4. Configuration
Alternatively, the uplink may be tagged and DSL ports untagged.
Procedure
4-6
2. Delete untagged ports from VLAN 1:
PDYN#!configure vlan modify 1 ports untagged delete
Vlan 1 default, 'untagged' ports 'delete', modified
successfully.
3. Create a new VLAN (VLAN 2 in this example):
PDYN#configure vlan create 2
Vlan 2 Created successfully.
4. Add untagged ports to VLAN 2:
PDYN#!configure vlan modify 2 ports untagged
mgmt_i,eth3
Vlan 2 , 'untagged' ports 'mgmt_i,eth3', modified
successfully.
5. Display the configuration of VLAN 2:
PDYN#!sho vlan configuration 2
VLAN 2
Name
Tagged Members
UnTagged Members
ProxyARP
Secure Mode
Proxy Arp NHR
1. Add a tagged port to VLAN 2:
PDYN#!configure vlan modify 2 ports tagged eth3
Vlan 2 , 'tagged' ports 'eth3', modified successfully.
2. Add untagged ports to VLAN 2:
PDYN#!configure vlan modify 2 ports untagged mgmt_i
Vlan 2 , 'untagged' ports 'mgmt_i', modified
successfully.
3. Display the configuration of VLAN 2:
PDYN#!sho vlan configuration 2
VLAN 2
Name
Tagged Members
UnTagged Members
ProxyARP
Secure Mode
Proxy Arp NHR
April 2005
mgmt_i, eth3
enabled
enabled
0.0.0.0
eth3
mgmt_i
enabled
enabled
0.0.0.0
2600-A2-GN20-50
