Index

Numerics
10/100BaseT pinouts, A-3
1000BaseT pinouts, A-3
A
AC power, 2-12
Activity LEDs, 3-2
administrator, login, 4-4
Alarm
connector pinouts, A-6
LED, 3-2
port cabling, 2-10
port connectors, A-6
port description, 1-3
audience for this document, iii
autosensing, 2-4, 2-7
B
BitStorm 2600
description, 1-1
brackets
installation for rack mount, 1-6
C
cables, A-1
DSL ports, A-2
MGMT port, A-3
required, 1-3
cabling, 2-1
ALARM port, 2-10
console port, 2-8
DSL ports, 2-2
GigE uplink, 2-3
ground, 2-11
management port, 2-7
Port 1, 2-7
Port 2, 2-4
Port 3, 2-3
POTS ports, 2-2
power, 2-12
T1/E1 MLPPP, 2-5
uplink, 2-4–2-5
CO alarm system, 2-10
CO grounding screw, 2-11
Command Line Interface (CLI), 4-2
2600-A2-GN20-50
commands, 4-2
community strings, 4-10
configuration, 4-1
CLI commands, 4-2
mounting brackets, 1-6
configuring
inband management, 4-5
out-of-band management, 4-7
SNMP parameters, 4-10
connectors, A-1
ALARM, A-6
CONSOLE port, A-3
DSL ports, A-2
front panel, A-1
Management port, A-3
Port 3, A-4
POTS splitter, A-2
T1/E1 uplink, A-5
CONSOLE port, 2-8
cabling and settings, 2-8
connecting modem, 2-9
connector, A-3
description, 1-3
pin assignments, A-3
pinouts, A-5
contents of shipping carton, 1-4
cooling and air handling, C-1
D
DB9
cabling, 2-8
pinouts, A-5
default gateway, 4-2
default password, 4-4
changing, 4-9
desktop installation, 1-12
dimensions, C-2
document purpose, iii
documents
online, iii
ordering, iv
related, iv
DSL ports
cabling, 2-2
description, 1-3
LEDs, 3-2
pin assignments, A-2
