the connection will now be
active.
6. Change the IP settings of your computer so you can access the web-based configuration software
through the Ethernet port or the USB port. The factory default LAN IP settings for the Modem are:
Ethernet port:
USB port:
7. Configure your modem using information given to you by your service provider. The modem uses this
information to establish the ADSL connection to the WAN.
8. Save the settings and restart your modem.
Before You Start
Please read and make sure you understand all the prerequisites for proper installation of your new Modem. Have
all the necessary information and equipment on hand before beginning the installation.
Note
DSL-302G ADSL Modem User's Guide
IP address = 10.1.1.1
IP address = 10.1.1.2
If you will use the DSL-302G's USB port to connect to your
computer, do not connect the USB cable to the modem until you
have finished all of the steps to install the USB driver, and your
computer has restarted.
subnet mask = 255.0.0.0
subnet mask = 255.0.0.0
