Startup Procedure for Out-of-Band Management

In out-of-band management, you manage the unit through Port 1.
Procedure
To start up the BitStorm 2600 using out-of-band management:
2600-A2-GN20-50
1. Assign an IP address, netmask, and next-hop router using the configure
management command. For example:
PDYN# configure management out-of-band address
137.90.80.3 255.255.255.0
PDYN# configure management default-gateway 137.90.80.1
You can now access the web interface by typing into the Location field of your
web browser the IP address assigned to the Port 1. See
Interface on page 4-8.
Do not configure inband and out-of-band management on the same subnet.
2. Configure routers as necessary to route data from the NOC to the
BitStorm 2600.
