Use Cursor And Zoom In Sonar Views (2D, Si, Di) - Humminbird ONIX Operating Manual

U C
SE URSOR AND
You can use the cursor in the 2D Sonar, Side Imaging, and Down Imaging Views. With the cursor activated, you can magnify sonar
returns on the view to get a closer look. You can also magnify the view without the cursor.
NOTE: To display the 2D Sonar View in Split Zoom mode, see Customize the 2D Sonar View: Change the Sonar Mode.
Activate the Cursor
1. Tap a position on the 2D Sonar, Down Imaging, or Side Imaging View.
OR
Move the Joystick.
Cursor Zoom
Use Cursor Zoom to magnify a selected area of the view.
1. With a Sonar View (2D, SI, DI) displayed on-screen, tap Sonar in the status bar.
OR
Press the MENU key once.
2. Select Sonar Options > Preferences > Zoom Mode.
3. Select Cursor Zoom.
4. Press and hold the EXIT key until the menu is closed.
5. Tap a position on screen, or use the Joystick to move the cursor to a position.
6. Zoom: Touch the screen with two fingers and move them apart (pinch out = increase), or move them together (pinch in =
decrease).
OR
Press the +/- ZOOM keys.
7. Close: Press the EXIT key.
Pane Zoom
Use Pane Zoom to magnify the full view.
1. With a Sonar View (2D, SI, DI) displayed on-screen, tap Sonar in the status bar.
OR
Press the MENU key once.
2. Select Sonar Options > Preferences > Zoom Mode.
3. Select Pane Zoom.
4. Press and hold the EXIT key until the menu is closed.
5. Zoom: Touch the screen with two fingers and move them apart (pinch out = increase), or move them together (pinch in =
decrease).
OR
Press the +/- ZOOM keys.
6. Close: Press the EXIT key.
Sonar Cursor & Zoom
Z S V
OOM IN ONAR IEWS
172
(2D, SI, DI)
