6. Install two wood screws (not provided) at the same height above the floor and
18.75 inches (476.25 mm) apart. Do not completely tighten the screws. Leave
them so their heads are about 1/4 inch (6 mm) from the wall.
17.85 in (453 mm)
7. Hang the unit from the wood screws to verify that the screws are properly
placed. The screws should freely slide into the top of the key slots in the
brackets.
Do not fasten the unit to the wall until after it is completely cabled and tested.
