MEGA LIVE IMAGING
INSTALLATION GUIDE
532769-3_A
1

Advertisement

Table of Contents
loading

Related Manuals for Humminbird 532769-3_A

Summary of Contents for Humminbird 532769-3_A

  • Page 1 MEGA LIVE IMAGING INSTALLATION GUIDE 532769-3_A...
  • Page 2 Always operate the boat at very slow speeds if you suspect shallow water or submerged objects. WARNING! The electronic chart in your Humminbird unit is an aid to navigation designed to facilitate the use of authorized government charts, not to replace them.
  • Page 3 APEX™, Fortrex™, HELIX®, Humminbird®, Minn Kota®, SOLIX®, Ultrex™ are trademarked by or registered trademarks of Johnson Outdoors Marine Electronics, Inc. © 2021 Johnson Outdoors Marine Electronics, Inc. All rights reserved.

  • Page 4: Table Of Contents

    Table of Contents Introduction Compatibility ................1 Supplies .
  • Page 5 Finding the Cause of Noise ............. 40 Specifications Contact Humminbird...

  • Page 7: Introduction

    • Testing the Installation • Powering Off Before proceeding with this installation, the Humminbird control head and Minn Kota trolling motor should be installed. The MEGA Live Imaging transducer can be connected directly to the control head or to a Humminbird Ethernet Switch (optional, separate purchase required) for networking.

  • Page 8: Supplies

    Cables: Your MEGA Live Imaging transducer comes with the cables required to connect directly to your Humminbird fish finder. In addition to the cables permanently attached to the transducer, this includes two extension cables (a 10' MEGA Live power cable and a 20' Ethernet cable) to allow for quick-disconnect. To connect the Ethernet to a HELIX control head, you will need to purchase an ethernet adapter cable.

  • Page 9: Update Software

    NOTE: It is important to install the latest software update on your control head to enable all MEGA Live features. For the latest software update, visit our Web site at humminbird.com. Check the Current Software Version It is helpful to review the software version number that is currently installed on the control head and each accessory.

  • Page 10: Update Control Head Software With An Sd Card

    Update Control Head Software with an SD Card You will need an SD or microSD card (depending on your control head model). WARNING! Humminbird is not responsible for the loss of data files (waypoints, routes, tracks, groups, snapshots, recordings, etc.) that may occur due to direct or indirect damage to the unit’s hardware or software.

  • Page 11: Update Accessory Software With An Sd Card

    You will need an SD or microSD card (depending on your control head model). 1. Install a formatted SD or microSD card into the computer card slot. 2. Go to humminbird.com, and click Support > Software Updates. 3. Scroll down to Accessories and Mapping. The available software updates are listed as downloads under each accessory product.

  • Page 12: Update Software With Fishsmart

    Update Software with FishSmart You can use the FishSmart App to download and push software updates directly to your Humminbird control head or accessory. NOTE: It is important to install the latest software update on your control head to enable all FishSmart features. For the latest software update, visit our Web site at humminbird.com.

  • Page 13: Install The Trolling Motor Mount

    Install the Trolling Motor Mount Use the following instructions to install the MEGA Live Imaging transducer on your Minn Kota trolling motor. It is important to read the instructions completely and understand the mounting guidelines before you start the installation. 1.

  • Page 14: Install The Landscape Mode Mount

    2. Install the Landscape Mode Mount Landscape Mode Mount Use the following instructions to install the Landscape Mode mount onto the transducer. 1. The Landscape Mode mount should be open for this step of the installation. Unlock the mount by pressing down on the two release release buttons, and pull the mount open.
  • Page 15 3. With the transducer face down and its cables pointed away from you, determine how the Landscape Mode mount should align with the transducer. Recommended Configuration: Align the mount with the hinge on the left for a Port installation or on the right for a Starboard installation (see the illustration Positioning the Landscape Mode Mount).
  • Page 16 4. Connect the Landscape Mode mount to the transducer according to your Recommended or Optional configuration. The ratchets are keyed to allow for Port or Starboard installation. The ribs on the Landscape Mode mount ratchet should align with the marks on your transducer. Connecting the Landscape Mode Mount to the Transducer The ratchets are keyed.

  • Page 17: Install The Shaft Mount

    Compressing the Lock Washer Loose Lock Washer Fully Compressed Lock Washer 3. Install the Shaft Mount 1. Fold the Landscape Mode mount back down using the release buttons. 2. For installation on a Fortrex trolling motor, secure the included small rubber pads to the inside of the shaft mount as shown in the illustration Shaft Mount Rubber Pad Placement.
  • Page 18 3. Align the keys on the shaft mount and the Landscape Mode mount to connect them. Connecting the Shaft Mount to the Landscape Mode Mount The ratchets are keyed. 4. Secure the shaft mount with one of the included lock washers and 1/4-28 screws, using the provided hex bit.

  • Page 19: Install The Shaft Clamp

    4. Install the Shaft Clamp WARNING! Disconnect the motor from all sources of electrical power before you start installation. WARNING! Confirm that the trolling motor is properly secured to the boat and will not shift during the installation. 1. The trolling motor should be in the fully retracted (flat) position on the boat deck for this installation.
  • Page 20 6. Rotate the MEGA Live Imaging transducer around the shaft until it is parallel with the lower unit of the trolling motor (see Aligning the Transducer). This ensures the transducer is pointing in the same direction as the trolling motor. Aligning the Transducer 7.

  • Page 21: Route The Cables And Connect Power

    5. Route the Cables and Connect Power WARNING! The power source must be turned off Molded Anchor Point before you proceed with this installation. 1. Position the first molded anchor point 4-5 inches from the top of the mount. Secure it with a cable tie. Do not fully tighten.
  • Page 22 MEGA Live Views Down View Forward View Recommended Landscape Mode Optional Landscape Mode 3. Adjust the first anchor point as needed and then fully tighten the cable tie. Cable Installation...
  • Page 23 4. Secure the remaining anchor points with cable ties as you route the cables up the trolling motor shaft. Depending on your installation configuration and motor’s shaft length, you may not need all five anchor points. 5. Route the rest of the cables to the side of the trolling motor, over the bow, to the chosen connection locations in Section 1: Prepare for Installation.
  • Page 24 Hand-tightening NOTE: You must ensure your MEGA Live ethernet the Screw Nut and power wires are installed in a location where they will not be cut or ripped by the trolling motor articulating or rotating. Wires damaged by improper installation are NOT covered by the product warranty. 6.
  • Page 25 WARNING! The MEGA Live Imaging transducer should be connected to a main switch, fuse panel, or battery switch. Humminbird does not recommend connecting to a battery without a fuse and a switch. CAUTION: Some boats have 24 or 36 Volt electric systems, but the MEGA Live Imaging transducer MUST be connected to a 12 VDC power supply.

  • Page 26: Install The Choke Cable

    Install the Choke Cable Reduce noise interference (if needed) using the included choke cable. 1. Determine Whether to Install the Choke Cable If an on-board charger is present and attached to the cranking battery, install the choke cable (included) to reduce noise interference in the transducer. If there is not an on-board charger connected to the cranking battery, the choke cable is not required.
  • Page 27 4. Strip back the shield on each end of the cut wires approximately 1/4 inch (6.4 mm). 5. Connect the stripped wires of the charger cable to the butt connectors on the choke cable (red to white and black to black). 6.

  • Page 28: Set Up The Control Head

    Set Up the Control Head Use the following instructions to power on the control head and confirm the MEGA Live Imaging transducer and the GPS Heading Sensor are detected by the unit. CAUTION! It is important to finish all installation connections before powering on the control head.
  • Page 29 GPS Heading Sensor Icon Icon Description Compass: The selected heading sensor is on and heading data is being received. Detected and Active: The GPS receiver is detected and a GPS fix has been obtained. Connected but not Detected or Active: The GPS receiver is connected, but not detected on the network or no GPS fix has been obtained.
  • Page 30 HELIX Series 1. Turn on the power source from the main switch. 2. On the control head, press the POWER key. If you are powering on a control head in a multiple-control head Ethernet network, power on the control head that is connected to the Mega Live Imaging transducer first.

  • Page 31: Set Up Mega Live Imaging On The Control Head

    GPS Diagnostic View Fix type should be 3D or Enhanced External GPS detected 2. Set Up MEGA Live Imaging on the Control Head APEX/SOLIX Series Your APEX or SOLIX control head will automatically detect and subscribe to MEGA Live Imaging. To review the selected sonar sources, open the Settings tool, and select CHIRP Sonar >...

  • Page 32: Test Mega Live Imaging On The Control Head

    Selecting the MEGA Live Imaging Transducer 3. Test MEGA Live Imaging on the Control Head It is important to confirm that the MEGA Live Imaging transducer is providing sonar returns to the display. The instructions in this section should be performed at trolling speeds in calm, open water, in a large area that is far from shallow water, boats, or other obstacles.
  • Page 33 HELIX Series 1. Press and hold the VIEW key. 2. Select Sonar > MEGA Live View. 3. The sonar returns from the MEGA Live scan will begin to display on the MEGA Live View. Review the display for the following information and see the illustrations Reviewing the MEGA Live View.
  • Page 34 (Forward) (Landscape) Control Head Setup...
  • Page 35 Changing the MEGA Live Mode Your control head will automatically select the best mode for your installation. Use the following instructions to manually change the MEGA Live Mode to Down, Forward, or Landscape. APEX/SOLIX Series 1. With a MEGA Live Imaging View displayed on-screen, tap the MEGA Live Mode icon in the status bar.
  • Page 36 HELIX Series 1. X-Press Menu: With a MEGA Live Imaging View displayed on-screen, press the Menu key once. 2. Select MEGA Live Mode. 3. Press the RIGHT or LEFT Cursor keys to select a mode. When you manually change the MEGA Live mode, a message box will display reminding you to also change the transducer's installation orientation.

  • Page 37: Confirm The Heading Sensor Operation

    4. Confirm the Heading Sensor Operation It is important to confirm that the Heading Sensor is installed correctly by reviewing the heading digital readout. NOTE: This procedure should be performed at slow speeds, in calm, open water, in a large area that is far from shallow water, boats, or other obstacles. APEX/SOLIX Series 1.
  • Page 38 Confirming the Heading Digital Readout (APEX/SOLIX) course heading (heading sensor required) HELIX Series 1. Main Menu: Press the MENU key twice. 2. Select the Chart tab > North Reference > Magnetic. 3. Press the EXIT key. 4. Select the Setup tab > Select Readouts (G3N models) or Edit Data Boxes (G4N models).
  • Page 39 Adjust (G3N): To adjust the zero point of the Heading Sensor, select Main Menu > Navigation tab > Heading Offset. Press the RIGHT or LEFT Cursor keys to adjust the setting. Adjust (G4N): To adjust the zero point of the Heading Sensor, select Main Menu >...

  • Page 40: Confirm The Baud Rate (For Devices Connected To Sensor Pigtail Only)

    5. Confirm the Baud Rate (for devices connected to the Sensor pigtail only) If there is an accessory, such as an autopilot, connected to the Sensor pigtail cable wires, you will need to confirm that the devices are communicating at the same baud rate.

  • Page 41: Power Off

    Power Off WARNING! When the boat is stored or at dock, the MEGA Live Imaging transducer must be turned off to prevent draining the battery. Power Off the Control Head 1. APEX/SOLIX Series: During operation, tap the top, right corner of the status bar or press the POWER key, and select Power Off.

  • Page 42: Maintenance

    Maintenance Your Humminbird fishfinder is designed to provide years of trouble free operation with very little maintenance. Use the following procedures to ensure your Humminbird continues to deliver top performance. Control Head Maintenance It is important to consider the following precautions when using your Humminbird control head: •...

  • Page 43: Transducer Maintenance

    Transducer Maintenance Use the following information to maintain the transducer operation. • If your boat remains in the water for long periods of time, algae and other marine growth can reduce the effectiveness of the transducer. Periodically clean the face of the transducer with a cloth dampened with fresh water. •...

  • Page 44: Troubleshooting

    Troubleshooting Before contacting the Humminbird Technical Support, please read the following section. Taking the time to review these troubleshooting guidelines may allow you to solve a performance problem yourself, and therefore avoid sending your unit back for repair. Fishing System Doesn’t Power Up If your Fishing System doesn’t power up, use the installation guide that is included...

  • Page 45: Fishing System Defaults To Simulator With A Transducer Attached

    Fishing System Defaults to Simulator with a Transducer Attached In addition to the MEGA Live Imaging accessory transducer, you will have a standard Humminbird transducer connected to the control head. A connected and functioning transducer with built-in temperature will cause the newly started Fishing System to go into Normal operating mode automatically.

  • Page 46: Finding The Cause Of Noise

    Finding the Cause of Noise Electrical noise usually affects the display with streaks or repetitive patterns on the view. One or more of the following sources can cause noise or interference: Possible Source of Noise Isolation Other electronic devices Turn off any nearby electronic devices to see if the problem goes away, then turn them on one at a time to see if the noise re-appears.

  • Page 47: Specifications

    Operating Temperature ......... 32°F to 158°F (0°C to 70°C) Storage Temperature ........-40°F to 158°F (-40°C to 70°C) NOTE: Humminbird verifies maximum stated depth in saltwater conditions, but actual depth performance may vary due to transducer installation, water type, thermal layers, bottom composition and slope.
  • Page 48 ROHS STATEMENT: Product designed and intended as a fixed installation or part of a system in a vessel may be considered beyond the scope of Directive 2002/95/EC of the European Parliament and of the Council of 27 January 2003 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.
  • Page 49 Notes...

  • Page 50: Contact Humminbird

    Contact Humminbird Contact Humminbird Technical Support in any of the following ways: Web site: humminbird.com E-mail: service@humminbird.com Telephone: 1-800-633-1468 Direct Shipping: Humminbird Service Department 678 Humminbird Lane Eufaula, AL 36027 USA Hours of Operation: Monday - Friday 8:00 a.m. to 4:30 p.m. (Central Standard Time) Social Media Resources: Facebook.com/HumminbirdElectronics...
