Startup Procedure for Inband Management

With inband management, the BitStorm 2600 is managed using the uplink port.
Procedure
To start up the BitStorm 2600 using inband management:

Changing the VLAN for Inband Management

By default, all ports are untagged members of VLAN 1. This can be modified using
the CLI.
Procedure
To change the VLAN for inband management:
2600-A2-GN20-50
1. Specify the uplink port using the configure uplink command. It must be either
eth2 (Port 2) or eth3 (Port 3). For example:
PDYN# configure uplink eth3
2. Assign an IP address, netmask, and next-hop router using the configure
management command. For example:
PDYN# configure management inband address 137.90.127.3
255.255.255.0
PDYN# configure management default-gateway
137.90.127.1
Do not configure inband and out-of-band management on the same subnet.
1. Display the current VLAN configuration:
PDYN# sho vlan configuration all
VLAN 1
Name
Tagged Members
UnTagged Members
ProxyARP
Secure Mode
Proxy Arp NHR
VLAN 4080
Name
Tagged Members
UnTagged Members
ProxyARP
Secure Mode
Proxy Arp NHR
April 2005
default
1-24, mgmt_i, eth2, eth3
disabled
disabled
0.0.0.0
OutOfBand VLAN
mgmt_o, eth1
disabled
disabled
0.0.0.0
